Dimplex DC20DE Manuale utente
For domestic household use
INSTRUCTION MANUAL
Glen Dimplex Connect App
Instructions
Models: DC20DE
only.
Pairing the Device
Connect the Device using EZ mode
Note: EZ mode acts as a broadcast system, which can be added to surrounding app
devices into the state of the distribution network at one time.
1. Connect the dehumidifier to a power source
2. Ensure your Bluetooth and Wi-Fi signal is switched on and working on your mobile
device.
3. Press and hold the Wi-Fi button on the dehumidifier for 5 seconds, until you hear
a long 'beep' sound. If the Wi-Fi indicator light flashed quickly, please repeat the
above until it flashes slowly.
4. Open the Glen Dimplex Connect App.
5. Click 'Add Device.'
6. Click 'Dehumidifier,' to add manually. The app will also search for nearby devices, in
which it can be added automatically.
2
Pairing the Device
Connect the Device using AP mode
Note: AP mode is equivalent to establishing a one-to-one channel transmission.
1. Follow the exact same steps as pairing to EZ mode. After you click 'Add Dehumidifier,'
go to the top right hand corner of the screen, and change to AP mode as per below.
3
Using the app
Create a scene
Using the Glen Dimplex Connect App, you can create a scene in order to automate
routine tasks.
1. Click on 'Scene' at the bottom of your screen.
2. Click on 'Create Scene.'
3. Here you are provided with multiple options for your given scene. These options are
'When weather changes,' 'Schedule,' and 'When device status changes.'
4. If you click 'When weather changes,' this will bring up options such as 'Temper-
ature,' 'Humidity,' 'Weather,' 'Sunset/Sunrise,' and 'Wind Speed.' Click on your
preferred option and follow the prompts on screen. For example, you can set it so
when a certain temperature is hit, the device will switch on or a certain function will
be activated.
5. If you click 'Schedule,' this allows you to set a certain time as to when you want the
device to start running. Follow the prompts on screen, and click 'Save' when satis-
fied. You are able to set a one off time, or an on-going time , for example 7am every
morning.
6. If you click 'When device status changes,' this will allow you to select a certain sta-
tus or function of the device, and choose an action in response. For example, if the
device goes over a certain humidity level, you can have the fan turn on etc.
4
Using the app
Tap-to-Run
Tap-to-Run mode can also be found in the 'Create Scene,' section of the app. This allows
you to create a task or scene, and then tap it once to begin running. Press 'Launch Tap-to-
Run,' and it will bring you to a page with an 'If' and 'Then' section. Press the '+' symbol on
the 'Then' section, and then select either 'Run the Device,' Select smart scenes,' or 'Delay
the action,' and follow the prompts on the app to create a Tap-to-Run button.
5
Other Functions
If you click on the 'Me' section on the bottom right of the page, it will take you to a page as
per below.
Google Assistant & Alexa
If you have a Google Assistant or Alexa device that you would like to connect through the
Glen Dimplex Connect App/ your compatible devices, click on the respective button above
to log into your account, and then follow the prompts on the app to work.
6
Other Functions
Home Management
In Home Management, you can create or join a home to help easily manage your rooms
and devices. Click 'Home Management,' and then 'Create a home,' to add your home
and feautures. To 'Join Home,' you will need an invitation code from the owner of the
home. This is useful if house sitting for someone and the owner wants you to maintain
their appliances.
Message Centre
This is where you may recieve any specific device alarms and system notification mes-
sages.The top panel of the page shows the sections, being 'Alarm,' 'Home,' and 'Bulle-
tin.'
FAQ & Feedback
Click here for a list of frequently asked questions, and if you have one of your own, click
the 'Feedback,' button to create your own query.
7
Customer Care: 1300 556 816
customercare@glendimplex.com.au
www.dimplex.com.au
Supplied by Glen Dimplex Australia
1340 Ferntree Gully Road, Scoresby, Victoria, 3179
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex Australia.
8
