4000 SERIES

ZTR®MOWERS

Operator's Manual

2001

The Dixon®ZTR®Mower is both easy and fun to operate. However,

any power mower must be operated properly to be safe.

It is not a toy or a recreational vehicle.

Before you start to use the mower: read the operator's manual carefully,

and become completely familiar with the controls.

The information in this operator's manual applies to all

Dixon®ZTR®4000 Series Model Mowers.

Your Dixon dealer will gladly answer any questions.

DIXON INDUSTRIES, INC.

A BLOUNT International Inc. Co.

PO BOX 1569

COFFEYVILLE KS 67337 0945

316 251 2000

IMPORTANT: READ CAREFULLY

See your dealer for warranty service, parts and repairs.

Page 3

INDEX

SAFETY ............................................................Pages 4 - 9

WARRANTY POLICY......................................Page 10

SPECIFICATIONS ...........................................Page 11

SEAT ADJUSTMENT ......................................Page 12

CONTROLS .....................................................Pages 13 - 15

OPERATIONINSTRUCTIONS......................Pages 16 - 21

CAREANDMAINTENANCE .........................Pages 22 - 30

STANDARD PARTS LIST................................Page 31

TROUBLESHOOTING ...................................Pages 32 - 34

4000 Series

Part No. 13087-0400

Page 4

RIDING LAWNMOWERS, IF IMPROPERLY OPERATED,

CAN CAUSE SERIOUS INJURY OR DEATH

The most common causes of injury to the operator or bystander...

...read and understand this manual to prevent injuries.

SAFETY

BLADE CONTACT

RUN-OVER BACK-OVER

TIP-OVER

Page 5

SAFETY SYMBOLS

Caution

indicates a potentially hazardous situation

which, if not avoided, may result in minor or

moderate injury. It may also be used to alert

against unsafe practices.

SAFETY

Safety Alert Symbol

When you see this symbol,

BE ALERT to the potential for injury.

Follow recommended safety precautions and safe

operating practices.

Danger

indicates an imminently hazardous situation

which, if not avoided, will result in death or

serious injury.

Warning

indicates a potentially hazardous situation

which, if not avoided, could result in death or

serious injury.

Page 6

SAFETY

Thiscuttingmoweriscapableofamputatinghands&feet,andthrowingobjects.

Failuretoobservethefollowingsafetyinstructionscouldresultin

seriousinjuryordeath.

WARNING:The engine exhaust from this product contains chemicals known to the

State of California to cause cancer, birth defects or other reproductive harm.

GENERALOPERATION:

• Read, understand, and follow all instructions in the manual and on the mower before starting.

• Only allow responsible adults, who are familiar with the instructions, to operate the mower.

• Clear the area of objects such as rocks, toys, wire, etc., which could be picked up and thrown by the blade.

• Be sure the area is clear of other people before mowing. Stop mower if anyone enters the area.

• Never carry passengers.

• Do not mow in reverse unless absolutely necessary. Always look down and behind before and while

backing.

• Be aware of the mower discharge direction and do not point it at anyone. Do not operate the mower

without either the entire grass catcher or the deflector in place.

• Slow down before turning.

• Never leave a running mower unattended. Always turn off blades, set parking brake, stop engine, and

remove key before dismounting.

• Turn off blades when not mowing.

• Stop engine before removing grass catcher or unclogging chute.

• Mow only in daylight or good artificial light.

• Do not operate the mower while under the influence of alcohol or drugs.

• Watch for traffic when operating near or crossing roadways.

• Use extra care when loading or unloading the mower into a trailer or truck.

Do not ride the mower when loading & unloading.

• Always wear safety goggles or safty glasses with side shields when operating mower.

• Data indicates that operators, age 60 years and above, are involved in a large percentage of riding mower-

related injuries. These operators should evaluate their ability to operate the riding mower safely enough

to protect themselves and others from serious injury.

• Follow the manufacturer's recommendation for wheel weights or counterweights.

•Maintain or replace safety & instruction labels, as necessary.

Page 7

SLOPE OPERATION:

Slopes are a major factor related to loss-of-control and tip-over accidents,

which can result in severe injury or death.

All slopes require extra caution.

If you cannot back up the slope or if you feel uneasy on it, do not mow it!

SAFETY

Mow across the slope with your Dixon ZTR - never up or down.

Remove obstacles such as rocks, tree limbs, etc.

Watch for holes, ruts or bumps. Uneven terrain could overturn the mower. Tall grass can hide

obstacles.

Useslowspeed. Tiresmaylosetractiononslopeseventhoughthebrakesarefunctioningproperly.

Useextracarewithgrasscatchersorotherattachments. Thesecanchangethestabilityofthemower.

Keep all movement on the slopes slow and gradual. Do not make sudden changes in speed or

direction.

Avoidstartingorstopping onaslope. Iftireslosetraction, disengagethebladesandproceedslowly

down the slope.

If front wheels lift off the ground, pull the levers back to stabilize the mower.

DO NOT

Do not turn on slopes unless necessary, and then, turn slowly and gradually downhill, if possible.

Do not mow near drop-offs, ditches, or embankments. The mower could suddenly turn over if a

wheel is over the edge of a cliff or ditch, or if an edge caves in.

Do not mow on wet grass. Reduced traction could cause sliding.

Do not try to stabilize the mower by putting your foot on the ground.

