ECS SF100 Manuale utente
Preface
i
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected
under international copyright laws, with all rights reserved. Neither this manual, nor
any of the material contained herein, may be reproduced without written consent of
the author.
Version 1.0
Disclaimer
The information in this document is subject to change without notice. The
manufacturer makes no representations or warranties with respect to the contents
hereof and specifically disclaims any implied warranties of merchantability or fitness
for any particular purpose. The manufacturer reserves the right to revise this
publication and to make changes from time to time in the content hereof without
obligation of the manufacturer to notify any person of such revision or changes.
FederalCommunicationsCommission(FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits govern-
ing this device. Changes or modifications not expressly approved by the system’s
manufacturer could void the user’s authority to operate the equipment.
TrademarkRecognition
Windows®7/8/10 are registered trademarks of Microsoft Corp.
Other product names used in this manual are the properties of their respective
owners and are acknowledged.
ii
Preface
CanadianDepartmentofCommunications
This class B digital apparatus meets all requirements of the Canadian Interference-
causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur
le matériel brouilieur du Canada.
DeclarationofConformity
This device complies with part 15 of the FCC rules. Operation is subject to the
following conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interfer-
ence that may cause undesired operation
Preface
iii
SafetyInstructions
Your system is designed and tested to meet the latest standards of safety for informa-
tion technology equipment. However, to ensure your safety, it is important that you
read the following safety instructions.
Settingupyour system
• Read and follow all instructions in the documentation before you oper-
ate your system.
• Do not use this product near water or a heated source such as a
radiator.
• Set up the system on a stable surface.
• Openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for
ventilation. Never insert objects of any kind into the ventilation open-
ings.
• Use this product in environments with ambient temperatures between
0°C and 40°C.
• If you use an extension cord, make sure that the total ampere rating of
the devices plugged into the extension cord does not exceed its am-
pere rating.
Attentionduringuse
• Do not step on the power cord or let anything rest on top of it.
• Do not spill water or any other liquid on your system.
• When the system is turned OFF, a small amount of electrical currentstill
flows. Always unplug all power, modem, and network cables from the
power outlets before cleaning the system.
• If you encounter the following technical problems with the product,
unplug the power cord and contact a qualified service technician or
your retailer.
• The power cord or plug is damaged.
• Liquid has been spilled into the system.
• The system does not function properly even if you follow the
operating instructions.
• The system was dropped or the cabinet is damaged.
• The system performance changes
The warranty does not apply to products that have been disassembled by
users
iv
Preface
Safetycautionsandwarnings
Optical Drive Safety Information
CAUTION:
Invisible laser radiation when open. Do not stare into beam or view
directly with optical instructions.
WARNING:
Makeing adjustments or performing procedures other than those speci-
fied in the user’s manual may result in hazardous laser exposuer. Do
not attempt to disassemble the optical drive. For your safety, have the
optical drive serviced only by an authorized service provider.
Optical drive sold with this system contains a CLASS 1 LASER PRODUCT.
Product disposal notice
INPORTANT:
This symbol if the crossed out wheeled bin indicates that the product
(electrical and electronic equipment) should not be placed in munici-
pal waste. Check local regulations for disposal of electronic products.
Nordic Lithium Cautions (for lithium-ion batteries)
CAUTION:
Danger of explosoin if battery is incorrectly replace only with the same
or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
Product disposal notice
1. Do not place this product underneath heavy loads or in an unstable
position.
2. Do not use or expose this product around magnetic fields as mag-
netic interference may affect the performance of the product.
3. Do not expose this product to high levels of direct sunlight, high-
humidity or wet conditions.
4. Do not block the air vents to this product or impede the airflow in
any way.
v
TT
TT
TABLE OF CONTENTSABLE OF CONTENTS
ABLE OF CONTENTSABLE OF CONTENTS
ABLE OF CONTENTS
Preface i
Chapter 1 1
IntroducingthePC 1
Introduction......................................................................................1
Specification......................................................................................2
FrontandRearI/O............................................................................3
PackingContents..............................................................................5
Chapter 3 9
UsingBIOS 9
Aboutthe SetupUtility..................................................................9
The Standard Configuration................................................9
Entering the Setup Utility......................................................9
Resetting the Default CMOS Values...................................10
UsingBIOS......................................................................................10
BIOS Navigation Keys.......................................................11
Main Menu ........................................................................12
Advanced Menu.................................................................13
Chipset Menu.....................................................................24
Tweak Menu.......................................................................27
Security Menu....................................................................28
Boot Menu..........................................................................29
Exit Menu...........................................................................30
Updating the BIOS.............................................................31
Chapter 2 77
77
7
SystemQuickInstalltion..................................................................7
Installing thePC 7
Chapter 4 3333
3333
33
UsingtheSoftware 33
AbouttheSoftwareDVD-ROM/CD-ROM..................................33
Auto-installingunderWindows7/8/10........................................33
Running Setup....................................................................34
ManualInstallation.........................................................................36
UtilitySoftwareReference.............................................................36
vi
Chapter5 3737
3737
37
TroubleShooting 37
Startup problemsduringassembly...............................................37
Startupproblemsafterprolonguse............................................38
Maintenanceand care tips............................................................38
BasicTroubleshooting Flowchart................................................39
1
IntroducingthePC
Chapter1
IntroducingthePC
Introduction
Thank you for choosing 1L SF100 of great performance and with stylish and flexible
design.
