Drive Bobcat X3 Manuale utente

BOBCAT X SERIES

OWNER’S MANUAL

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

I. PREFACE 3

II. SAFETY NOTICES 4

III. SAFETY GUIDELINES 6

IV. EMI & RFI INFORMATION 13

V. PARTS 14

VI. ASSEMBLY & DISASSEMBLY 16

VII. COMFORT ADJUSTMENTS 23

VIII. OPERATION 25

IX. BATTERIES & CHARGING 26

X. INSPECTION & MAINTENANCE 28

XI. BASIC TROUBLESHOOTING 32

XII. SPECIFICATIONS 33

XIII. LIMITED WARRANTY 34

XIV. ACCESSORIES 36

TABLE OF CONTENTS

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

Please read this Owner’s Manual before operating your scooter for the first time.

Improper use or unfamiliarity of the scooter may result in harm, injury, or traffic

accidents.

This Owner’s Manual includes operation instructions, assembly instructions, and best

practices to ensure maximum use from your scooter.

The symbols used throughout this Owner’s Manual are explained below. Read

carefully, and fully understand the sections marked with these symbols:

WARNING –Improper use could lead to death, serious injury, hazardous

conditions, or product malfunction.

ATTENTION –Improper use could lead to injury and/or damage to your

scooter.

SUGGESTION –Follow these instructions for best practices, and to keep

your scooter in prime operating order.

This Owner’s Manual includes a repair maintenance record chart and warranty. Please

keep it in a safe place, or with the scooter.

If someone else uses the scooter, please provide a copy of the Owner’s Manual for

their consideration.

This Owner’s Manual is composed from the product design and specifications at the

time of publication. As designs change, some illustrations and pictures in the manual

may not correspond to the scooter that you purchased. We reserve the right to make

design modifications.

This product has been designed to provide a comfortable and secure solution for

individuals limited to a seated position who are capable of operating a scooter.

The manufacturer disclaims all responsibilities for any personal injury or property

damage which may occur as a result of improper or unsafe use of this product.

I. PREFACE

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

II. SAFETY NOTICES

Read and follow the information in the owner’s manual.

Fully charge the battery after every trip and prior to using the scooter. If you do not

frequently use the scooter fully charge the batteries every two weeks to prevent

battery failure.

If the battery gauge drops to red, charge the scooter as soon as possible.

Completely discharging the batteries may damage the batteries, or shorten the

expected life of the batteries.

Batteries contain lead and lead compounds. Wear proper safety attire when

handling batteries.

Only use sealed lead acid AGM or gel-cell batteries in this product.

Keep metal objects away from the battery terminals, electric shock may occur.

Always replace both batteries at the same time for optimum performance.

Always make sure the power is turned off when getting in and out of the scooter.

Always make sure freewheel levers are in the drive position before getting in or out

of the scooter.

Do not put the scooter in freewheel when on an incline or decline.

To ensure the user’s familiarity with the scooter’s operation, practice driving at low

speeds in a spacious hazard-free area travelling forward, backward, left, right,

decelerating, maneuvering up inclines, and down inclines.

Avoid unnecessary movement of the scooter.

Never reach, lean or bend when driving your scooter.

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

II. SAFETY NOTICES

Avoid exposure to moisture, standing water, rain, snow, ice or salt when possible.

Store in a clean and dry condition.

Do not drive your scooter at night without proper lighting.

Do not remove the anti-tip wheels.

Keep your feet on the foot board at all times during operation.

Do not stand on the foot board.

Keep your hands and feet away from moving parts while driving.

Be aware of loose fitting clothes that can become caught in the drive wheels.

Do not connect an extension cord to the battery charger.

Disassembling the controller, motor, or charger by anyone other than an

authorized Drive Medical service agent is prohibited, and voids any applicable

warranty.

Do not take your scooter on roads or highways.

Do not operate your scooter when you are tired, or after consuming alcohol.

Be cautious when driving your scooter in busy areas or shopping malls.

