Dover IMAJE Jaime 1000 Series Manuale utente
IMAJE SA. reserves the right to alter the specifications and the design of this product at any time without giving prior notice.
Reproduction, in whole or in part, is not allowed.
IMAJE SA. Siège social : 9, rue Gaspard Monge B.P. 110 - 26501 BOURG-LES-VALENCE Cedex - France
: 04 75 75 56 00 - : 04 75 82 98 10 - http://www.imaje.com
Edition Anglaise
Jaime 1000 range
RS232 Link
Parallel Link
A13862
Co n t e n t s
A13862 Version E
General
General principle of a V24 exchange
Protocol
Contents
List of the V24 commands
Appendix
Parallel link
Presentation 7
5
2
3
4
1
Parallel link
Selection of messages 8
6
PRELIMINARY INSTRUCTIONS
Read all these instructions
• FIRE:
CAUTION:
Consult the safety data sheet for the ink to determine whether your printer uses
INFLAMMABLE inks and additives.
If this is the case:
– Place a foam, CO2or powder extinguisher close to the printer (maximum 10 metres).
– The printer must be kept in a well aired place away from sources of heat, flames or
sparks.
– Never leave ink, additive or cleaning solution cans or cloths soaked in ink near the
printer.
– Never smoke near the printer. Display a notice with "NO SMOKING,
INFLAMMABLE INK" close to the printer.
– Make sure to keep the printer very clean, as a dry ink deposit is highly inflammable.
– The ink, additive and cleaning solution cans must be closed and stored in a well
aired room.
• ELECTRICAL CONNECTION:
– The connection to the single phase electricity supply network must use a standard
3 pin plug with earth ; this plug must be easy to access.
– The earth connection must comply with applicable regulations.
• HEALTH:
– It is strictly forbidden to wear contact lenses when handling consumable products.
– It is recommended that ink-resistant gloves and safety goggles should be worm
during filling and cleaning operations.
Disconnect the printer from the mains power supply before any intervention.
IMAJE cannot be in any way held responsible should the above-mentioned rules not be
respected, and in general for the non-respect of elementary safety rules concerning the
utilization of these machines.
All modifications without written authorization from imaje are prohibited and
their possible consequences are the responsability of the person who performed
them.
The same applies for any use of the printer which does not comply with the
printer’s specifications.
A13862 Version E Page 1-1
REVISION
Update to instruction manual "RS232 link - parallel link for the Jaime 1000
range"
• The revision index A0 corresponds to the first edition of this manual.
• The revision index changes with every modifications.
The modified pages are mentioned in the following table. This one indicates all
updating since the first edition.
Date
of edition Document revision
index JAIME 1000
Software index Modified
pages
July 1994
July 1995
Marsh 1999
A0
B
E
D4
D5
D7/A43
Initial edition
All
All
Page 1-2 A13862 Version E
CONTENTS
1 FOREWORD. REVISION. CONTENTS (5 pages)
2 GENERAL (14 pages)
1 Introduction 2-2
2 Description of the signals used 2-3
3 Electricalspecifications 2-4
4 Timing diagram 2-4
5 Material configuration 2-5
6 Softwareconfiguration 2-10
7 Memory aid 2-14
3 GENERAL PRINCIPLE OF A V24 EXCHANGE (3 pages)
1 General principle of a V24 exchange 3-2
4 LIST OF THE V24 COMMANDS (4 pages)
1 Sendings 4-2
2 Requests 4-3
3 List of the V24 commands 4-4
A13862 Version E Page 1-3
CONTENTS
5 PROTOCOL (64 pages)
1 Sendings concerning the printer 5-3
2 Sending concerning the print heads 5-15
3 Sendings concerning messages 5-16
4 Sendings concerning the variable elements
(counter, hour code, auto-dating) 5-26
5 Requests concerning the printer 5-31
6 Requests concerning the heads 5-44
7 Requests concerning the message 5-46
8 Requests concerning the variable elements 5-49
9 General message structures 5-52
10 Detail of the data bytes 5-53
6 APPENDIX (16 pages)
1 Examples of message programming 6-2
