Model 2301 Insert

Part No. 6520-1099

Model ZTR 2301Model ZTR 2301

Model ZTR 2301

Please refer to the 3000 Series Manual (Model

Year 2000) for Safety Policy, Seat Adjustment

Instructions, Controls, Operation Instructions,

Care and Maintenance, and Troubleshooting.

1997-2000

Page 2

DIXON LIMITED WARRANTY POLICY -- MODEL ZTR 2301

This warranty policy applies to all 2301 mowers purchased on or after October 1, 1993.

WARRANTY: Dixon Warranty term is for a period of one (1) year from date of purchase or 200 hours of use,

whichever occurs first. Mowers used for residential homeowner applications (used only at owner's primary place

of residence) are warranted for two (2) years from date of purchase or 200 hours of use, whichever occurs

first. DIXON ZTR MOWERS ARE WARRANTED AGAINST DEFECTS IN MATERIALS AND WORK-

MANSHIP AND PROVIDES FOR REPLACEMENT OR REPAIR OF PARTS INCLUDING LABOR

COSTS. THIS WARRANTY IS SUBJECT TO THE FOLLOWING CONDITIONS AND LIMITATIONS:

1. Warrantyappliesonlytooriginalretailpurchaserofnewandunusedmowersandaccessories.

2. AllDixonwarrantymustbeaccomplishedbyauthorizedDixondealersandinaccordancewithDixonwarranty

policyandallowances.AllwarrantyclaimsmustbeapprovedbyDixonIndustries,Inc.

3. Batterywarranty:Limitedto90daysfromdateofpurchase.

4. AccessoriesWarranty(GrassCatchers,SnowBlades,Covers,etc.):Limitedto90daysfromdateofpurchase.

5. Warrantydoesnotapplytodamageintransitorincidentsofmisuse,negligence,accidents,oralteration.Theuse

ofpartsor componentsotherthanthosesuppliedbyDixonIndustries,Inc.VOIDSALLWARRANTY.

6. Thefollowingitemsarenotcoveredbythiswarrantypolicy:

(a) PickupanddeliverychargesfortransportationofmowertoandfromanAuthorizedDixonDealer'splaceof

business.

(b) Routinemaintenanceoradjustments.

(d) Engines--AllenginesusedonDixonZTRmowersarewarrantedbyeachindividualenginemanufacturer.

(e) Anycostsorexpenseofprovidingsubstituteequipmentwhilerepairworkisbeingperformedonawarranted

mower.

7. Thereisnootherexpresswarranty.Impliedwarranties,includingthoseofmerchantabilityandfitnessfora

particularpurpose,arelimitedtothesamedurationoftheexpresswarranty,andtotheextentpermittedbylaw

anyandallimpliedwarrantiesareexcluded.Liabilitiesforconsequentialdamagesunderanyandallwarrantiesare

excluded.

(Address)

(Dealer's

Signature)

SEE DEALER FOR DETAILS

(Owner's

Name) (Dealership)

DM-

(Address)

(Owner'sSignature)

WARRANTYVALIDATION: Atthetimeofsale,sellingdealermustrevieweachportionofthiswarrantydocument,complete

theinformationsectionbelow,securecustomer’ssignatureandsendcopytoDixonIndustries,Inc.

DATEOFPURCHASE MODEL S/N

Page 3

SPECIFICATIONS

Model ZTR 2301

CHASSIS: Twin 12 gauge side frames and 7 gauge transmission and engine base plate.

BODY: All body parts are made of rotational molded polyethylene. Front body

contains access panel for battery service. Seat tilts forward to allow

transmission service.

MOWER DECK: 11 GA stamped steel construction.

Single 30" cut blade.

Cut height approximately 1" to 4" via 7 position lift handle.

BLADE DRIVE: Mechanical; hand lever engagement.

TRANSMISSION: Each rear wheel is independently driven by chain and sprockets through a

friction mechanical drive.

ENGINE: 16 HP Kohler Command 16, 4-Cycle, Single Cylinder, Overhead Valve, Air-

Cooled, Gasoline, Pressure Lubricated, With Oil Filter, Vertical Shaft,

Aluminum Head and Block with Cast-Iron Cylinder Liner. Smart Spark

Ignition.

STARTINGSYSTEM: Electric by key switch operation with safety interlocks on parking brake and

blade drive.

TIRES: Front 11 X 4.00-5 ribbed tread.

Rear 16 X 6.50 X 8 Multi-Trac.

RECOMMENDED Front 16-21PSI.

TIREPRESSURE: Rear 8-14PSI.

CAPACITIES: Fuel 2.0 gallons total.

Engine 1.25 quarts oil.

DIMENSIONS: Width 32.5" outside rear wheel measurement.

Height 32.0" to top edge of seat.

