Owner's Guide

Limited Lifetime

Consumer Warranty

For a period of one calendar year from the date of purchase of this auto-security

device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or

replace (with a comparable reconditioned model), free of cost, any electronic control

module which proves to be defective in workmanship or material under normal use,

SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL

AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY

INSTALLED. If warranty service is necessary you must have a clear copy of your sales

receipt containing all of the information shown on the following page.

After the first calendar year, from the date of purchase of this auto-security device,

Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace

(with a comparable reconditioned model) any electronic control module which proves

to be defective in workmanship or material under normal use FOR A CHARGE OF

$45.00, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PRO-

FESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS

ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy

of your sales receipt containing all of the information shown on the following page.

This warranty contains the entire agreement relating to warranty and supersedes all

previous and contemporaneous representations or understandings, whether written or

oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS

CONTENTS.

This warranty is void if the product has been damaged by accident, unreasonable use,

neglect, improper service or other causes not arising out of defects in materials or

construction. This warranty is nontransferable and does not apply to any unit that

has been modified or used in a manner contrary to its intended purpose and does not

cover batteries. The unit in question must be returned to the manufacturer, postage

prepaid. This warranty does not cover labor costs for the removal, diagnosis, trou-

bleshooting or reinstallation of the unit. For service on an out-of-warranty product a

flat rate fee by model is charged. Contact your authorized dealer to obtain the ser-

vice charge for your unit.

These systems are a deterrent against possible theft. Directed Electronics, Inc. is not

offering a guarantee or insuring against the theft of the automobile or its contents

and disclaims any liability for the theft of the vehicle and/or its contents. Directed

Electronics does not authorize any person to create for it any other obligation or lia-

bility in connection with this security system.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD-

ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM-

MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU-

SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-

RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF

NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR

ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH

SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT

NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING,

REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE

ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR

THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

IMPORTANT NOTE:

This product warranty is automatically void if its date code or serial number is

defaced, missing, or altered. This warranty will not be valid unless you have com-

pleted the warranty card and mailed it to Directed Electronics, Inc. within 10 days

after purchase to the address listed on the warranty registration card.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of system installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

Table of Contents

Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

FCC/ID Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Arming While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disarming Without a Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Silent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Remote Valet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

False Alarm Prevention Circuitry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Arming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Disarming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Owner Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Code Hopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Rapid Resume Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Multi-Vehicle Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Security and Luxury Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Standard Configuration

controls the Arm function.

controls the Disarm function.

controls Silent Mode™and an Auxiliary Output.

controls the Panic function.

and pressed simultaneously control Remote Start.

and pressed simultaneously control an Auxiliary Output.

What is Included

■A control module

■Two four-button remote transmitters

■A dual-stage shock sensor (on-board the control module)

■A soft chirp, six-tone siren

■A red status LED indicator light

■A push-button Valet switch

■A starter interrupt relay

Important Information

Congratulations on the purchase of your state-of-the-art vehicle

security system. This system has been designed to provide years

of trouble-free operation. By carefully reading this owner's guide,

you will maximize the use of this system and its features.

The system requires no specific maintenance. Your remote is pow-

ered by a small, lightweight 3-volt lithium battery that will last

approximately one year under normal use. When the battery begins

to weaken, operating range will be reduced and the LED on the

remote will dim. To access the battery for replacement, remove the

rear cover of the remote with a small, flat-blade screwdriver.

System Maintenance

This device complies with Part 15 of FCC rules. Operation is subject

to the following two conditions: (1) This device may not cause

harmful interference, and (2) This device must accept any interfer-

ence received, including interference that may cause undesired

operation.

Caution: Changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to

operate this device.

Transmitter Functions

Your vehicle security system is programmable, making it possible

to assign any button on the transmitter to any specific receiver

function. The remote transmitter initially comes programmed with

the Standard Configuration, but may also be customized by an

authorized dealer. All instructions in this manual assume operation

using the Standard Configuration.

The functions of the buttons described in this section correspond

to a remote transmitter programmed with the default Standard

Configuration. These buttons will function differently in a Custom

Configuration.

Standard Configuration

FCC/ID Notice

LOCK/ARM Button

Pressing arms the security system and locks the vehicle

doors.

UNLOCK/DISARM Button

Pressing disarms the security system and unlocks the vehicle

doors.

AUX Button

Silent Mode and trunk release are controlled by pressing .

(Pressing for less than one second before arming or disarm-

ing activates Silent Mode. Pressing and holding for 1.5

seconds engages the trunk release.)

PANIC Button

Pressing and holding for 1.5 seconds activates the Panic

Mode.

LOCK/ARM and UNLOCK/DISARM Buttons

An optional auxiliary convenience or expansion function that you

have added to your system can be activated by pressing and

simultaneously.

This auxiliary output controls_____________________________.

AUX and PANIC Buttons

Another optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing

and simultaneously.

This auxiliary output controls_____________________________.

