Dimplex DC09MINI Manuale utente
DC09MINI
2.6kW Portable
Air Conditioner
www.dimplex.com.au
INSTRUCTION MANUAL
PLEASE READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USING THE UNIT.
www.dimplex.com.au
CONTENTS
WARNINGS AND PRECAUTIONS 1
STRUCTURE 3
OPERATION 4
CLEANING AND MAINTENANCE 9
TECHNICAL REFERENCE DATA 10
WARRANTY 10
1
IMPORTANT INFORMATION
Carefully read this instruction manual before you install or use
your portable air conditioner. Please retain this manual for product
warranty and for future reference.
CAUTION
• Make sure the inlet and outlet vents are never blocked.
• Ensure the appliance is on a stable, even surface when operating to
avoid water leakage.
• Do not operate this unit in an explosive or corrosive atmosphere.
• When switched to cooling, only operate this unit in ambient
temperatures between 17°C and 35°C.
• Clean the air lter frequently to ensure efcient operation.
• To prevent compressor damage when the unit has been operating and
is turned off, please wait at least 3.5 minutes before restarting.
• This unit needs to be plugged into a 220-240V ~ 50Hz AC, 7 Amp
power outlet.
• Do not use any extension cords with this unit.
• This unit is for indoor operation only.
• Open the adjustable air vent and extend the exhaust pipe (and drain
pipe, if tted) to the closest window before using.
• After starting the unit, the fan will run rst and the cooling display light will
be ash for 3 minutes until then compressor starts working.
• Only professional technicians, manufacturers or service agents can
replace a damaged power cord.
• When the batteries no longer work, they must be removed from the
remote control and disposed of safely.
WARNINGS & PRECAUTIONS
2
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• The appliance can only be connected to power source less than
0.219Ω.
• Clear the water before move the unit.
IMPORTANT
The air conditioner must always be stored and transported
upright. In case of doubt we suggest you wait at least 24 hours
before operation. (Please keep the unit upright at all times)
PACKAGE CONTENTS
• Portable air conditioner
• Extendable window kit (0.48m X 2 pcs)
• Water tray
WARNINGS & PRECAUTIONS
3
1. Controls
2. Cool air outlet
3. Cool air lter
4. Cool air inlet
5. Upper drain plug
6. Hot air outlet
7. Hot air lter
8. Hot air inlet
9. Lower drain plug
STRUCTURE
4
OPERATION
BEFORE FIRST USE
•
Please read these instructions carefully before use and keep them for
future reference.
•
Check your local main voltage whether it is the same as stated on the
appliance.
•
Before using for the rst time, remove any protective lms or stickers
from the appliance and ensure the control knob is in the “OFF” position.
•
Make sure drain plugs (5 & 9) are tted before use.
CONTROLS
5
OPERATION
INSTALLATION
Unpack the unit and remove the exhaust hose
and the hose connector from the storage
compartment at the bottom of the unit.
EXHAUST HOSE INSTALLATION
1. Remove the 2 x joints from the exhaust hose. See picture (1) below,
and connect joint (a) and joint (b) together.
2. Attach the joint to the exhaust hose in an anticlockwise direction. See
picture (2) below.
3. Rotate the exhaust hose clockwise as shown in picture (3), so that
the exhaust hose can be installed on the inner joint.
4. Attach the inner joint to the product. See picture (4).
6
OPERATION
LOCATION
Ensure the portable air conditioner is
installed on a at surface with adequate
space, to ensure the air inlets and outlets
are not blocked.
Keep a minimum clearance of 50cm from
walls and other objects. Locate the unit, so
the exhaust pipe and drain hose can reach
a suitable window, as shown.
Avoid sharp bends or kinks in the exhaust
pipe. The optional adjustable window slider
is included to ensure the exhaust pipe is
held in place (in the window) and prevents
expelled hot air re-entering the room.
The appliance should not be used in damp areas such as a laundry or
bathroom. Do not place the unit where it will be in direct sunlight, as it
may overheat and turn off.
ADJUSTABLE WINDOW SLIDER KIT
The adjustable window slider kit is installed as below:
7
OPERATION
DIRECTIONS
1. Plug the unit into a suitable power outlet.
2. Turn the control knob to the “FAN” position. This will put the
appliance into “FAN MODE”.
3. Turning the control knob to the “COOL” position, will put the
appliance in “COOLING MODE”.
4. The “FULL” indicator light will illuminate when the internal water tank
is full. Note: The unit will also stop working until the tank is emptied.
5. The “OPERATION” indicator light will illuminate when the unit is on
and working.
6. Turn the control knob to the position, to turn the unit off.
8
OPERATION
DRAINING THE WATER TANK
When the air conditioner is used, condensation may be produced that
cannot be removed via the exhaust hose. This water is captured by an
internal water tank. When the water tank is full, the unit will stop working
and the FULL indicator light will turn on.
When the FULL indicator light has turned on, the water tank must be
manually drained by following the below steps:
1. Switch off and unplug the unit.
2. Move the unit to a suitable place to drain the water. Consider placing
a tray or container under the outlet to catch the water.
3. Remove the lower drain plug (9) - refer to parts illustration on page 3.
4. Slightly tilt the unit to the rear to drain the water.
5. Once the water has completely drained, replace the drain plug (9).
IMPORTANT:
• Ensure the drain plug is re-tted to the drain outlet before use.
• Extend the exhaust back out the window before restarting the unit.
