Table of Contents
DoCash 2015/2015F 2 www.docash.de
1 SAFETY PRECAUTIONS 3
2 DESIGN 5
3 USING THE MACHINE 6
4 DAILY MAINTENANCE 7
5 TRANSPORT AND STORAGE 8
6 COMPLETE SET 8
7 WARRANTY 8
8 TECHNICAL FEATURES 9
1. Safety Precautions
ATTENTION
Please read this manual carefully before you start to operate the
device.
DoCash 2015/2015F 3 www.docash.de
Do not operate the product in areas with high
temperature or high humidity since it may cause
the unit to malfunction.
Do not disassemble this product. Incorrect re-
assembly can cause electric shock. Take it to
qualify personnel if repair is required.
Before turning on the power, please make sure
that there are no objects obstructing the operation
of the rollers and wheels.
Unplug this product from the outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning the cover.
Thank you for choosing DoCash equipment.
DoCash is a wide range of special cash handling equipment
for retail trade and financial organizations. DoCash is a brand for
simple and reliable banknote and coin counters, universal and
automatic currency detectors, vacuum packaging machines,
shredders, etc. You will find any further information at
www.docash.de
Purpose
DoCash 2015/2015F – reliable impulse sealer, which is used to
insure the solid protection from water and air.
Declaration of Conformity
The sealer conforms to the following safety requirements:
General - GOST IEC 60950-1-2011,
Electromagnetic compatibility - GOST R 51318.22-2006.
TR TS 004/2011 «Low-voltage equipment safety»;
TR TS 020/2011 «Electromagnetic compatibility of technical
means».
This manual contains information that is actual for the moment of
publishing, and may not contain the latest changes.
The manufacturer may change machine’s specifications and
control algorithms.
DoCash 2015/2015F 4www.docash.de
2. Design.
DoCash 2015/2015F 5www.docash.de
1 handle 9 teflon cloth 17
cushion 25 cable
2 seal arm 10 cover 18 transformer 26 hanger plate
3 arm spring 11 panel 19 transformer
strip
27 hanger plate
spring
4 arm spring 12 body 20 base 28 micro switch
plate
5 Silica gel 13 cushion 21 base cushion 29 micro switch
6 aluminum bar 14 pillars 22 fuse set 30 teflon cloth
7 bracket 15 hook spring
piece
23 fuse 31 heating ele-
ment
8 bolts 16 brass tab 24 wire buckle 32 teflon cloth
3. Using the machine.
Plug the power cord into AC outlet. If the arm is pressed down,
the machine will start automatically.
Set the timer parameter according to the thickness of the material.
Use a higher number for thick materials.
Pull the handle down. The Light will indicate the beginning of the
sealing process.
After the light goes off - hold the handle for a few more seconds
for better sealing results.
If your seal has burned through - set a lower timer parameter.
If your seal isn’t solid enough - set a higher timer parameter.
Give the machine enough time to cool down for preventing
sticking to the silicon rubber.
DoCash 2015/2015F 6 www.docash.de
Parameter Polyethylene Polypropylene or highly heat-
ed film
1 Under 0.06 m/m
2 Under 0.1 m/m
3 Under 0.14 m/m
4 Under 0.2 m/m Under 0.03 m/m
5 Under 0.44 m/m
6 Under 0.06 m/m
7 Under 0.08 m/m
The timer parameters will not change for the next procedures,
unless the user changes them manually.
After finishing the procedure, lower the handle to shut the machine
down.
4. Daily maintenance.
Keep the platform clean and do not leave anything on Teflon
covers or silicon rubbers before starting to work.
Do not use any liquid chemicals to clean the machine’s parts.
In case of finding any damage on the top or bottom teflon cover -
replace both covers in order to prevent short circuit.
Use only genuine parts and accessories for replacement and
service of the machine.
Replace the silicon element in case of finding any damage in order
to prevent burned sealing.
Unplug the machine before the maintenance.
DoCash 2015/2015F 7www.docash.de
5. Transport and storage
When transporting and storing the sealer follow the symbols on
the package. When transporting the permissible temperature is
from –30°Сto +50°С. Storage of the sealer is allowed at
temperature from +1°Сto +40°Сand relative humidity of up to 80
% (at 25°С), noncondensing.
6. Complete set
DoCash 2015/2015F includes:
Sealer 1.
Heating element 2.
Teflon-impregnated adhesive glass tape 2.
Fuse 2.
User manual 1.
7. Warranty
Guarantee period is 12 months from the delivery date subject to
compliance with the conditions of use and storage indicated in this
Manual and additional conditions specified in the Warranty
Coupon Manufacturer shall be released from any obligation for
the sealer malfunction resulting from improper transportation,
storage and use, as well as from mechanical failure.
Contact the Technical service support department in any case of
malfunction.
DoCash 2015/2015F 8www.docash.de
8. Technical features
Contact the Technical service support department in any case of
malfunction.
DoCash 2015/2015F 9www.docash.de
Welding bar length, mm 300
Weld length (cliche length), mm 300
Bag film thickness, mm 0.06 – 0.18
Power supply, V/Hz 110-220 / 50-60
Power installed, kW 0.4
Weight, kg 4 (DoCash 2015) /
14,6 (DoCash 2015F)
Heating element, mm 8х0.2х320
2015 dimensions, mm 430x100x180
Certification CE, EAC, ROHS approved
2015F dimensions, mm 450x400x860