2 Commanding the printer by a programme in BASIC 6-9
Performance 6-13
Synoptic of a V24 exchange 6-15
Page 1-4 A13862 Version E
CONTENTS
7 PARALLEL LINK - PRESENTATION (6 pages)
1 Introduction 7-2
2 Characteristics of the Parallel link 7-3
3 Connection diagram 7-4
8 PARALLEL LINK -
SELECTION OF MESSAGES (11 pages)
1 Selection of a message from the library 8-2
2 Input signals diagram 8-4
3 Master jet, master message 8-6
4 General operation of the parallel interface 8-7
5 Restriction of the parallel interface operation 8-7
6 Usage according to printer configurations 8-8
7 Summary charts 8-11
A13862 Version E Page 1-5
GENERAL
(14 pages)
Contents
1 Introduction 2-2
2 Description of the signals used 2-3
2.1 Reference (GND) 2-3
2.2 DSR (Data Set Ready) in voltage levels transmission or
DSR+ and DSR- in loop transmission. 2-3
2.3 DTR (Data Terminal Ready) in voltage levels transmission 2-3
2.4 RTS (Request To Send) 2-3
2.5 CTS (Clear To Send) 2-3
2.6 TXD (Transmit Data) in voltage levels transmission or
TTY OUT+ and TTY OUT- in loop transmission. 2-3
2.7 TXD (Receive Data) in voltage levels transmission or
TTY IN+ and TTY IN- in loop transmission. 2-3
3 Electricalspecifications 2-4
4 Timing diagram 2-4
5 Material configuration 2-5
5.1 Presentation of the terminal block of the Industrial Interface 2-5
5.2 Configuration of the jumpers on the Industrial Interface board 2-6
5.3 Presentation of the different modes 2-7
5.4 Suggested connection diagrams 2-7
5.4.1 Slave. Voltage transmission 2-7
5.4.2 Slave. Loop transmission 2-8
5.4.3 Complete dialogue. Transmission in voltage. 2-9
6 Softwareconfiguration 2-10
6.1 Transmission speed and format on Serie 4 2-10
6.1.1 Programming 2-10
6.1.2 List of speeds and formats available 2-11
6.2 Watchdog on Serie 4 2-12
6.3 Transmission speed, format and watchdog on Serie 4 Plus 2-13
7 Memory aid 2-14
A13862 Version E Page 2-1
1 Introduction
The printers in the Jaime 1000 Series 4 range are equipped with an asynchronous series, half
duplex, interface, for connection to a V24 mode, "Voltage levels" or "20mA loop" transmission
computer.
REMINDER "20mA loop" transmission affords good immunity against electric
and electromagnetic interference. It is therefore particularly
recommendedforlongdistanceconnectionsorin a highly parasitic
area.
ATTENTION A current loop adapter is required when"20 mA current loop"
transmission is used on the S4 Plus printers.
The RS232C (or V24) standard describes the signals available during a dialog between a DTE
(Data Terminal Equipment) and a DCE (Data Communication Equipment).
A maximum of 7 signals only are used for connection to an IMAJE printer of the Jaime 1000,
whether for "voltage level" or "loop" transmission.
NOTE The Jaime 1000 printers should be considered as DTE.
ATTENTION Do not use the keyboard to make any changes to the printer during
a V24 dialogue (risk of conflicts).
You are also recommended to leave the S4 Plus printers in the
"MAIN MENU" during a V24 dialogue.
General
Page 2-2 A13862 Version E
2 Description of the signals used
2.1 Reference (GND)
Computer and printer earth in common.
2.2 DSR (Data Set Ready) in voltage levels transmission or
DSR+ and DSR- in loop transmission.
A printer input. This signal activates the V24 mode.
A symbol appears on the screen when the DSR signal is active
on S4 or on S4 Plus.
2.3 DTR (Data Terminal Ready) in voltage levels transmission
A printer output. The signal is active as soon as the printer is ready to dialog.
2.4 RTS (Request To Send)
A printer output. The signal is active at every character sequence sent by the printer.
2.5 CTS (Clear To Send)
A printer input. The signal instructs the printer to send.
2.6 TXD (Transmit Data) in voltage levels transmission or
TTY OUT+ and TTY OUT- in loop transmission.
A printer output. Data transmission.
2.7 RXD (Receive Data) in voltage levels transmission or
TTY IN+ and TTY IN- in loop transmission.
A printer input. Data reception.
C
General
A13862 Version E Page 2-3
