Edimax SP-1101W Manuale utente

SP-1101W / SP-2101W with EdiLife

Quick Installation Guide

08-2018 / v1.0

CONTENTS

IIntroduction .......................................................................................... 1

II Smart Plug Setup................................................................................... 2

II-1 Package Contents .......................................................................................... 2

II-2 Hardware Installation.................................................................................... 3

III EdiLife App Setup .................................................................................. 5

III-1 Apple iOS....................................................................................................... 6

III-2 Android OS ....................................................................................................9

IV Resetting the Smart Plug ......................................................................12

IMPORTANT SAFETY INFORMATION

In order to ensure the safe operation of the device and its users, please read and act in accordance with

the following safety instructions:

WARNING: There is risk of fire or electric shock if the device is used inappropriately.

If you experience problems with the device, please contact your dealer of purchase for help. Accidental

damage will void the warranty of the device.

1. The device must be used within its published power outlet rating.

2. The device is recommended for indoor use in a dry location only.

3. Do not place the device near steam releasing devices or heat sources.

4. Avoid exposure of the device to external heat sources, sunlight, dust, corrosive chemicals, steam,

liquids and moisture.

5. Handle the device with care. Do not drop the device or subject the device to unnecessary physical

shock.

6. There are no user-serviceable parts inside the device. If you experience problems with the device,

do not attempt to service the device yourself.

7. Unplug the device during extended periods of inactivity and during lightning storms.

8. Do not use the device to operate or control heat-emitting devices unattended.

9. The power socket/outlet should be easily accessible and located near to the device intended for

use with the product.

10. Do not stack multiple devices on the product.

IIntroduction

SP-1101W / SP-2101W is Wi-Fi smart plugs that are mostly managed by a

powerful application tool from Edimax Technology. Once the smart plug is

connected to the internet, the accompanying app can turn on/off the smart

plug remotely.

This quick installation guide will guide you through the steps required to setup

the smart plug with the EdiLife app.

II Smart Plug Setup

II-1 Package Contents

SP-1101W / SP-2101W

Quick Installation Guide

CD with User Manual

Front Panel

1. Switch Status Button

& LED

2. Reset Button

3. Power LED

4. Network LED

II-2 Hardware Installation

Follow the instructions below to ensure your smart plug is properly connected

and ready for setup.

Please only set up one smart plug at a time.

1. Plug the smart plug into a power socket.

2. Press and hold the reset button (for ~10 seconds) on the plug until the

network LED starts flashing quickly in red and let go.

3. Wait a few moments for the smart plug to start up. The smart plug is

ready for setup when the network LED is flashing slowly in red to

indicate installation mode.

4. When smart plug is in installation mode, please continue to III EdiLife

App Setup to set up your smart plug using the free EdiLife app.

III EdiLife App Setup

To allow remote access to your smart plug, please use the EdiLife app.

After setup, you can use the EdiLife app to switch your smart plug on/off

remotely from any compatible mobile device with an Internet connection.

Please go to the setup instructions suitable for your mobile device (iOS

or Android OS).

III-1 Apple iOS

For EdiLife app to control the Smart Plug, it must be connected

to a Wi-Fi network with internet connectivity. To do so, follow

the steps below:

If you have not reset your smart plug, please do that now! Press and hold the

Reset Button (for ~10 seconds) until the network LED starts flashing quickly in

red and let go.

Please bring the smart plug within the Wi-Fi range of a

Wi-Fi router that has internet connectivity.

1. Search and download “EdiLife”in Apple App Store.

2. On your iOS device, go to Settings.

3. Tap the “Wi-Fi”(outlined in red) option.

4. Find and connect to the smart plug by tapping the

smart plug’s Wi-Fi name.

The smart plug’s Wi-Fi name should be in the format

EdiPlug.Setup XX as shown on the left:

When connected, the blue tick should be shown.

If you cannot find your smart plug, try resetting it.

See IV Resetting the Smart Plug

5. Open the EdiLife app and tap the icon (outlined

in red) on the top-right corner of the screen.

6. Enter a device name, password and confirm the

password.

For device name, enter a name where you will likely

use the smart plug for. For example, office desktop

light, bedside lamp, etc.

You can always come back to change its name later!

Please refer to the user manual.

7. Select a Wi-Fi network (e.g. your home’s Wi-Fi

router) from the Wi-Fi list.