Under no circumstances should the scooter be used as a seat in a motor vehicle.

Do not attempt to lift your scooter by any parts other than the frame.

If you will be seated in your scooter for an extended period of time, power off the

scooter. This will prevent inadvertent movement from unexpected throttle contact.

WARNING - The items and packaging in this shipment contain chemicals known to

the state of California to cause cancer, birth defects or other reproductive harm.

Drive Medical products meet or exceed all federal safety and environmental

regulations.

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

GENERAL GUIDELINES

Before operating your scooter fully read and understand this Owner’s Manual.

Be sure to follow the setup instructions prior to using your scooter for the first time.

Users may encounter difficult maneuvering situations such as narrow doorways,

travelling up and down ramps, cornering, and travelling on uneven terrain. Be sure to

lower the speed, take your time, and carefully maneuver the scooter.

MODIFICATIONS

Do not modify, remove, disable, or add any parts, features, or functions on your

scooter. Drive Medical offers a wide variety of accessories for your scooter to help

accommodate your needs.

WARNING –Do not modify your scooter in any way; doing so will void the

warranty.

SAFETY CHECK

ATTENTION –Inspect the following components before each use:

Electrical connections –secure and free from corrosion

Freewheel Levers –engaged in drive position

Batteries –fully charged and free from corrosion

If you notice a problem please contact your authorized Drive Medical Provider for

assistance.

III. SAFETY GUIDELINES

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

WEIGHT CAPACITY

This scooter has a maximum weight capacity that should never be exceeded. Please

refer to Section XII SPECIFICATIONS for this information. The maximum weight

capacity includes the user and any accessories.

WARNING –Exceeding the maximum weight capacity will void your

warranty. Drive Medical will not be held responsible for injuries and/or

damages resulting from failure to observe weight capacities.

WARNING –Do not carry passengers on your scooter. Your scooter is

designed and tested for one user to operate while seated.

INCLINE GUIDELINES

Use caution when approaching inclines or declines; if necessary lower the speed

before travelling on a slope.

When travelling up an incline try to keep the scooter moving forward. If you must

come to a stop, use caution and slowly accelerate the scooter forward.

When travelling down an incline lower the speed on your scooter to the slowest

setting, and proceed cautiously. If the scooter is travelling down the incline faster than

you expected, slowly release the throttle to come to a stop, then slightly push the

throttle forward to continue safely down the incline.

WARNING –Never put the scooter in freewheel model while on an

incline.

WARNING –Drive your scooter straight up or down an incline, never

backwards. Erratic movements, or back and forth patterns may increase

the chance of tipping.

III. SAFETY GUIDELINES

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

WARNING –Do not travel up an incline with the seat completely reclined

without an attendant. Inclines vary, and doing so may decrease stability.

WARNING –Do not, under any circumstances, travel on a slope greater

than the maximum climbing angle for this scooter. Please refer to Section

XII SPECIFICATIONS for this information. Exceeding the climbing angle

may cause unstable conditions.

FREEWHEEL GUIDELINES

Your scooter is equipped with manual freewheel levers to maneuver the unit without

power. The manual freewheel levers can be engaged or disengaged.

Disengaged, or “freewheel” mode, releases the locking mechanism on the gearbox

allowing the scooter to roll freely with or without power.

Engaged, or “drive” mode, secures the locking mechanism on the gearbox preventing

the scooter from rolling freely.

WARNING –Never attempt to personally put your scooter in freewheel

mode while seated in the unit.

WARNING –Never put the scooter in freewheel mode while on an incline.

This may cause uncontrollable movements.

ATTENTION –When your scooter is in freewheel mode you may feel

resistance when maneuvering; this is normal, and prevents damage to the

gearbox.

ATTENTION –Please refer to Section V PARTS to locate the freewheel

levers on your scooter.

SUGGESTION –If you hear a “clicking” noise when engaging the throttle,

but the scooter will not move –turn off the power, engage the freewheel

levers, and power back on to continue.

