DURKOPP ADLER 745-34-2 Manuale utente

Manual, complete

745 - 34 - 2

Sewing unit for runstitching of piped flap

and welt pocket openings and pocket corners

Working methods: A, B, D, F

Operating Instructions

Installation Instructions

Service Instructions

Instructions for Programming DAC

Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld

Telefon + 49 (0) 5 21 / 9 25-00 • Telefax + 49 (0) 5 21 / 9 25 24 35 • www.duerkopp-adler.com

Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:

08/2007 Rev. index: 01.0 Printed in Federal Republic of Germany 0791 745181

745 - 34 - 2

Manual, complete

Contents

Operating Instructions

Installation Instructions

Service Instructions

Instructions for Programming DAC

Interconnection-diagram

9870 745154 B

9890 745002 B

Pneumatic circuit plan

9770 745005

Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in

any manner, even in extracts, without prior written permission of Dürkopp Adler AG, is

prohibited.

Foreword

This instruction manual is intended to help the user to become familiar

with the machine and take advantage of its application possibilities in

accordance with the recommendations.

The instruction manual contains important information on how to

operate the machine securely, properly and economically. Observation

of the instructions eliminates danger, reduces costs for repair and

down-times, and increases the reliability and life of the machine.

The instruction manual is intended to complement existing national

accident prevention and environment protection regulations.

The instruction manual must always be available at the machine/sewing

unit.

The instruction manual must be read and applied by any person that is

authorized to work on the machine/sewing unit. This means:

–Operation, including equipping, troubleshooting during the work

cycle, removing of fabric waste,

–Service (maintenance, inspection, repair) and/or

–Transport.

The user also has to assure that only authorized personnel work on the

machine.

The user is obliged to check the machine at least once per shift for

apparent damages and to immediatly report any changes (including the

performance in service), which impair the safety.

The user company must ensure that the machine is only operated in

perfect working order.

Never remove or disable any safety devices.

If safety devices need to be removed for equipping, repairing or

maintaining, the safety devices must be remounted directly after

completion of the maintenance and repair work.

Unauthorized modification of the machine rules out liability of the

manufacturer for damage resulting from this.

Observe all safety and danger recommendations on the machine/unit!

The yellow-and-black striped surfaces designate permanend danger

areas, eg danger of squashing, cutting, shearing or collision.

Besides the recommendations in this instruction manual also observe

the general safety and accident prevention regulations!

General safety instructions

The non-observance of the following safety instructions can cause

bodily injuries or damages to the machine.

1. The machine must only be commissioned in full knowledge of the

instruction book and operated by persons with appropriate training.

2. Before putting into service also read the safety rules and

instructions of the motor supplier.

3. The machine must be used only for the purpose intended. Use of

the machine without the safety devices is not permitted. Observe all

the relevant safety regulations.

4. When gauge parts are exchanged (e.g. needle, presser foot, needle

plate, feed dog and bobbin) when threading, when the workplace is

left, and during service work, the machine must be disconnected

from the mains by switching off the master switch or disconnecting

the mains plug.

5. Daily servicing work must be carried out only by appropriately

trained persons.

6. Repairs, conversion and special maintenance work must only be

carried out by technicians or persons with appropriate training.

7. For service or repair work on pneumatic systems, disconnect the

machine from the compressed air supply system (max. 7-10 bar).

Before disconnecting, reduce the pressure of the maintenance unit.

Exceptions to this are only adjustments and functions checks made

by appropriately trained technicians.

8. Work on the electrical equipment must be carried out only by

electricians or appropriately trained persons.

9. Work on parts and systems under electric current is not permitted,

except as specified in regulations DIN VDE 0105.

10. Conversion or changes to the machine must be authorized by us

and made only in adherence to all safety regulations.

11. For repairs, only replacement parts approved by us must be used.

12. Commissioning of the sewing head is prohibited until such time as

the entire sewing unit is found to comply with EC directives.

13. The line cord should be equipped with a country-specific mains

plug. This work must be carried out by appropriately trained

technicians (see paragraph 8).

It is absolutely necessary to respect the safety

instructions marked by these signs.

Danger of bodily injuries !

