Edwards RV3 Manuale utente

NRA8-80-880

Issue C Original

Instruction Manual

Micromass UK

Autospec Rotary Pump Platform Assembly

Description Item Number

RV3, RVJ2 and E2Ml8 Pumping Platform NRA880000

This product has been manufactured under a quality system registered to ISO9001

Declaration of Conformity

We, Edwards,

Crawley Business Quarter,

Manor Royal

Crawley,

West Sussex, RH10 9LW, UK

declare under our sole responsibility, as manufacturer and person within the EU authorised

to assemble the technical file, that the product(s)

Autospec Platform NRA880000

to which this declaration relates is in conformity with the following standard(s) or other

normative document(s)

EN1012-2:1996, A1: 2009 Compressors and Vacuum Pumps. Safety Requirements. Vacuum

Pumps

EN12100:2010 Safety of machinery. General principles for design. Risk

assessment and risk reduction.

EN60034-1: 2004 Rotating electrical machines. Rating and performance

EN13463-1: 2009 Non-electrical equipment for use in potentially explosive

atmospheres. Basic method and requirements

EN13463-5: 2003 Non-electrical equipment for use in potentially explosive

atmospheres. Protection by constructional safety ‘c’

and fulfils all the relevant provisions of

2006/42/EC Machinery Directive

2006/95/EC Low Voltage Directive

2004/108/EC Electromagnetic Compatibility (EMC) Directive

94/9/EC ATEX Directive on use in Potentially Explosive Atmospheres

Note: This declaration covers all product serial numbers from the date this Declaration was

signed onwards.

26.02.2013, Lutin, CZ

Peter Meares, GV Technical Support Manage

Date and Place

P200-07-580 Issue A

Edwards and the Edwards logo are trademarks of Edwards Limited.

Contents

NRA8-80-880 Issue C

Contents

Section Page

1 Introduction .......................................................................................1

1.1 Scope and definitions ................................................................................................... 1

1.2 Description ................................................................................................................ 1

2 Technical Data ....................................................................................3

2.1 General .................................................................................................................... 3

3 Installation .........................................................................................5

4 Operation ..........................................................................................7

5 Maintenance .......................................................................................9

6 Storage and Disposal ........................................................................... 11

6.1 Storage ...................................................................................................................11

6.2 Disposal ...................................................................................................................11

7 Spares and Accessories ........................................................................ 13

7.1 Introduction .............................................................................................................13

For return of equipment, complete the HS Forms at the end of this manual.

Illustrations

Figure Page

1 Autospec rotary pump platform assembly ........................................................................... 2

Associated Publications

Publication Title Publication Number

RV3, RV5, RV8, RVI2 Rotary Vane Pumps A652-01-880

Rotary Vacuum Pumps EIMI8 and E2MI8 A343-01-880

Speedivalvcs C331-55-880

Vibration Isolators A248-01-880

System Safety Manual P400-40-100

cg/02/13

This page has been intentionally left blank.

NRA8-80-880 Issue C

Edwards and the Edwards logo are trademarks of Edwards Limited.

Introduction

NRA8-80-880 Issue C

1Introduction

1.1 Scope and definitions

For the safe operation of the pump platform please refer to the relevant instruction manuals and safety booklet

supplied as part of this document package.

This manual provides Installation, Operation and Maintenance instructions for the pump platform. You must use the

pump platform as specified in this manual and associated publications.

Read this manual before you install and operate the pump. Important safety information is highlighted as WARNING

and CAUTION instructions; you must obey these instructions. The use of WARNINGS and CAUTIONS is defined below.

CAUTION

Cautions are given where failure to observe the instruction could result in damage to the equipment, associated

equipment and process.

The following IEC warning labels appear on the pump:

The units used throughout this manual conform to the SI international system of units of measurement.

1.2 Description

The pump platform comprises of three rotary vacuum pumps RV3, RVl2 and E2Ml8 mounted on a single mobile

platform. Three manual speedivalve isolation valves provide process isolation. The exhausts from the vacuum pumps

arc connected via Tygon®tubing and provides a 5-metre exhaust line.

WARNING

Warnings are given where failure to observe the instruction could result in injury or death to

people.

Warning - refer to accompanying documentation.

Warning - hot surface.

XDS5 Designated Analyser

XDS10 Designated Source

XDS10 Designated Inlet-1

NRA8-80-880 Issue C

Edwards and the Edwards logo are trademarks of Edwards Limited.

Introduction

Figure 1 - Autospec rotary pump platform assembly

1 Speedivalve

2 RV3 Rotary vane pump

3RV12Rotaryvanepump

4 E2M18 Rotary vane pump

5Tygon

®tubing process exhaust

Edwards and the Edwards logo are trademarks of Edwards Limited.

Technical Data

NRA8-80-880 Issue C

2TechnicalData

2.1 General

Technical data relating to the rotary vane pumps can be found in the accompanying product manuals.

Inlet connection NW25

Exhaust connection Tygon® tubing 12.7 mm I.D.

Electrical connections Harting connector HAN 3A-M 10 A/240 V

Electrical supply 220/240 V, 50/60 Hz, 1 Ph

NRA8-80-880 Issue C

Edwards and the Edwards logo are trademarks of Edwards Limited.

This page has been intentionally left blank.

Edwards and the Edwards logo are trademarks of Edwards Limited.

Installation

NRA8-80-880 Issue C

3 Installation

WARNING

This pump platform is mounted on fixed castors; risk of movement is possible which may result in

damage to the inlet and exhaust pipe work, ideally the platform should be chocked in its operating

position to prevent accidental movement.

The pump platform should be placed in a position where it does not constitute a trip hazard. The

vacuum pumps overhang the footprint of the platform. Care should be taken when moving the

platform to avoid damage to the platform and personnel.

WARNING

The pump platform should not be lifted using the individual vacuum pump lifting eyes. The pump

platform should be lifted using suitably rated slings positioned beneath the base platform and

external to the castors. Care should be taken to ensure the lifting slings do not foul the vacuum

pumps.

NRA8-80-880 Issue C

Edwards and the Edwards logo are trademarks of Edwards Limited.

This page has been intentionally left blank.