Do not use grass catcher on steep slopes.

Page 8

Tragic accidents can occur if the operator is not alert to the

presence of children.

Children are attracted to lawn mowers and the mowing activity.

NEVER assume children will stay where they were last seen.

Be alert to avoid accidents.

• Keep children out of the mowing area and under the watchful care of another

responsible adult.

• Be alert and turn mower off if a child enters the area.

• Before and during backing, look behind and DOWN for small children.

• Never carry children. They may fall off and be seriously injured or interfere with

safe mower operation.

• Never allow children to operate the mower.

• Use extra care when approaching blind corners, shrubs, trees, or other objects that

may obscure vision.

SAFETY

CHILDREN:

Page 9

SERVICE: SAFETY

• Use extra care in handling gasoline and other fuels. They are flammable and vapors are explosive.

Use only an approved container.

Never remove gas cap or add fuel with the engine running. Allow engine to cool before refueling.

Do not smoke.

Never refuel the mower indoors.

Never store the mower or fuel container inside a building where there is an open flame,

If fuel is spilled on clothing, change clothing immediatley.

To prevent fire and explosion caused by static electricity:

Never fill containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always

place containers on the ground away from your vehicle before filling.

When practical, remove gas-powered equipment from the truck or trailer and refuel it on the

ground. If this is not possible, then refuel such equipment on a trailer with a portable

container, rather than from a gasoline dispenser nozzle.

If a gasoline dispenser nozzle must be used, keep the nozzle in contact with the rim of the fuel

tank or container opening at all times until fueling is complete. Do not use a nozzle lock-

open device.

• Never run a mower inside a closed area. The exhaust fumes are toxic.

• Keep nuts and bolts tight, especially blade attachment bolts, and keep equipment in good condition.

• Never tamper with safety devices. Check their proper operation regularly.

• Keep mower free of grass, leaves, or other debris buildup. Clean up oil or fuel spillage. Allow mower to

cool before storing.

• Stop and inspect the equipment if you strike an object. Repair, if necessary, before restarting.

• Never make adjustments or repairs with the engine running.

• Grass catcher components are subject to wear, damage, and deterioration, which could expose moving

parts or allow objects to be thrown. Frequently check components and replace with original equipment

parts, when necessary.

• Mower blades are sharp and can cut. Wrap the blade(s) or wear gloves, and use extra caution when

servicing them.

• Batteries contain sulfuric acid. To prevent burns avoid contact with skin, eyes and clothing. To

prevent a fire or explosion keep sparks and open flames away from battery.

• Before disconnecting the negative (-) ground cable, make sure all switches are OFF.

• Check to assure that the drive chains are properly adjusted. A loose chain may come off causing loss of

control.

Page 10

DIXONINDUSTRIES,INC.

aBLOUNTcompany

AIRPORTINDUSTRIALPARK

PO BOX 1569

COFFEYVILLEKS 67337 0945

316 251 2000

FAX 316 251 4117

Blue/Customer Yellow/Dealer White/Dixon Ind.

DIXON LIMITED WARRANTY POLICY - 3000 & 4000 SERIES

WARRANTY: Home Owner Application: This Dixon Warranty term is for a period of two (2) years from date of

purchase. Commercial Application: Dixon mowers used for commercial application are warranted for 30 days from the

date of purchase. Commercial use is specified as use other than, or in addition to, mowing at owner's primary place of

residence.

DIXON ZTR MOWERS ARE WARRANTED AGAINST DEFECTS IN MATERIALS

AND WORKMANSHIP AND PROVIDES FOR REPLACEMENT OR REPAIR OF PARTS INCLUDING

LABOR COSTS. THIS WARRANTY IS SUBJECT TO THE FOLLOWING CONDITIONS

AND LIMITATIONS:

1. Warranty applies only to original retail purchaser of new and unused mowers and accessories.

2. All Dixon warranty must be accomplished by authorized Dixon dealers and in accordance with Dixon

warranty policy and allowances. All warranty claims must be approved by Dixon Industries, Inc.

3. Battery warranty: Limited to 90 days from date of purchase.

4. Accessories Warranty (Grass Catchers, Snow Blades, Covers, etc.): Limited to 90 days from date of purchase.

5 Warranty does not apply to damage in transit or incidents of misuse, negligence, accidents, or alteration. The

use of parts or components other than those supplied by Dixon Industries, Inc. VOIDS ALL WARRANTY.

6. The following items are not covered by this warranty policy:

(a) Pick up and delivery charges for transportation of mower to and from an Authorized Dixon dealer's place

of business.

(b) Transaxle adjustments.

(d) Engines -- All engines used on Dixon ZTR mowers are warranted by each individual engine

manufacturer.

(e) Any costs or expense of providing substitute equipment while repair work is being performed on a

warranted mower.

7. There is no other express warranty. Implied warranties, including those of merchantability and fitness for a

particular purpose, are limited to the same duration of the express warranty, and to the extent permitted by law

any and all implied warranties are excluded. Liabilities for consequential damages under any and all warranties

are excluded.

WARRANTY VALIDATION: At the time of sale, selling dealer must review each portion of this warranty document,

complete the information section below, secure customer's signature and send copy to Dixon Industries, Inc.

DATE OF PURCHASE______________________Model _______________S/N__________________________

Owner'sName

Address

Owner'sSignature

Dealership

Address

Dealer'sSignature