Please note also the general safety instructions.

Index Page:

Part 1: Operating Instructions 745-34-2

(Edition 08/2007)

1. Product Description

1.1 Description of proper use........................................ 5

1.2 Briefdescription............................................. 5

1.3 Technicaldata .............................................. 7

1.4 Optional equipment ........................................... 8

2. Operation

2.1 Swingingthefoldingstationaside................................... 11

2.2 Pushing the covering hood back and removing the fabric sliding sheet ............ 12

2.3 Tilting the machine head up ...................................... 15

2.4 Needles and threads .......................................... 16

2.5 Threading the needle thread...................................... 19

2.6 Winding the hook thread ........................................ 20

2.7 Remainingthreadmonitor....................................... 21

2.8 Changing the bobbins.......................................... 22

2.9 Threadtension.............................................. 24

2.10 Stackingcontrol ............................................. 25

2.11 Slantedpocketcorners......................................... 26

2.11.1 Swingingthecornerknifestationout/in .............................. 27

2.11.2 Setting the corner knives (Manual corner knife station)...................... 28

2.12 Referenceposition-Startingthesewingcycle-Quickstop................... 30

2.13 Flapandpipingprojection....................................... 31

2.14 Piping strip length ............................................ 32

2.15 Working methods............................................. 33

2.15.1 Working method A (Production of trousers) ............................. 34

2.15.2 Sewingwithflap............................................. 37

2.15.2.1 Sewing without light barrier ...................................... 37

2.15.2.2 Sewingwithlightbarrier ........................................ 39

2.15.3 Working method A (Production of jackets)

Piped pockets, manual positioning of piping strip, flaps and other additional parts ..... 40

2.15.4 Working method B

Piped pockets, automatic feed of the piping strip, without/with incision of the

piping ends ................................................ 46

2.15.5 Working method D

Breastweltpockets,automaticfeedandmatchingofthebreastwelt ............. 56

2.15.6 Working method F

Piped pockets, automatic feed of the piping strip,

incision of the piping ends, matching and feed of the flap .................... 62

2.15.7 Foldermonitoring ............................................ 66

2.16 Functions and operation of the optional equipment ........................ 67

2.16.1 Automatic incision device for piping ends .............................. 67

2.16.2 Downholder, pocket bag and waistband clamp ........................... 70

2.16.3 Feeding devices for flaps, pocket bags etc.............................. 71

Index Page:

2.16.4 Throw-overstacker ........................................... 72

2.16.5 Roll-offdevice .............................................. 74

2.16.6 Blow-outdevice ............................................. 75

2.16.7 Bundle clamp and roll-off device ................................... 76

2.16.8 Tapefeedandautomaticcutting.................................... 77

2.16.9 Endless zipper device.......................................... 81

2.16.10 Vacuumdevice.............................................. 82

2.16.11 WorkingmethodBwithsetofparts“Pocketbagonflap” .................... 83

2.16.12 Zipper feeders for method B ...................................... 86

2.16.13 Set of parts “Shaped guide Lining loop triangle” for 745-34-2 methods B and F ....... 87

2.16.14 Smoother for 745-34-2 A and B .................................... 88

3. Maintenance

3.1 Cleaning .................................................. 89

3.2 Weeklylubrication............................................ 92

1. Product description

1.1 Description of proper use

The 745-34-2 is a sewing unit which can properly be used for sewing

light to medium-weight material. Such material is, as a rule, material

made of textile fibres or leather. These materials are used in the

garment industry.

In general only dry material should be sewn on this machine. The

material must not contain any hard objects.

The seam is generally made with core thread, polyester fibre

or cotton threads.

The dimensions for needle and hook threads can be taken from the

table in chapter 2.4.

Before using any other threads it is necessary to estimate the

consequential dangers and to take the respective safety measures, if

required.

This sewing unit must only be installed and operated in dry and

well-kept rooms. If the sewing unit is used in other rooms, which are

not dry and well-kept, further measures to be agreed upon may

become necessary (see EN 60204-31 : 1999).

We, as a manufacturer of industrial sewing machines, assume that at

least semi-skilled operating personnel will be working on our products

so that all usual operations and, where applicable, their risks are

presumed to be known.

