INSTRUCTION MANUAL
MV-01
Ventilation Unit
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 1
1. Index
1. Index 1
2. Important User Information 2
2-1. Contact Information 2
2-2. Warranty and Liability 2
2-3. About Instruction Manual 3
2-4. Environment 3
2-5. CE Declaration 4
3. Safety Information 5
3-1. WARNING/CAUTION 5
4. Introduction 7
4-1. Main Features 7
4-2. Package Contents 8
5. Getting Started 9
5-1. Parts Name and Descriptions 9
5-2. Installation 11
5-3. Ventilator Tachometer 13
6. Maintenance & Troubleshooting 14
6-1. Maintenance 14
6-2. Troubleshooting 15
7. Specification 16
7-1. Main Unit 16
7-2. Dimensions 17
7-3. Cables 18
7-4. Accessories List 18
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 2
2. Important User Information
Thank you for using EKO Products
Make sure to read this instruction manual thoroughly and to understand the contents before starting to operate the
instrument. Keep this manual at safe and handy place for whenever it is needed.
For any questions, please contact us at one of the EKO offices given below:
2-1. Contact Information
EKO INSTRUMENTS CO., LTD.
Asia, Oceania Region
https://eko-asia.com
EKO INSTRUMENTS Co., Ltd.
1-21-8 Hatagaya, Shibuya-ku
Tokyo, 151-0072 Japan
Tel: +81 (3) 3469-6711
Fax: +81 (3) 3469-6719
Europe, Middle East, Africa, South America Region
https://eko-eu.com
EKO INSTRUMENTS Europe B.V.
Lulofsstraat 55, Unit 28,
2521 AL, Den Haag, The Netherlands
Tel: +31 (0)70 3050117
Fax: +31 (0)70 3840607
North America Region
https://eko-usa.com
EKO INSTRUMENTS USA Inc.
111 North Market Street, Suite 300
San Jose, CA 95113 USA
Tel: +1 408-977-7751
Fax: +1 408-977-7741
2-2. Warranty and Liability
For warranty terms and conditions, contact EKO or your distributor for further details.
EKO guarantees that the product delivered to customer has been verified, checked and tested to ensure that
the product meets the appropriate specifications. The product warranty is valid only if the product has been
installed and used according to the directives provided in this instruction manual.
In case of any manufacturing defect, the product will be repaired or replaced under warranty. However, the
warranty does not apply if:
➢Any modification or repair was done by any person or organization other than EKO service
personnel.
➢The damage or defect is caused by not respecting the instructions of use as given on the product
brochure or the instruction manual.
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 3
2-3. About Instruction Manual
Copy Rights Reserved by EKO INSTRUMENTS CO., LTD. Making copies of whole or parts of this
document without permission from EKO is prohibited.
This manual was issued: 2019/11/11
Version Number: 4
2-4. Environment
1. WEEE Directive 2002/96/EC
(Waste Electrical and Electronic Equipment)
In August of 2005, the European Union (EU) implemented the EU WEEE Directive 2002/96/EC and later the
WEEE Recast Directive 2012/19/EU requiring Producers of electronic and electrical equipment (EEE) to
manage and finance the collection, reuse, recycling and to appropriately treat WEEE that the Producer
places on the EU market after August 13, 2005. The goal of this directive is to minimize the volume of
electrical and electronic waste disposal and to encourage re-use and recycling at the end of life.
EKO products are subject to the WEEE Directive 2002/96/EC. EKO Instruments has labeled its branded
electronic products with the WEEE Symbol (figure Trash bin) to alert our customers that products bearing this
label should not be disposed of in a landfill or with municipal or household waste in the EU.
If you have purchased EKO Instruments branded electrical or electronic products in the EU and are intending
to discard these products at the end of their useful life, please do not dispose of them with your other
household or municipal waste. Disposing of this product correctly will help save valuable resources and
prevent any potential negative effects on human health and the environment, which could otherwise arise
from inappropriate waste handling.
2. RoHS Directive 2002/95/EC
EKO Instruments has completed a comprehensive evaluation of its product range to ensure compliance with
RoHS Directive 2002/95/EC regarding maximum concentration values for substances.As a result all products
are manufactured using raw materials that do not contain any of the restricted substances referred to in the
RoHS Directive 2002/95/EC at concentration levels in excess of those permitted under the RoHS Directive
2002/95/EC, or up to levels allowed in excess of these concentrations by the Annex to the RoHS Directive
2002/95/EC.
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 4
2-5. CE Declaration
DECLARATION OF CONFORMITY
We: EKO INSTRUMENTS CO., LTD
1-21-8 Hatagaya Shibuya-ku,
Tokyo 151-0072 JAPAN
Declare under our sole responsibility that the product:
Product Name: Ventilation unit for Pyranometer
Model No.: MV-01
To which this declaration relates is in conformity with the following harmonized
standards of other normative documents:
Harmonized standards:
EN 61326-1:2013 Class A (Emission)
EN 61326-1:2013 (Immunity)
Following the provisions of the directive:
EMC-directive: 2014/30/EU
Low Voltage- directive: 2006/95/EC
Date: Jan. 14, 2016
Position of Authorized Signatory: Deputy General Manager of Quality Assurance Dept.
Name of Authorized Signatory: Shuji Yoshida
Signature of Authorized Signatory:
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 5
3. Safety Information
EKO Products are designed and manufactured with consideration for safety; however, please make
sure to read and understand this instruction manual thoroughly to be able to operate the instrument
safely in the correct manner.
WARNING
CAUTION
Attention to user; pay attention to the instructions given on the
instruction manual with this sign.
HIGH
VOLTAGE
WARNING
High voltage is used; pay special attention to instructions given on
this instruction manual with this sign to prevent electric leakage
and/or electric shocks.
