Eaglemaster E5 Manuale utente

IMPORTANT:

Please read the entire manual for complete details on the features, accessories and

operation before attempting to use your security system.

This Security system must be installed by a qualified technician to ensure proper

operation. Do not attempt to install or modify this system yourself as

this way void your warranty.

2-WAY CAR ALARM SYSTEM

Instruction manual

Table of contents

About your system

System maintenance

Remote battery replacement

LCD 2-way configuration

1-way remote description

2-way & 1-wayremote function table

Standard LCD 2-wayicon instructions

Standard features

ToARM the system

Defective Zone Bypass& Alert

Auto Reset

Arm without sirenchirp

ToDISARM the system

Programming 2-way remote

Disable remote receiving

Remote button 1.2.3on/off

Vibrate mode on/off

Time adjust mode

Alarm clock setting

2-way signal pagingfeatures

Command Page

Alarm Page

Page Recognition (Acknowledgement)

Check-in range notification(on/off )

Reminder disarm status(Programmable)

Vehicle statuschecking

Turn on LCD display backlight

Intrusion Alert

2-way LCD IntrusionAlert

Disarm without sirenchirp

Silent arm mode

Automatic REARM (programmable)

Passive arm (programmable)

Panic mode

Dual stage shocksensor

Remote sensor bypass

Car search mode

Confort /window close

Valet mode

Ignition controlled doorlock/unlock(programmable)

Ch-4: 2nd stagedoor unlock (programmable)

Ch-4: Remote latched(programmable)

Passive immobilizer (programmable)

Arming without Remotecontrol (programmable)

2-1.

7-1.

7-2.

7-3.

7-4.

7-5.

8-1.

8-2.

8-3.

8-4.

8-5.

8-6.

8-7.

9-1.

9-2.

9-3.

9-4.

9-5.

9-6.

9-7.

9-8.

9-9.

9-10.

9-11.

9-12.

9-13.

9-14.

9-15.

9-16.

9-17.

9-18.

9-19.

9-20.

9-21.

9-22.

-1-

Page

2nd step disarm

Remote trunk open

CH-5: Dome lightsupervision

CH-5: ArmW/Engine running

CH-5:Turbo mode

CH-6: Programmable output

CH-7: Programmable output

Red/black programme (+)input

- Reverse warning

- Heard lightwarning

- Extra sensor(knock sensor) input

Siren chirps ON/OFF(programmable)

Status LED timer

Power disconnecting memory

Emergency reset switch

Emergency disarm (Valet SW &PIN code)

Anti car-jacking mode

R.f antenna callswitch

Set your ownPIN code

Programme mode features

Wiring diagram

Programme mode table

Transmitter programming

System installation

Central door lockwiring

9-23.

9-24.

9-25.

9-26.

9-27.

9-28.

9-29.

9-30.

9-31.

9-32.

9-33.

9-34.

9-35

9-36.

9-37.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

-2-

About Your System

NOTE:

Congratulations on yourpurchase of this state-of-the-art vehicle security system.

With proper installationthis system will provide superior protection and performance for

many years tocome.

What is included:

Acontrol module

2-way pager transceiverantenna

One 5-button 2-wayLCD remote transmitter

One 3-button or4-button random code remote transmitter

Dual stage shocksensor

High output 6-tonesiren (optional)

Status LED indicator

Valet over-rideswitch

Options and Accessories:

This system includesseveral optional inputsand outputs allowing the creation ofa

completely personalized securityand convenience system by offering manyoptional

features such as:

2nd stage doorunlock

Horn honk output

2pulse signal doorunlock

Engine turbo timemode

Check range notification

Arm/disarm chirpon/off

*Many require additionalparts and/or labor, see storefor details

Some of thefeatures described in this manual mayrequired additional parts and/or

labor, andmay not be included as partof the standardinstallation of thisunit.

Additionally, manyfeatures of thissecurity system have selectable options thatmust be

activated or programmedduring the system's installation. These itemswill be identified

in the followingsections. Please discuss these features andany questions you may

regarding the installationof this product with your authorizeddealer.

Window close control

Anti car-jack bydoor switch

Power trunk/hatch release

Glass breakage sensor

Micro-wave detector

Back-up battery sirem

-3-

System maintenance

The system requiresno specific maintenance other than batteryreplacement for the remotes.