1.2 Brief description

The Dürkopp Adler 745-34-2 is a sewing unit for automatic

runstitching of piped, flap and welt pocket openings with rectangular or

slanted pocket corners.

The slanted pocket corners result from the seam offset of the two seam

rows. At the seam beginning and seam end it is possible to sew with

different slants.

Dependent on the working method different feeding devices, corner

knife stations and optional equipment are used.

Machine head

–Twin needle lockstitch version

–Needle bars can be switched separately or together

–Large vertical hooks

–Externally driven center knife, speed and circuit timing

programmable

–Thread trimming device for needle and hook threads

–Needle thread monitor

–Photoelectric remaining thread monitor for the hook threads

–Sewing drive as DC direct drive

Step motors for the material feed and the length adjustment of the

corner cutting device

The step motor technology results in short machine times and

guarantees an absolutely precise corner incision.

Thus, it contributes to a pocket quality as yet unequalled and combined

with high productivity.

New generation of “DAC III” controls (DÜRKOPP ADLER Control)

The graphic user guidance exclusively occurs via internationally

comprehensible symbols and text lines in the corresponding language.

The various symbols are combined in groups within the menu structure

of the sewing and test programs.

The ease of use makes short training times possible.

The user can combine 99 freely programmable pocket programs with

up to 20 seam patterns.

20 pocket sequences can be called up.

Every pocket sequence can be combined of up to 8 pocket programs in

any order whatever.

All slants suitable for practical application can be programmed by the

operator at the touch of a button.

The time-consuming adjustment of the corner knives and the tiresome

programming of seam offsets are not required.

The comprehensive test and monitoring system MULTITEST is

integrated in the DAC.

A microcomputer does the control tasks, monitors the sewing cycle and

signals operating faults and malfunctions on the display.

Optional equipment

By means of a flexible system of optional equipment the sewing unit

can be equipped optimally and economically corresponding to the

respective application.

See chapter 1.4 (Equipment of the 745-34-2).

Sewing equipment and folders

Data concerning the sewing equipment and folders for the various

applications can be taken from the Equipment Sheets of cl. 745-34-2.

Please direct your enquiries to the DÜRKOPP-ADLER sales offices.

1.3 Technical data

Machine head: Class 0246 992002

Needle system: 2134-85

Needle distance: 10, 12, 14, 16, 20, 24, 26, 30 mm

Needle size: Nm 80 to Nm110

Threads: see table chapter 2.4

Stitch type: Twin needle lockstitch

Speed: min. 2000 rpm

max. 3000 rpm

Stitch length: min. 2.0 to 3.0 mm

Number of stitches/condensed

stitches: 1 - 10 stitches

Number of stitches/bartack

stitch: 0 - 5 stitches

Stitch length condensed

stitches / bartack: 0.5 - 3.0 mm

Pocket length: max. 220 mm

Seam offset: max. +/- 13 mm

Operating pressure: 6 bar

Air consumption: approx. 6 NL per work cycle

Rated voltage: 3 x 230 / 400 V / 50/60 Hz

Rated load:

Machine with

vacuum blower 0,8 KW

Machine without

vacuum blower 0,5 KW

Dimensions: 1540 x 925 x 1200 mm (L x W x H)

Working height: 790...1100 mm

(upper edge of table top)

Weight: 280 kg

Rated noise level: LC = 81 dB (A)

Workstation-specific emission value

according to DIN 45635-48-B-1

Stitch length: 2.5 mm

Seam length: 180 mm

Speed: 2750 rpm

Material: double fabric

240 g/m2

Measuring point according to DIN

4895 Part 1

X = 600 mm Y = 0 mm Z = 300 mm

1.4 Optional equipment

Order No. Optional equipment A B D F

0745 597514 Downholder- pocket bag clamp

Downholder for smoothing the fullness

caused by darts as well as a

clamping device for pocket bags

0745 597524 Waistband clamp

For smoothing the fullness.

Only possible in conjunction with 0745 597514

0745 597544 Endless zipper

Scissors with roll-off device for endless zippers

without slider

0745 597554 Throw-over stacker

To be positioned near the machine for stacking to the

side or to the back.

