Dimplex GDH-DEH16E Manuale utente

16L DEHUMIDIFIER

OWNERS MANUAL

GDH-DEH16E

Description of components/function 1

Operating Instructions 2

Continuous Drainage Feature 3

Cautions 4

Maintenance 5

Specications Last Page

Comfort. By design

HUMIDITYSETTING

Settinghumidityfrom30%~90%,

while60%RH is recommended.

Powercontrol

On/Off

FAN SPEED

High/Low

TIMERS

Timersetting 1~12

hours.

Lcd display

BUCKETFULL INDICATOR

Watertank is full, when lit

STOP



%RH



Settinghumidity30%~90%

Roomtemperature

Displaytimersetting of autoswitch on / off

Theindicator is on whenthedefrost

function isinoperation.

Bucketfullindicatorthemachinewillstoprunning.

Low fanspeed

Highfanspeed

Heatingmode

LCDdisplay :

FUNCTIONEXPLANATION

DESCRIPTION OF COMPONENTS

AIRFILTER

CONTROLPANEL

WATER

STORAGE

CONTAINER

AIR INLET

OUTLET FOR

DEHUMIDIFIED

DRYAIR

CASTORS

CONTINUOUS

DRAINAGE OUTLET

In heatingmode,theairflow is selectable

(Note:Heating is activatedonlywhenthe

ambienttemperature is below 25 degreeC.)

*Heating mode only available on EP Models*

HEATING

(available on EP Models only)

OPERATIONINSTRUCTIONS

1) Makesuretheplug is firmlyplugged into thesocket.

2) Makesurethewatertank is placed in correct position.

(When using the dehumidifier forthefirsttime, if thefull

tanklampis lit up,justpulloutthewatertankthen

push it backintothecorrect position.)

Whenthewatertankisfull,theindicationlampwilllightup,

thedehumidifierwillstopoperating.Removethewater in

thetank,thenplacethewatertankback to it'sproperposition

themachinewillstart operatingagain.

emove the water in the water

tank with two hands

4DEFROST

Whenoperating in low temperatures(lessthan12°C)thesurface of theevaporator

willaccumualatefrostandeffecttheefficiency of thedehumidifier.When this

happensthemachinewill go intoperiodicdefrostmodeautomatically. This is quite

normal.Defrostlampwillcomeon.Model(GDH-DEH16E)willoperate in

temperaturesdown to 5 . Defrosttimemayvary. If thedehumidifierfreezesup,

turnoff at powersupplyandrestartunit. If thetemperatureremains ataverylow

level,continuouslyoutsidetheoperationalrangeoffthedehumidifier,5°C to35°C,

theunitshould be switched off.

°C.

Full Tank Indicator

1. PreparePVChosetodrainoutwater

(The hose requires an inner dia of 13mm)

2. Takeoutthe bung of the drainage outlet .

3. Takeoutthesoftcover,put it andtubebung

into the bucket forstorage.

4. ConnectthePVChosewiththe drainage outlet.

5.Place the bucket in its original location.

For drainage

Back of the unit

Bucket

Pushbucketbackinto

theunittoward the direction

as thearrowpoints to

DrainagePVC hose

DrainagePVChose

Tube stopple

Tubestopple

Soft cover

ContinuousDrainageFeature

TheProperWay To PlaceTheWaterDrainagePVCHose

PutthePVChoseintotheback of theclosedhole,thenconnectthePVChose

to thefront.

Whenusingcontinuousdrainage,thePVChosemost be placedbelowthedrainage

hole.

CONTINUOUSDRAINAGE

ontinuous drainage outlet

PVC hose is not sold with this unit.

, but is readily available from your local hardware store.

50cm

20 cm

Do notpulltheplug out with the cord Donotspray insect repellent, oil or paintspraynear

the machine

Do notplacethemachine on an unevenKeeptheunit 20 cm awayfromthe

surface wall to dissipatetheheatproperly.Hang

clothing at least 50 cm above the machine

Close windows and doors when in use.

KeepthemachineawayfromWhenmoving or storing,

SAFETY GUIDE

Do not put objects in the machine

Extreme heat Keep dehumidifier upright

MAINTENANCE

For safety reasons please make sure the dehumidifier is unplugged before

cleaning.

1) Cleaning theCasing

A. Wipethecasing using soft andcleancloth.

Use mild detergent and a damp cloth to clean

C. Do not submerge unit in water

2) Cleaning the Air Filter

The purpose of the air filter is to filter dust or other materials in the air.

clean the filter every two weeks.

Cleaning Steps

A. Pull out thefilter gently.

B. Clean the filterby using a vacuum cleaner or washingwithclean water.

C. Place the filter back to it's position.

：

If a problem occurs, unplug the machine and contact your Dimplex Service Center

immediately on 0800 6662824. Do not tamper with the internal workings of the unit.

Then dry the filter with a cloth

Glen Dimplex Australasia Ltd

5 ~ 35

220-240V /50Hz

L/D (30 80%RH)

360W

362*582*270 mm

17.5 kg

SPECIFIC ATION

MODEL

POWER

MOISTUR E REMOVAL

POWER

INPUT

SIZE OF SHELL

( W H D )

WEIGHT

OPERATING

TEMPERATURE

Waste electrical products should not be disposed of with household waste.

Please recycle where facilities exist. Check with your local authority or retailer

for recycling advice.

If the power cord on this unit is damaged it must be replaced by the

manufacturer a service agent or qualified persons in order to avoid

ahazard

38 Harris Road, East Tamaki

Auckland, NEW ZEALAND

TEL:0800 666 2824 FAX:09 274 8472

GDH-DEH16E
