2
CONTENTS
1. MANUFACTURER'S DECLARATION OF CONFORMITY ...................... 2
2. GENERAL INFORMATION ............................................ 2
3. SAFETY RULES ................................................... 3
4. SAFETY FEATURES ................................................ 4
5. GENERAL VIEW ................................................... 5
6. PACKAGE ........................................................ 6
7. INSTALLATION .................................................... 6
8. OPERATION ..................................................... 10
9. MAINTENANCE .................................................. 11
10. TROUBLESHOOTING .............................................. 12
11. APPENDIXES .................................................... 13
Appendix 1. Spare parts ........................................... 13
Appendix 2. Hydraulic components for dock leveller series ................ 17
Appendix 3. Pits for dock levellers ................................... 23
1. MANUFACTURER’S DECLARATION OF CONFORMITY
Manufacturer: LLC StoreHan, 143002, Russia, Moskovskaya obl., Odintsovskij r-n, s. Akulovo, ul. Novaya, d. 120
Trademark: DoorHan
Dock levellers serie DS/DSI
fulfil the stipulations of the Machinery Directives
2006/42/EC Machinery, 2006/95/EC Low-voltage, 2004/108/EC Electromagnetic compatibility and harmonized
to the following standarts
EN ISO 12100:2010, EN 1398:2009, EN 60204-1:2006/А1:2009/Cor.Feb.:2010, EN 61000-6-2:2005/Corr.Sep.:2005, EN
61000-6-4:2007/A1:2011
This declaration of conformance is not applied if:
ythe Product is operated in the extreme climatic conditions, in the magnetic action environment etc, and in case of special
requirements, e.g. explosion hazard;
ythe Product is operated for loading/unloading of hazardous substances e.g. acids, radiation-emitting materials, molten
metal, fragile freights;
2. GENERAL INFORMATION
The purpose of this manual is to give information to the operating personnel on correct procedures for installation, operation
and maintenance of telescopic lip dock leveler. The manual contains rules to observe for safe operation and maintenance of the
dock leveller. The manufacturer does not handle the operation, maintenance and placement of the equipment. The operator is
responsible for safe operation and maintenance of the equipment. It is the operator’s responsibility to study this manual prior
to installation. The manufacturer assumes no liability for interpretation of the contents of this manual.
Dock levellers with hinged lip is designed to act as bridge between warehouse and truck body and to enable quick and
unimpeded movement of forklift during loading/unloading.
Only qualified personnel can make installation, operation and maintanace for dock leveller.
We reserve the right to make design modifications without preliminary notice.
LIFTING EQUIPMENT
Fork lift: minimum carrying capacity 35 kN, fork length 2000 mm.
Crane: minimum carrying capacity 20 kN at the given radius.
EQUIPMENT FOR INSTALLATION
Before installation you should have following equipment:
welding machine (5-200 A) or similar;
welding electrodes 3,0 mm.
Control unit
Dock leveller serie DS, DSI compatible with DCUT-1/2/3 control units.
CONTENTS