Supports LGA1151 Socket for Intel®Skylake processor and a dimension of 173mm
(H)* 176mm (D)* 33mm (W), 1L SFF provides the features of low power
consumption (working with a 90Watt power adaptor), and space saving. The chipset
is Intel®Q170, supporting up to 32 GB of system memory with DDR4 memory
SO-DIMM, 2.5” SATA III HDD, 3 independent displays, Intel TXT and vPro
technology.
2
IntroducingthePC
Specification
• Additional DVD docking support (optional)
• 90W power adaptor
Chipset
CPUSupport
Graphics
Storage
ODD
Power
Dimensions(mm)
Memory
FrontPanel
OS Support
• Intel®Q170
• Supports LGA1151 Socket for Intel®Skylake
processor (up to 35W)
• Intel®HD graphics from CPU
• Support 4K resolution and DX12 for Intel Skylake-S
• Support 1 x 2.5” SATAIII HDD
• 4 x USB 3.0 (one supports 2.6A for DVD docking)
• 1 x 10/100/1000 LAN RJ45
• 1 x Microphone/headphone connector
• 1 x COM port (optional)
• 1 x HDMI (support dual dispaly)
• 1 x D-Sub(VGA)
• 1 x DP port
• 1x DC-IN
• 173mm*176mm* 33mm
• 2 x SO-DIMM up to 32 GB, Dual-channel
• 2x USB 3.0 (one supports EZ Charger), 2x USB 2.0
• 1 x Headphone output
• 1 x MIC-IN
• Hardware Compatible with Windows 7/8.1/10
Expansion • 2 x M.2 slots
RearPanel
3
IntroducingthePC
FrontandRearI/O
4. USB 2.0 Connectors The USB 2.0 connector is used for USB 2.0 devices,
such as mouse, keyboard, printer, scanner and other
USB 2.0-compatible devices.
6. Headphone Jack Connecting Headphone.
5. USB 3.0 Connectors The USB 3.0 connector is used for USB 3.0 devices,
such as mouse, keyboard, printer, scanner and other
USB 3.0-compatible devices.
7. Mic In Jack Connecting Microphone.
1. Power Button Press the prower button to turn the system on and
off.
2. Power LED This is the power LED light.
3. HDD LED This is the HDD LED light.
4
IntroducingthePC
15. DP Port You can connect display device to the DP port.
14. D-SUB Connector
9. Kensington This is the security lock.
12. COM Port (optional) Connecting a serial port extension bracket.
10. LAN Connecting the Network.
11. HD Audio Microphone Jack/ Headphone Jack.
13. HDMI Port Connect display device to the HDMI port.
Connecting VGA Monitor.
16. DC Jack It is used for power adapter.
8. USB 3.0 Connectors Connecting USB 3.0 Devices.
Indice
Altri manuali ECS Scrivania
ECS
ECS MS110 Manuale utente
ECS
ECS LIVA One H310C Manuale utente
ECS
ECS 3L Small Form Factor 945GCD-3L Manuale utente
ECS
ECS Liva One Manuale utente
ECS
ECS LIVA X Manuale utente
ECS
ECS LIVA Z Manuale utente
ECS
ECS MS110 Manuale utente
ECS
ECS MD200 Manuale utente
ECS
ECS Liva One Manuale utente
ECS
ECS LIVA Z Manuale utente
ECS
ECS 3L Small Form Factor Manuale utente
ECS
ECS LIVA Q1A PLUS Manuale utente
ECS
ECS ECS G24 Manuale utente
ECS
ECS Liva One Manuale utente
ECS
ECS 3.8L MS400 Manuale utente
ECS
ECS 3.8L MS200 Manuale utente
ECS
ECS ECS G24 Manuale utente
ECS
ECS DS110 Manuale utente
ECS
ECS 3L SFF Nettop MD120 Manuale utente
ECS
ECS SI mPC Manuale utente