Length 65.5" hitch tab to front bumper.

Weight 440 lbs.

NOTE: Additional information provided in service instructions under the individual

component.

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

Page 4

Model 2301 Insert

Part No. 6520-1099

SPARE PARTS

Model Year 2000

The ZTR 2301 spare/replacement parts will be the same as the ZTR

3304, with the following exceptions:

Lower Body (no decals): 6514

Left Fender (no decals): 6515

Right Fender (no decals): 6516

Muffler Guard: 5834

Front Wheel & Tire Assembly: 6513

Rear Wheel & Tire Assembly: 7759

ZTR 2301 Model Decal: 7763

Body Wiring Loom: 6519

Wiring Adapter Loom: 2811

2000 Operator's Manual

30003000

3000

SERIESSERIES

SERIES

Page 6

The Dixon® ZTR® Mower is both easy and fun to operate. However,

any power mower must be operated properly to be safe.

It is not a toy or a recreational vehicle.

Before you start to use the mower: read the operator's manual carefully,

andbecomecompletelyfamiliarwiththecontrols.

The information in this operator's manual applies to all

Dixon® ZTR® 3000 Series Model Mowers.

Your Dixon dealer will gladly answer any questions.

IMPORTANT: READ CAREFULLY

See your dealer for warranty service, parts and repairs.

DIXON INDUSTRIES, INC.

A BLOUNT International Inc. Co.

PO BOX 1569

COFFEYVILLE KS 67337 0945

316 251 2000

Page 7

SAFETY ............................................................Pages 2 - 7

WARRANTYPOLICY......................................Page 8

SPECIFICATIONS ...........................................Page 9 - 11

SEATADJUSTMENT ......................................Page 12

CONTROLS .....................................................Pages 13 - 16

OPERATIONINSTRUCTIONS......................Pages 17 - 22

CAREANDMAINTENANCE .........................Pages 23 - 30

STANDARD PARTS LIST................................Page 31

TROUBLESHOOTING ...................................Pages 32- 34

INDEX

3000 Series

Part No. 1855-0599

Page 8

SAFETY

BACK-OVER

RUN-OVER

BLADECONTACT TIP-OVER

RIDING LAWNMOWERS, IF IMPROPERLY OPERATED,

CAN CAUSE SERIOUS INJURY OR DEATH

The most common causes of injury to the operator or bystander...

...read and understand this manual to prevent injuries.

Page 9

SAFETY

Safety Alert Symbol

Whenyou seethis symbol,

BEALERTto thepotential forinjury.

Follow recommended safety precautions and safe operating practices.

Danger

indicates an imminently hazardous situation

which, if not avoided, will result in death or

serious injury.

Warning

indicates a potentially hazardous situation

which, if not avoided, could result in death

or serious injury.

Caution

indicates a potentially hazardous situation

which, if not avoided, may result in minor

or moderate injury. It may also be used to

alert against unsafe practices.

SAFETY SYMBOLS

Page 10

SAFETY

WARNING:The engine exhaust from this product contains chemicals known to the

StateofCaliforniatocausecancer,birthdefectsorotherreproductiveharm.

Thiscuttingmoweriscapableofamputatinghands&feet,

andthrowingobjects.

Failuretoobservethefollowingsafetyinstructionscouldresultin

seriousinjuryordeath.

GENERAL OPERATION:

•Read, understand, and follow all instructions in the manual and on the mower before starting.

• Only allow responsible adults, who are familiar with the instructions, to operate the mower.

• Clear the area of objects such as rocks, toys, wire, etc., which could be picked up and thrown by the blade.

• Be sure the area is clear of other people before mowing. Stop mower if anyone enters the area.

• Never carry passengers.

• Do not mow in reverse unless absolutely necessary. Always look down and behind before and while backing.

• Be aware of the mower discharge direction and do not point it at anyone. Do not operate the mower without either

the entire grass catcher or the deflector in place.

• Slow down before turning.

• Never leave a running mower unattended. Always turn off blades, set parking brake, stop engine, and remove key

before dismounting.

• Turn off blades when not mowing.

• Stop engine before removing grass catcher or unclogging chute.

• Mow only in daylight or good artificial light.

• Do not operate the mower while under the influence of alcohol or drugs.

• Watch for traffic when operating near or crossing roadways.

• Use extra care when loading or unloading the mower into a trailer or truck.

Do not ride the mower when loading & unloading.

• Always wear safety goggles or safty glasses with side shields when operating mower.

• Data indicates that operators, age 60 years and above, are involved in a large percentage of riding mower-related

injuries. These operators should evaluate their ability to operate the riding mower safely enough to protect

themselves and others from serious injury.

• Follow the manufacturer's recommendation for wheel weights or counterweights.
