ECS ECS G24 Manuale utente

Preface

This publication, including all photographs, illustrations and software, is protected

any of the material contained herein, may be reproduced without written consent of

the author.

Version 1.0

Disclaimer

The information in this document is subject to change without notice. The manufac-

turer makes no representations or warranties with respect to the contents hereof and

specifically disclaims any implied warranties of merchantability or fitness for any

particular purpose. The manufacturer reserves the right to revise this publication and

to make changes from time to time in the content hereof without obligation of the

manufacturer to notify any person of such revision or changes.

FCC

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful inter-

ference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment onto an outlet on a circuit different from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Shielded interconnect cables and a shielded AC power cable must be employed with

this equipment to ensure compliance with the pertinent RF emission limits govern-

ing this device. Changes or modifications not expressly approved by the system’s

manufacturer could void the user’s authority to operate the equipment.

Trademark Recognition

Windows®7/8 are registered trademarks of Microsoft Corp.

Other product names used in this manual are the properties of their respective

owners and are acknowledged.

Preface

Canadian Department of Communications

This class B digital apparatus meets all requirements of the Canadian Interference-

causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur

le matériel brouilieur du Canada.

Declaration of Conformity

This device complies with part 15 of the FCC rules. Operation is subject to the

following conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interfer-

ence that may cause undesired operation

This product has been tested and found to comply with the limits of the European

Council Directive on the approximation of the laws of the member states relating to

electromagnetic compatibility according to 2004/108/EC.

Preface

iii

Safety Instructions

Your system is designed and tested to meet the latest standards of safety for informa-

tion technology equipment. However, to ensure your safety, it is important that you

read the following safety instructions.

Setting up your system

• Read and follow all instructions in the documentation before you oper-

ate your system.

• Do not use this product near water or a heated source such as a

radiator.

• Set up the system on a stable surface.

• Openings on the chassis are for ventilation. Do not block or cover these

openings. Make sure you leave plenty of space around the system for

ventilation. Never insert objects of any kind into the ventilation open-

ings.

• Use this product in environments with ambient temperatures between

0°C and 40°C.

• If you use an extension cord, make sure that the total ampere rating of

the devices plugged into the extension cord does not exceed its am-

pere rating.

Attention during use

• Do not step on the power cord or let anything rest on top of it.

• Do not spill water or any other liquid on your system.

• When the system is turned OFF, a small amount of electrical currentstill

flows. Always unplug all power, modem, and network cables from the

power outlets before cleaning the system.

• If you encounter the following technical problems with the product,

unplug the power cord and contact a qualified service technician or

your retailer.

• The power cord or plug is damaged.

• Liquid has been spilled into the system.

• The system does not function properly even if you follow the

operating instructions.

• The system was dropped or the cabinet is damaged.

• The system performance changes

The warranty does not apply to products that have been disassembled by

users.

Preface

Safety cautions and warnings

Optical Drive Safety Information

CAUTION:

Invisible laser radiation when open. Do not stare into beam or view

directly with optical instructions.

WARNING:

Makeing adjustments or performing procedures other than those speci-

fied in the user’s manual may result in hazardous laser exposuer. Do

not attempt to disassemble the optical drive. For your safety, have the

optical drive serviced only by an authorized service provider.

Optical drive sold with this system contains a CLASS 1 LASER PRODUCT.

Product disposal notice

INPORTANT:

This symbol if the crossed out wheeled bin indicates that the product

(electrical and electronic equipment) should not be placed in munici-

pal waste. Check local regulations for disposal of electronic products.

Nordic Lithium Cautions (for lithium-ion batteries)

CAUTION:

Danger of explosoin if battery is incorrectly replace only with the same

or equivalent type recommended by the manufacturer. Dispose of used

batteries according to the manufacturer’s instructions.

Product disposal notice

1. Do not place this product underneath heavy loads or in an unstable

position.

2. Do not use or expose this product around magnetic fields as mag-

netic interference may affect the performance of the product.

3. Do not expose this product to high levels of direct sunlight, high-

humidity or wet conditions.

4. Do not block the air vents to this product or impede the airflow in

any way.

TABLE OF CONTENTSABLE OF CONTENTS

ABLE OF CONTENTSABLE OF CONTENTS

ABLE OF CONTENTS

Preface i

Chapter 1 1

Introducing the PC 1

Introduction......................................................................................1

1.1 Specfications...............................................................................1

1.2 Front view....................................................................................2

1.3 Left and right view of the computer.........................................3

1.4 Back view.....................................................................................5

1.5 VESA Mount Installation..........................................................6

1.6 Connecting your computer.......................................................7

1.7 Optional-Remote controller.......................................................9

Packing Contents............................................................................13

Chapter 2 1515

1515

Trouble Shooting 15

Start up problems during assembly............................................15

Solving Problems.........................................................................15

Display Problems............................................................................15

TroubleshootingAudio Problems...................................................16

Troubleshooting Remote Controller Problems...............................17

Maintenance and care tips.................................................................17

Panel clean tips.............................................................................17

Memo

IntroducingthePC

Chapter1

IntroducingthePC

Introduction

Thank you for choosing G24 which has great performance with stylish and flexible

design. The G24 will give you an exciting PC experience by allowing you to choose

your own favorite motherboard to install in.

