Duerkopp Adler 550-767 Manuale utente

550-767

Gestalteter Arbeitsplatz für

Seitenairbag - Sollreißnaht

Engineered work station for

side airbag tearing seam

Bedienanleitung / Operating instructions

Aufstellanleitung / Installation instructions

Postfach 17 03 51, D-33703 Bielefeld Potsdamer Straße 190, D-33719 Bielefeld Sprache: D/ GB

Telefon +49 (0) 5 21/ 9 25-00 Telefax+49(0)521/9252435www.duerkopp-adler.com

Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:

10/2007 Rev. index: 01.0 Printed in Federal Republic of Germany 0791 550034

Eigentum der Dürkopp Adler AG und urheberrechtlich geschützt. Jede, auch auszugsweise

Wiederverwendung dieser Inhalte ist ohne vorheriges schriftliches Einverständnis der Dürkopp Adler AG

verboten.

Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner,

even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited.

Übersicht Summary

Bedienanleitung

Aufstellanleitung

Serviceanleitung (0791 767651)

Bauschaltplan

9890 550004 B

Operating Instructions

Installation Instructions

Service Instructions (0791 767651)

Interconnection-diagram

9890 550004 B

Foreword

This instruction manual is intended to help the user to become familiar

with the machine and take advantage of its application possibilities in

accordance with the recommendations.

The instruction manual contains important information on how to

operate the machine securely, properly and economically. Observation

of the instructions eliminates danger, reduces costs for repair and

down-times, and increases the reliability and life of the machine.

The instruction manual is intended to complement existing national

accident prevention and environment protection regulations.

The instruction manual must always be available at the machine/sewing

unit.

The instruction manual must be read and applied by any person that is

authorized to work on the machine/sewing unit. This means:

–Operation, including equipping, troubleshooting during the work

cycle, removing of fabric waste,

–Service (maintenance, inspection, repair) and/or

–Transport.

The user also has to assure that only authorized personnel work on the

machine.

The user is obliged to check the machine at least once per shift for

apparent damages and to immediatly report any changes (including the

performance in service), which impair the safety.

The user company must ensure that the machine is only operated in

perfect working order.

Never remove or disable any safety devices.

If safety devices need to be removed for equipping, repairing or

maintaining, the safety devices must be remounted directly after

completion of the maintenance and repair work.

Unauthorized modification of the machine rules out liability of the

manufacturer for damage resulting from this.

Observe all safety and danger recommendations on the machine/unit!

The yellow-and-black striped surfaces designate permanend danger

areas, eg danger of squashing, cutting, shearing or collision.

Besides the recommendations in this instruction manual also observe

the general safety and accident prevention regulations!

General safety instructions

The non-observance of the following safety instructions can cause

bodily injuries or damages to the machine.

1. The machine must only be commissioned in full knowledge of the

instruction book and operated by persons with appropriate training.

2. Before putting into service also read the safety rules and

instructions of the motor supplier.

3. The machine must be used only for the purpose intended. Use of

the machine without the safety devices is not permitted. Observe all

the relevant safety regulations.

4. When gauge parts are exchanged (e.g. needle, presser foot, needle

plate, feed dog and bobbin) when threading, when the workplace is

left, and during service work, the machine must be disconnected

from the mains by switching off the master switch or disconnecting

the mains plug.

5. Daily servicing work must be carried out only by appropriately

trained persons.

6. Repairs, conversion and special maintenance work must only be

carried out by technicians or persons with appropriate training.

7. For service or repair work on pneumatic systems, disconnect the

machine from the compressed air supply system (max. 7-10 bar).

Before disconnecting, reduce the pressure of the maintenance unit.

Exceptions to this are only adjustments and functions checks made

by appropriately trained technicians.

8. Work on the electrical equipment must be carried out only by

electricians or appropriately trained persons.

9. Work on parts and systems under electric current is not permitted,

except as specified in regulations DIN VDE 0105.

