Digital Watchdog DWC-B362DIR Manuale utente

ABOUT MANUAL

Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for future reference.

DWC-B362DIR

Digital Bullet Camera

User Manual

01312011

PRECAUTIONS

FCC COMPLIANCE

WARNING : Changes or modifications are not expressly approved by the manufacture.

Do not open or modify.

Do not open the case except during maintenence and installation,

for it may be dangerous and can cause damages.

Do not put objects into the unit.

Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits,

or other damages.

Be careful when handling the unit.

To prevent damages, do not drop the camera or subject it to shock or vibration.

Do not install near electric or magnetic fields.

Protect from humidity and dust.

Protect from high temperature.

Be careful when installing near the ceiling of kitchen or a boiler room, as the temperature may rise to

high levels.

Cleaning

To remove dirt from the case, moisten a soft cloth with a soft detergent solution and wipe.

Mounting Surface.

The material of the mounting surface must be strong enough to support the camera.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC rules. These limits are designed to Provide reasonable protection against harmful

interference. when the equipment is operated in a residential environment. This equipment generates, uses,

and radiates radio frequency energy; and if it is not installed and used in accordance with the instruction

manual, it may cause harmful interference to radio communications.

TROUBLESHOOTING

No VIDEO

Out-of-Focus VIDEO

Before sending your camera for repair, check the following or contact our technical specialist.

Check the coaxial cable and make sure it is connected securely.

Check the lens’ iris adjustment at the menu setup of the camera.

Check the power supply and make sure the camera has the proper voltage and current.

Check the clear dome cover and the lens for dirt or fingerprints. Use a soft cloth and gently clean.

Check the lens manual focal and zoom adjustment. Field test monitor is recommended.

DIMENSIONS IN MILLIMETERS*

CONTROL BOARD*

CON 1

FUNCTIONAL OF CONTROL BOARD

[1] SW : Functional control of OSD (On Screen Display)

[2] CON 1 :Second Video Output Connector

CONNECTIONS*

CAUTION :

Check for polarity when using a DC 12V & AC 24V power supply.

CAMERA SETTING ANGLE*

①

②

ATTENTION

Do not rotate ① more than 360°

Do not unnecessarily twist ② too many times.

OSD MENU SETTINGS*

EXPOSURE

LENS DC / MANUAL

SHUTTER 1/160, 1/100, FLC, 1/250 ~ 100000

OFF / ON

BLC (Back Lignt Compensation)

BLC

AGC OFF ~ 36dB

EXIT JUMP

COLOR

WB MODE AWC / ATW / PUSH LOCK / MANUAL (AWC is recommended.)

R - Y GAIN 0 ~ 255

EXIT JUMP

DAY&NIGHT

DAY&NIGHT MODE AUTO / COLOR / BW

B - Y GAIN 0 ~ 255

EXIT JUMP

FUNCTION

MIRROR OFF / ON

SHARPNESS 0 ~ 49

GAMMA 0.05 ~ 1.00 / USER

OFF / ON

SLC (Side Light Compensation)

OFF / ON

DRC (Dynamic Range Compressor)

EXIT JUMP

SLC

DRC

HME OFF / ON

HME (Highlight Masking Exposure)

MOTION

DELAY OUT (1 ~ 15)

Motion Alarm Zoom-In Delay

SET WINDOW

MOTION

EXIT JUMP

OFF / ON

ALL SET (Set the Entire Screen)

ALL CLEAR (Clear the Entire Screen)

SENSITIVITY (0 ~ 55)

SHOW INDICATOR (OFF / Icon / TRACE)

PRIVACY

OFF / ON

SET WINDOW

OFF / ON

SET WINDOW

OFF / ON

SET WINDOW

MASK 1

MASK 2

MASK 3

MASK 4 OFF / ON

COLOR SET BLACK / GRAY / COLOR 1 ~ 6

EXIT JUMP

SETUP

0 ~ 255

TOP_L/TOP_R/BOT_L/BOT_R

OFF / ON

CAMERA ID

TITLE EDIT

TITLE RESET

TITLE POS.

LANGUAGE

DPC SET

WHITE THR. 0~255

BLACK THR. 0~255

DPC LEVEL. 0~255

English, Chinese

EXIT

SAVE & EXIT

FACTORY SET

PC CONT.

EXIT JUMP

OFF / ON