HIGH
TEMPERATURE
WARNING
Touching or getting close to the devise may lead to burn.
3-1. WARNING/CAUTION
1. Setup
➢The installation base or mast should have enough load capacity for the instrument to be mounted.
Fix the pyranometer securely to the base or mast with bolts and nuts; otherwise, the instrument
may drop due to gale or earthquake, which may lead to unexpected accidents.
➢Make sure the instrument and the cables are installed in a location where they will not get soaked.
➢Do not use this product in environment where corrosive gas, such as ammonia and sulfurous acid
gas, are generated. It may cause malfunction.
➢Do not install in area that cause salt damages. It may cause malfunction by paint peeling off or
corrosion. When installing in area with risk of salt damages, make sure to take following
measures: 1. Wrap the connector with self-fusing tape, 2. Change the fixing screw to bolt screw
made of aluminum, 3. Run the cables in resin pipe or metal pipe treated with salt-resistant paint
such as molten zinc plating, 4. periodically clean.
➢Do not use this instrument in vacuum environment.
➢If the cable and main unit are in risk for getting damaged by birds and small animals, protect the
cable and the main unit by using: 1. Reflective tape, 2. Repellent, 3. Cable duct, 4. Installing
bird-spike
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 6
2. Fan Operation
➢Do not let your body parts, clothes, papers, animals and plants get close to the MV-01 while it is in
operation. You may be injured by getting your body part or clothing caught into the fan, or may
cause accidents by damaging the fan.
3. Power Supply
➢Make sure to check if there is an error in the type of power supply (AC or DC) or voltage for
measurement, and then connect this product. If you make a mistake, it may cause a failure or an
accident of this product.
➢Do not supply more than DC16V to the heater power supply line. Overcurrent protection works and
stops working.
4. High Temperature
➢Do not touch metal parts while heater is in operation as it will become high temperature. You may
get burn. Use the MV-01 in place where out of reach of children.
➢To avoid the temperature increase, always turn on the fan first before turning on the heater.
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 7
4. Introduction
EKO’s Ventilation Unit MV-01 can be used in combination with several kinds of pyranometer models
(MS-80/80A/80M, MS-60/60A/60M and MS-40/40A/40M), pyrgeometer model (MS-20). The MV-01 will reduce the
need for maintenance and assures the availability of solar irradiance data when deployed in cold climate regions or
desert environments. Due to the compact and integrated design with pyranometer, pyrgeometer and UV
radiometer, the heating and airflow dynamics are optimized. The power consumption of the ventilator is only 1.9
Watts, which makes it suitable for solar powered systems. When the heater is activated the total power
consumption will be about 8.4 watt, which is sufficient to prevent snow and ice deposition on the sensor (dome and
sun screen).
Pyranometer with ventilator can be mounted in horizontal or tilted plane, which make it suitable for PV monitoring
applications. The Tacho output provides a data pulse to monitor the fan speed.
For the pyranometers, pyrgeometers or UV radiometer operated in harsh environments, the measurements can be
easily affected by environmental factors. In such case the MV-01 will keep the pyranometer dome free of dew, ice
and snow. In combination with the MV-01 ventilator the best possible measures are taken for reliable unattended
operation.
4-1. Main Features
⚫Low power consumption (power consumption: 8.4W, fan 1.9W, heater: 6.5W)
⚫Wide range of operating temperature (-40℃to +70℃), the MV-01 can be operated in many different
areas of the world.
⚫Overheating protection trough temperature fuse
⚫Using the ventilation with long expected life has made possible to offer 2-year warranty.
⚫By measuring the rotation signal (pulse signal) of the MV-01, the rotation frequency of the fan can be
monitored.
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 8
4-2. Package Contents
Check the package contents first; if any missing item or damage is noticed, please contact EKO immediately.
Table 4-1 Package Contents
Standard Items
Qty.
Remarks
Ventilation Main Unit MV-01
1 set
Constructed with combination of heater unit and fan unit
Power Supply Cable [*]
1pc
Main Body Fixing Bolts
2pcs
M6 x100mm, bolts used for fixing the MV-01 main body in
installation position
Fixing Bolts
3pcs
M5 x 10mm, bolts used for fixing equipment to MV-01, Fine pitch
thread, 1pc spare screws attached.
Washers (M6)
4pcs
Nuts (M6)
2pcs
Hex Wrench (M5)
1
Used for fixing Pyranometer to MV-01
Inspection Report
1
Instruction Manual
1
Download from EKO website
Quick Start Guide
1
[*] Standard length of the Power Supply Cable is 10 meters. Contact EKO when longer cables are required.
Pyranometer or pyrgeometer is not included in this package.
EKO INSTRUMENTS CO., LTD. Ventilation Unit MV-01 Instruction Manual Ver. 4
Pg. 9
5. Getting Started
5-1. Parts Name and Descriptions
Each part name and its main functions are described below.
Parts Names
A. Heater Unit
B. Overcurrent protection
C. Fan Unit
D. Cable Connector
E. Leveling Screws
F. Fixed foot
Figure 5-1. Parts Names
1. Heater Unit
Heater can be used together with the fan unit to increase the forced air temperature. When the instruments
are used in cold regions and/or snowy regions, turn on the heater unit to prevent snow and ice getting on the
glass dome and sun screen.
2. Overcurrent protection
Overcurrent protection is included to prevent damage due to excessive temperature rise of the heater.
* Do not operate the heater in case the ambient temperature will be over 50℃and the heater supply voltage
more than DC16V. Overcurrent protection may be activated and stopped to supply to the heater current.
Since the MV-01 cannot be used for snow melting, please operate the fan and heater beforehand.
The heater should be used with the fan unit.
Table 5-1. Parts Name
A
F
B
D
C
E