10. Conversion or changes to the machine must be authorized by us

and made only in adherence to all safety regulations.

11. For repairs, only replacement parts approved by us must be used.

12. Commissioning of the sewing head is prohibited until such time as

the entire sewing unit is found to comply with EC directives.

13. The line cord should be equipped with a country-specific mains

plug. This work must be carried out by appropriately trained

technicians (see paragraph 8).

It is absolutely necessary to respect the safety

instructions marked by these signs.

Danger of bodily injuries !

Please note also the general safety instructions.

Contents Page:

Part 2: Installation Instructions, Class 550-767

1. Items delivered ............................................... 2

2. General and transport packing

2.1 Transportpacking .............................................. 3

2.2 Connecting the control unit (PC)...................................... 3

2.2.1 Checkdateandtime............................................. 3

2.3 Transportwithincustomerpremises ................................... 4

2.4 V-belttension................................................. 4

2.5 Mounting the reel stand ........................................... 5

2.6 Adjustingworkingheight .......................................... 6

2.7 Pedal adjustment ............................................... 6

3. Electrical connection

3.1 Nominalvoltage................................................ 7

3.2 Checkingthedirectionofrotation..................................... 7

3.3 Checkingthepositioning .......................................... 8

3.4 Settingparameters.............................................. 9

4. Pneumatic connection ........................................... 10

5. Lubrication

5.1 Topping up with oil .............................................. 11

5.2 Adjusting hook lubrication.......................................... 11

5.3 Oilingwicksandfelt............................................. 12

6. Sewing test .................................................. 13

1. Items delivered

What items are supplied depends on your order. Before setting-up

please check that all the required components are present.

–Basic equipment

–maintenance unit 1

–Knee switch 2

–sewing lamp

–Additional equipment

–Minor components in the accessory pack

2. General and transport packing

CAUTION:

The sewing unit may only be set up by trained specialist personnel.

2.1 Transport packing

The transport packing must be removed before setting-up.

–Remove the safety straps and battens from the upper part of the

machine, table and frame.

–Remove the safety block and straps from the motor.

2.2 Connecting the control unit (PC)

–Connect plug connector 1.

–Screw on supply lead 2.

2.2.1 Check date and time

Attention:

After switching on the machine, check the system date 3 without fail!

–Check the date and correct it if necessary.

–Check the time (AM or PM) and correct it if necessary.

2.3 Transport within customer premises

For internal transport the sewing machine and the control unit (PC)

must be lifted and moved by a suitable vehicle (e.g. a fork-lift).

All connections between the sewing machine and the control unit

should be undone if appropriate.

2.4 V-belt tension

After the machine has been moved the pre-set V-belt tension must be

checked.

The tension in the V-belt 1 must be such that it can be depressed by

approx. 10 mm by applying finger pressure in the middle.

–Loosen nuts 2 and 3

–Swivel drive until V-belt tension is correct.

–Retighten nuts 2 and 3.

2.5 Mounting the reel stand

The structure and position of the reel stand 3 can be seen in the

illustration.

–Fit reel stand 3 in the hole of the table plate and secure it with

nuts 1 and washers 2 supplied.

–Fit the reel holders and take-up arms. The reel holder and take-up

arm of each reel must be vertically in line.

–If necessary adjust retaining pins 4 to the height of the

needle-thread cone.

Once the attachment 5 has been secured, the needle-thread cone

must press on the switch 6.

312 1

45 4

2.6 Adjusting working height

The working height is adjustable between 685 mm and 1085 mm

(measured to the upper edge of the table plate).

The working height is factory-set to 790 mm.

–Adjust the working height as required by pressing button 1.

2.7 Pedal adjustment The angle of the pedal 3 should be such that the operator can

comfortably move it forwards and backwards.

–Undo screw 2.

–Adjust pedal 3 as required.

–Retighten screw 2.