LCD 2-Way Remote Battery Replacement

The 2-way remoteis powered by a 1.5VAAA battery. The BatteryLevel indicator hasthree level

indicators that serveas a visual indication of batterycharge. When thebattery reaches a low

charge level thatrequires replacement, the transceiver will generatea single notificationchirp,

and the BatteryLevel indicator will flash continuously.

Toreplace the battery, gently pull the battery coverrelease tab, thenslide the door down to

expose the batteryand remove the expired battery.Place the new battery into the transceiver

observing the correctpolarity. Whenpower is returnedthe transceiver will light all iconsin the

LCD and generateall beeper tones once.

3 & 4-ButtonRemote Battery Replacement

Your remote is poweredby a 12V A27 thatwill last approximatelyone year under normal use.

When the batterybegins to weaken, operating range willbe reduced andthe LED on the remote

will dim.

FULL REPLACE EMPTY

LCD 2-Way configuration

-4-

Button 1 Button 2

Button 3

Button 4

Button 5

LCD display

Antenna

TR-45

CALL

AHJ

IMMO

PASS

BRAKE

2-way & 1-way Remote Function Table:

Functions Step Condition

Arm and door lock

Arm without siren chirp

Disarm and door unlock

Disarm without siren chirp

Trunk open

Anti car-jack mode

Panic mode

Car search mode

1st stage sensor bypass

2nd stage sensor bypass

Valet mode

Status check & Back light

Remote button 1.2.3 on/off

Silent arm mode

Enable check-in range

Vibrate mode on/off

Disable remote receiving

Time adjust mode

Alarm clock setup

Press once

Press once then within 3sec. press once

Press once

Press once then within 3sec. press once

Press over 2sec

Press together over 2sec..

Press over 2sec.

Press once after 8sec. of armed

Press once within 8sec. of armed

Press together over 2sec.

Press once

Press over 2sec.

Press once. & Press 1-way once.

Press once within 8sec. of armed.

Press over 2sec.

Press together over 2sec.

Press together over 3sec.

Disarmed & ACC off

Armed

Any time

ACC ON

Armed

ACC ON

Disarmed

Armed

1-Way Remote Transmitter Description (optional 3 & 4 button available)

Button 1 (Arm / Door lock)

LED indicator

Button 2 (Disarm / Door unlock)

Button 3 (Trunk open)

Button 4 (Silent arm mode)

TX-4R

NO:

-5-

Standard LCD 2-way icon instructions

Remote transmitting asignal.

System Armed.

Passive arming &

Auto re-arming mode.

Panic mode.

Check-in range turnON status.

System Disarmed.

1st-stage sensor bypass.

Door open whenarmed.

Weak signal notification.

Silent Armed.

2nd-stage sensor bypass.

Trunk open when armed.

-6-

PASS

AHJ

IMMO

Hood open whenarmed.

Door switch triggered.

Ignition switch triggered.

Valet mode.

1st stage sensortriggered.

Trunk switch triggered.

Passive immobilizer mode.

Arm W/engine runningmode.

2nd stage sensortriggered.

Hood switch triggered.

Anti car-jacking mode.

Turbo mode.

-7-

-8-

CALL

Call / pagemode.

2way time display.

Hand brake indication.

(Optional for startermodel)

2way receiving OFFmode. 2way button OFFmode.

Alarm clock.

2way battery levelindication.

2way Vibration mode.

Extra sensor triggered.

(Knock sensor) optional

BRAKE

Disable remote receiving

You may turn offthe 2-Way remote receiving signal from the mainunit. Press button

simultaneously for 2sec.until one long beep is heard.Remote receiving is now

disabled. To turn on receiving again, Pressbutton simultaneously untiltwo long

beep is heard,remote receiving is now enable.

2way remote button ON/OFF

For safety purpose,this 2-way remotecan be lockout the remote buttonin order notto

mis-touched the buttons.Press button forover 2sec. until one beep is heard, remote

button is nowlocked. To turn onremote button, pressbutton for over2sec. until two

beeps is heard,remote button isnow unlocked.

Programming 2-way remote

2-way LCD display:

If set withvibration only

the 2-way LCDwill display :

-9-

Vibrate mode on/off

Press button for over 2sec. the2-way remote will respond tone & vibrate feature,

the button pressing 2sec. will changethe feature, see under table:

Beeps 2-way remote feature

Vibrations

1-beep

1-time

Remote with toneand vibration

Remote with vibrationonly

Remote with toneonly