III. SAFETY GUIDELINES

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

BRAKES & STOPPING

Coming to a stop in your scooter can simply be done by releasing the throttle. The

throttle will automatically return to the center position, and the scooter will come to a

stop.

ATTENTION –Quickly moving the throttle in the opposite direction of

travel will cause the scooter to come to an abrupt stop, and if held

continuously in the opposite direction may cause erratic movements if

you are unfamiliar with the controls.

Your scooter is equipped with two types of brake systems:

Regenerative brakes –when the throttle is returned to the center position, or

stop neutral position, regenerative brakes use electricity to quickly decelerate

the vehicle.

Park brakes –once the scooter comes to a complete stop the park brake

activates automatically locking the drive wheels.

OUTDOOR OPERATION & INCLEMENT WEATHER PRECAUTIONS

While your scooter is purposed for in-home use to assist you in daily living activities;

Drive Medical understands there are times you need to operate the scooter outdoors,

and has designed it to perform superbly on level outdoor surfaces.

ATTENTION –When operating outdoors avoid uneven terrain, soft

surfaces, tall grass, loose gravel, loose sand, fresh water, salt water, edges

of streams, lakes or oceans. If you are unsure about a surface, avoid it.

Exposure to inclement weather should always be avoided. If you find yourself caught

in inclement weather while operating your scooter, proceed to the closest shelter

immediately. Completely dry your scooter before operating, charging, or storing.

III. SAFETY GUIDELINES

REV.1.03.07.14

Bobcat X Owner’s Manual www.drivemedical.com

STEPS, CURBS & FIXED OBSTACLES

Use extreme caution when operating your scooter near curbs, porches, stairs,

escalators, drop-offs, unprotected ledges, and raised areas.

WARNING –Never attempt to navigate your scooter over a fixed obstacle

taller than the maximum ground clearance. Please refer to Section XII

SPECIFICATIONS for this information.

WARNING –Never attempt to navigate your scooter backwards over an

obstacle.

WARNING –Never attempt to operate your scooter on steps or

escalators.

ATTENTION –Refer to the following guidelines and diagrams when

travelling over a fixed obstacle lower than the maximum ground

clearance of your scooter:

To maneuver up a fixed obstacle –Approach slowly, and make sure the front of the

scooter is perpendicular to the obstacle. Increase the forward speed until the scooter

has cleared the obstacle, and then you may reduce the speed or return the throttle to

neutral.

To maneuver down a fixed obstacle –Approach slowly, and make sure the front of the

scooter is perpendicular to the obstacle. Reduce the forward speed just before the

front wheels come in contact with the obstacle, and remain at the reduced speed until

scooter has cleared the obstacle, and then you may increase the forward speed.

CORRECT

APPROACH:

INCORRECT

APPROACH:

III. SAFETY GUIDELINES

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Scooter popolari di altre marche

TEKTRO

TEKTRO CHEETAH Manuale utente

Douglas

Douglas Vespa Sprint Guida all'installazione

PLAYTIVE

PLAYTIVE AS-2448 Manuale utente

Ebinger

Ebinger DONKEY XL Manuale utente

Flyer

Flyer Mountain Guida utente

BackCountry eBikes

BackCountry eBikes Storm Manuale utente

equipmed

equipmed FreeRoam II Manuale utente

Yoto

Yoto Lion Manuale utente

WESTHILL BIKES

WESTHILL BIKES LINK Manuale utente

BAnff

BAnff eProdigy series Manuale utente

Winther

Winther 475 Manuale utente

Jetson

Jetson JBZL17 Manuale utente

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuale utente

Carrera

Carrera impel Manuale utente

Afikim

Afikim Superlight SL-3 Manuale utente

CareCo

CareCo ZOOM Manuale utente

Douglas

Douglas Vespa G.S. Manuale utente

Gazelle

Gazelle with BOSCH System Manuale utente