1.1Specifications

• CPU support up to 77W

Processor

• Power, Brightness Up/Down, Display On/Off (depends

on motherboard support)

Button

• Support 2 x SO-DIMM DDR3

• Built-in up to 1.3M pixel webcam/MIC

• 2 x USB 2.0 ports

• 2 x Audio jacks (Headphone out, MIC-IN)

• 1 x Multi card reader (SD/MMC/MS)

• Wireless module

• TV kit (IR receiver, antenna and remote controller)

Memory (L6

w/ motherboard)

Webcam

I/O (Side)

Option

• 19v, DC-In adapter (The required wattage depends on

motherboard specification.)

Power

Display Panel • 23.6” wide screen 16:9 HD LED Panel

(panel voltage 5v, backlight converter voltage 19v)

Max resolution 1920 x 1080

• Optional Panel:

Non-touch panel

• Support 1 x 3.5” HDD or 2 x 2.5” HDD

• Support 1 x SATA II Slim DVD Super-multi tray type or

1 x External 2.5” HDD

Drive Bays

• 675(W) x 580(H) x 275(D) mm

• Net Weight: 13Kg

• Gross Weight: 15Kg

Dimension

• Thin Mini-ITX form factor

Form Factor

Multi-touch panel

IntroducingthePC

Webcam/WebcamLEDLight

The built-in webcam with the microphone can be used for picture taking, video

recording, online conference and any other interactive applications. Webcam

LED light is on when webcam is activated.

Built-in Microphone

The built-in microphone can be used for online video chatting.

LCD/LED Display

The 23.6-inch TFT LCD/LED display is with an optimal resolution of 1920X 1080.

Speakers

The built-in stereo speakers deliver high quality sound blaster with stereo system

and Hi-Fi function supported.

1.2Frontview

Note:

ID design may vary.

WARNING:

Do not thrust the speaker with your fingers or sharp-pointed things such as

pens.

IntroducingthePC

1. Brightness Up

2. Brightness Down

3. Display On/Off (Depend on motherboard support)

4. Power Button

5. USB Ports

6. Headphone Jack

7. Microphone Jack

1.3Leftandrightviewofthecomputer

1.Brightness Up

Press this button to turn up the brightness of screen.

2.Brightness Down

Press this button to turn down the brightness of screen.

3.Display On/Off (Depend on motherboard support)

Press the auto button to switch video input or monitor display.

4.Power Button

Press the power button to turn the system on and off. The power LED is on

when you turn on the system; the power LED is off when you turn off the

system.

5. USB Ports

The USB (Universal Serial Bus) ports are provided for attaching USB devices

such as mouse, keyboard, printer, scanner, camera, PDAor other USB compatible

devices.

IntroducingthePC

8. External HDD Box or Optical Drive

To switch the external HDD box with optical drive (vice versa), press the eject

button to pull out the external HDD or optical drive. For optical drive device, the

LED is on when CD/DVD is read from or written to the optical drive.

9. Multi Card Reader

The built-in card reader may support various types of memory card, such as XD

(eXtreme Digital), SD (Secure Digital), SDHC (SD High Capacity), MS (Memory

Stick), MS Pro (Memory Stick Pro) or MMC (Multi-Media Card) cards that usually

used in devices like digital cameras, MP3 players, mobile phones and PDAs.

Contact the local dealer for further information and please be noted that the

supported memory cards may vary without notice.

8. External HDD Box or Optical drive

9. Multi Card Reader

6. Headphone Jack (Green)

This is a jack for headphone.

7. Microphone Jack (Pink)

This is a jack for microphone.

WARNING:

Push to remove the device. Please don’t push while data is in

processing.

Altri manuali per ECS G24

Indice

Manuali Scrivania popolari di altre marche

HP m9060n - Pavilion - Elite Scheda tecnica

Asus

Asus E210 Series Manuale utente

Dell

Dell Inspiron 600m Manuale utente

Dell

Dell Inspiron 3662 Manuale utente

TotalFlow

TotalFlow uFLO Manuale utente

HP Presario SV7000 - Desktop PC Manuale utente

HP ProDesk 400 G5 Manuale

Logitech

Logitech MK320 Manuale utente

Dell

Dell XPS 730 H2C Manuale utente

Sony

Sony Vaio Series Manuale utente

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuale utente

Alto

Alto MD 250 Manuale utente

Lenovo

Lenovo ThinkCentre Edge 72 Manuale

Lenovo

Lenovo ThinkStation D20 Manuale

Arbor Technology

Arbor Technology FPC-7800 Series Manuale utente

Sony

Sony VAIO VGX-TP1 Series Manuale utente

Asus

Asus Eee Box B204 Manuale utente

Dell

Dell Optiplex 9010 All In One Manuale utente