Using Your System

Remember, use of the buttons described in all instructions in this

manual corresponds to the Standard Configuration, unless other-

wise specified.

You can arm the security system and lock your vehicle's doors by

pressing for one second. When the system arms, you will hear

a short siren sound (chirp) and the parking lights will flash once.

Once armed, the status LED will flash once per second to indicate

that the system is actively protecting your vehicle. If you hear a

second chirp after arming and notice that the status LED is flash-

ing in a grouped pattern, this signals Bypass Notification. Bypass

Notification is described in further detail in the Diagnostics section

of this manual.

Your vehicle security system can also be programmed to arm itself

automatically 30 seconds after the ignition is turned off and the

last vehicle door has been closed (called Passive Arming). Once the

30-second countdown period initiates, the status LED will flash

twice as fast as it does when the system is armed. After 20

seconds, the siren will chirp once to warn that the system has only

10 seconds remaining prior to arming. The system is not actually

armed at this point. The system arms itself at the 30-second mark.

At this point, the vehicle doors will also lock (if programmed for

Arming

Passive Locking) and the status LED will begin flashing once per

second to indicate armed status. If the system is programmed for

Passive Locking, care must be taken to prevent the keys from being

locked in the vehicle.

NOTE: If any protected entry point (such as a door or switch-protected

trunk or hood) is open, Passive Arming will not engage. Additionally,

each time a sensor is triggered during the 30-second arming countdown,

the countdown starts over.

Arming your security system protects your vehicle in the follow-

ing ways:

■Light impacts trigger a Warn Away Response, causing the siren

to chirp and the parking lights to flash for a few seconds.

■Heavy impacts trip a triggered sequence, which consists of the

siren sounding continuously and the parking lights flashing

for 30 seconds.

■If a door is opened, the siren immediately starts chirping and

the parking lights start flashing to provide an instant

response. Three seconds later, the siren output changes to a

continuous blast. This two-stage progressive response allows

you time to disarm the security system with your remote

transmitter, in case the door is inadvertently opened while

the system is armed.

■Turning on the ignition key triggers the same two-stage pro-

gressive response as opening a door.

■The starter interrupt relay prevents the vehicle’s starter from

cranking.

Altri manuali per Hurricane 3

Indice

Altri manuali Directed Electronics Allarme auto

Directed Electronics

Directed Electronics Clifford G5 Manuale utente

Directed Electronics

Directed Electronics Hurricane 3 Manuale utente

Directed Electronics

Directed Electronics Avital 2300 Manuale utente

Directed Electronics

Directed Electronics Intelliguard 950 Manuale utente

Directed Electronics

Directed Electronics K10 Manuale utente

Directed Electronics

Directed Electronics 555X Manuale utente

Directed Electronics

Directed Electronics Hornet 563T Manuale utente

Directed Electronics

Directed Electronics 556U Manuale utente

Directed Electronics

Directed Electronics AVITAL 3001L Manuale utente

Directed Electronics

Directed Electronics 3901T Manuale utente

Directed Electronics

Directed Electronics 650 ESP Manuale utente

Directed Electronics

Directed Electronics Car Alarm Manuale utente

Directed Electronics

Directed Electronics 417 Manuale utente

Directed Electronics

Directed Electronics PYTHON 210P Manuale utente

Directed Electronics

Directed Electronics Hornet 742T Manuale utente

Directed Electronics

Directed Electronics 381 Series Manuale utente

Directed Electronics

Directed Electronics Concept 650 Manuale utente

Directed Electronics

Directed Electronics Intelliguard 850 Manuale utente

Directed Electronics

Directed Electronics Automate 640M Manuale utente

Directed Electronics

Directed Electronics SmartStart 5000-series Manuale utente

Directed Electronics

Directed Electronics Security System and Convenience 125xv Manuale utente

Directed Electronics

Directed Electronics Python 533 Manuale utente

Directed Electronics

Directed Electronics Viper 5904 Manuale utente

Directed Electronics

Directed Electronics CLIFFORD 320.3X Manuale utente

Manuali Allarme auto popolari di altre marche

Clifford

Clifford 3606X Manuale utente

Ultra Start

Ultra Start 2500M SERIES Manuale utente

Ultra Start

Ultra Start 650 Series Manuale utente

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuale utente

Sparkrite

Sparkrite SRA8 Manuale utente

Viper

Viper 4708V Manuale utente

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuale

Falcon

Falcon Predator XL3 Guida utente

Audiovox

Audiovox Auto Security XR91 Istruzioni operative

Clifford

Clifford Sabre II Manuale utente

CrimeStopper

CrimeStopper CS-8717 Guida rapida

Ultra Start

Ultra Start 450 SERIES Manuale utente

Scytek electronic

Scytek electronic Vectra X3 Manuale utente

Excalibur

Excalibur AL-1860-EDPB Manuale utente

Clifford

Clifford CYBER 2 Manuale utente

Gemini

Gemini 7057 Manuale utente

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuale utente

Magicar

Magicar FAI-440 Manuale utente
