Digitus DA-10190 Manuale utente
Power Adaptor AC/DC 90W, for Notebook
Manual
DA-10190
Firstly thank you for purchasing our new 90W ultra slim product, which is
especially designed for charging and supplying power for notebooks and
netbooks. The integrated USB port can charge for iPhone®, iPod®, mobile
phones, MP3, MP4 and other devices. This product has acquired many
patents and certificates already and the max power can reach 90W. Also it
adopts the widest output voltage technology and switch voltage automatically.
With ultra slim appearance and fashion style, it will be one of the best choice
for you and your family.
Product Feature:
1. Ultra slim housing with only 17mm and very competitive size with full
power 90W, smart appearance and portable.
2. Charge or supply power to notebooks with 11pcs DC connectors which
cover the most popular brands in the markets.
3. 100% Automatic switch when different tips used, just plug & go, no fiddly
switch.
4. Adopt SCM computer controlling technique to make sure working
precision.
5. Adopt the newest ultra slim transformer technology.
6. Adopt ABS+PC materials for the housing, being safe and environmental
friendly.
7. Automatic computer electrical overload test and high temperature
overload aging test before shipment to make safer.
8. High efficiency: up to 91%.
9. Self-designing and produced with several applied patents.
10. AC Input 100-240V worldwide compatible.
11. Widest output voltage: 12V to 24V.
12. Multi protections: over temperature, over voltage, over current, short
circuit protection and etc.
Product Diagram
DC Joint
USB output
DC Tips
AC Input
AC cable
Product Specification
AC Input: 100~240V, 1.8A 50-60Hz
DC Output: 12~24V 6A 90W (MAX)
USB output: DC 5V 2A (MAX)
Size: 114*70*17mm
Net Weight: 239g
Package Content:
1. Adaptor Body
2. AC power cord
3. 11pcs Notebook tips
4. User manual
Operation Steps
1. When you want to charge or supply power to laptop, connect the AC plug
into the wall socket (picture A). Choose the right tip, such as N04, connect
it with the DC joint (picture B), put the joint DC tip to the laptop then it
can be used. (picture C)
2. When you use the 5V USB output, connect the USB cable to digital Product
(like tablet pc, smart phones, and etc.), then it can be charged (As picture
D and E)
D E
BC
Notes:
Please check that the product’s feature, connector, and voltage will be
compatible with your laptop, tablet pc, camera and/or other devices; in
accordance to your device's manual instruction. Please read this manual
and its instructions carefully before use. We are not responsible for any
damage caused by incorrect or reckless operation.
Important Safety Information:
This safety guideline is to help you operate your power adapter safely, to
ensure your personal safety and reduce the risk of fire, electric shock or
injury.
1. Do not apply external force on the cord.
2. Do not unplug by pulling the cord.
3. Do not connect a binding cord to the power supply.
4. Do not place the cord or device near heating elements.
5. Do not bend the blade or pins of the plug.
6. If there is any strange sound, smoke or odor, pull of the cable
immediately.
7. Do not disassemble (It may cause fire or electric shock)
8. Do not put any sharp objects into the venting hole of the product
(It may cause fire or electric shock)
9. Ensure to plug the product firmly.
10. Ensure not to use a damaged cable. (It may cause fire or electric shock)
11. Do not place the product on a bed, bag or inside a closet that is not good
for ventilation.
12. Always wipe off the product with soft fabric, not water mop.
(water may cause electric shock)
13. Keep clean the power plug and the outlet
(Dirt may cause a short circuit and fire)
14. Keep the product out of reach of children.
15. Don't unplug the power cord with a wet hand.
(It may cause electric shock)
16. Unplug the power cord if you don't use the product for a long time.
(It may cause heat, fire and electric shock)
Notebook DC Connectors Specification:
No Output
Voltage
Range
Voltage Connectors Spec. Replacement
N04 19V 18.1-19.9V 4.8*1.7*10.7mm
HP/COMPAQ: 18.5V/2.7A, 18.5V/3.5A, 18.5V/3.8A,
18.5V/4.9A; DELTA: 19V/2.64A; ASUS: 19V/2.64A;
NEC: 19V/2.64A
N07 19V 18.1-19.9V 5.5*2.5*10.7mm
IBM: 19V/4.2A; COMPAQ/HP: 18.5V/4.9A, 19V/4.9A;
DELTA: 19V/2.64A.;
TOSHIBA: 19V/3.16A, 19V/3.42A, 19V/4.74A;
ASUS: 19V/4.74A. LENOVO: 20V/2A;
LITEON: 19V/3.16A, 19V/3.42A, 19V/3.95A, 19V/4.74A;
NEC: 19V/2.64A, 19V/3.16A; GATEWAY: 19V/3.16A,
19V/3.42A, 19V/3.68A, 19V/4.74A
N09 19.5V 18.5-20.4V 6.0*4.3*10.7mm
SONY: 19.5V/2.7A, 19.5V/3A, 19.5V/4.1A, 19.5V/4.7A;
FUJITSU: 19V/3.16A, 19V/3.69A, 19V/4.22A
N11 19V 18.1-19.9V 5.5*1.7*10.7mm
TOSHIBA: 19V/3.95A; ACER: 19V/3.42A;
DELTA: 20V/3.5A
N18 19V 18.1-19.9V 5.5*2.1*10.7mm
ACER: 19V/3.16A, 19V/3.42A, 19V/4.74A;
LITEON: 19V/3.16A, 19V/3.42A; NEC: 19V/3.16A
N19 19V 18.1-19.9V 5.5*3.0*10.7mm
SAMSUNG: 19V/3.16A, 19V/3.75A, 19V/4.22A,
19V/4.74A
N22 19.5V 18.5-20.4V 7.4*5.0*12.5mm DELL: 19.5V/3.34A, 19.5V4.62A
N23 18.5V 17.6-19.4V 7.4*5.0*12.5mm HP/COMPAQ: 18.5V/3.5A, 18.5V4.9A etc.
N24 20V 19-21V 7.9*5.5*0.9mm IBM/LENOVO: 20V/4.5A, 20V/3.25A etc.
N35 20V 19-21V
11*5.6*11mm
square tip
Lenovo: 20V2.25A, 20V3.25A, 20V4.5A
N36 19.5V 18.5-20.4V 4.5*3.0 with pin HP: 19.5V2.31A, 19.5V3.33A, 19.5V4.62A
Notes: 1, All listing of brand names are registered trademarks of their respective companies.
Warranty Specifications:
1. Two years of guarantee for our products.
2. The guarantee will be treated as void in case of breakage or manipulation
of the seals of guarantee, if the material is damaged, without suitable
packing and/or damages of transport and in the case of evident samples of
an incorrect manipulation, illegal use, mistreat, blows, falls, dirt... etc.
3. This warranty does not cover the damage done to other equipment used
in conjunction with this unit.
4. Terms subjected to change without previous notice.
Hereby ASSMANN Electronic GmbH, declares that this device is in compliance with the
requirements of Directive 2014/30/EU (EMC), Directive 2014/35/EU (LVD) and the Directive
2011/65/EU for RoHS compliance. The complete declaration of conformity can be requested
by post under the below mentioned manufacturer address.
Warning:
This device is a class B product. This equipment may cause some radio interference in living
environment. In this case, the user can be requested to undertake appropriate measures to
prevent interference.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