Furthermore, this throw-over stacker is equipped with

an easy-to-operate height adjustment and

a swivel device.

XXXX

0745 597604 Blow-out device

For blowing the finished workpieces out XX

0745 597614 Shaped guide “Lining loop triangle”

In case of inside pockets the lining loop triangle

is fed automatically.

0745 597674 Table extension (large)

The table extension required for the working method

with bundle clamp carriage

0745 597684 Table extension (small)

Tableextensiontobeusedforstackingtotheside XXXX

0745 597694 Bundle clamp

This includes the required large table extension XX

0745 597764 Right zipper feeder

In conjunction with feeding device 0745 517574

For cut-to-length zippers,

without slider, total width 24 mm, chain width

approx. 4 mm, in case of ready-made pocket chain

inside.

0745 597774 Left zipper feeder

In conjunction with feeding device 0745 517564

For cut-to-length zippers,

without slider, total width 24 mm, chain width

approx. 4 mm, in case of ready-made pocket chain

inside.

0745 597784 Right zipper feeder

In conjunction with feeding device 0745 517574

For cut-to-length zippers,

without slider, total width 24 mm, chain width

approx. 4 mm, in case of ready-made pocket chain

inside.

0745 597794 Left zipper feeder

In conjunction with feeding device 0745 517564

For cut-to-length zippers,

without slider, total width 24 mm, chain width

approx. 4 mm, in case of ready-made pockets chain

inside.

Altri manuali per 745-34-2

Indice

Altri manuali DURKOPP ADLER Macchina da cucire

DURKOPP ADLER

DURKOPP ADLER DAC BASIC - CLASS 271 PART II V 12-2010 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 768 Manuale operativo

DURKOPP ADLER

DURKOPP ADLER 888 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 991-210-10 Series Istruzioni operative

DURKOPP ADLER

DURKOPP ADLER 745-34-2 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 275 Series Manuale utente

DURKOPP ADLER

DURKOPP ADLER M-Type Delta D867 Manuale operativo

DURKOPP ADLER

DURKOPP ADLER 171 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 911-210 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 867 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 550-12-33 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 504 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 697 Guida

DURKOPP ADLER

DURKOPP ADLER 867-M Premium Manuale utente

DURKOPP ADLER

DURKOPP ADLER DAC BASIC - CLASS 271 PART II V 12-2010 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 967 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 745-34-2 Manuale di installazione

DURKOPP ADLER

DURKOPP ADLER 667 PREMIUM Istruzioni operative

DURKOPP ADLER

DURKOPP ADLER 767 - Istruzioni operative

DURKOPP ADLER

DURKOPP ADLER 868 Manuale utente

DURKOPP ADLER

DURKOPP ADLER 396 Manuale

DURKOPP ADLER

DURKOPP ADLER 969 PURE Manuale utente

DURKOPP ADLER

DURKOPP ADLER 559 - Manuale utente

DURKOPP ADLER

DURKOPP ADLER M-Type Delta D867 Manuale utente

Manuali Macchina da cucire popolari di altre marche

Riccar

Riccar RL634DE Manuale utente

Singer

Singer 2517 Manuale utente

Pfaff

Pfaff 3307-1 SERIES Manuale utente

Janome

Janome Quilt Maker Pro 18 VERSA Manuale utente

Siruba

Siruba C007JP Manuale utente

Husqvarna Viking

Husqvarna Viking Designer SE Manuale utente

Singer

Singer 148-5 Manuale utente

IKEA

IKEA SY Manuale utente

Pfaff

Pfaff 571 Manuale utente

Singer

Singer 15-91 Manuale utente

Brother

Brother BB370 Manuale utente

Pegasus

Pegasus WT100 Series Manuale utente

Reliable

Reliable 7100DB Manuale utente

Pfaff

Pfaff 937 Manuale utente

Singer

Singer 6038 Manuale utente

Singer

Singer 413K Manuale utente

Pfaff

Pfaff 1471 E1 Manuale utente

Kenmore

Kenmore 16677 - Serger Sewing Machine Manuale utente
