EKSA E900 Pro Manuale utente
User Manual
2-IN-1 Gaming Headset
EN
①
②
③
④
⑤
⑥
⑦
⑧
EKSA E900 Pro Gaming Headset
Detachable Microphone
Microphone Foam Cover
USB Audio Cable
3.5 mm Audio Cable
Carry Pouch
User Manual
Y Extension Cable
Package Contents
Specifications
Interface Type: 3.5 mm / USB
Driver Diameter: 50 mm
Sensitivity: 118 ± 3 dB
Impedance: 32 Ω
Frequency Response: 20 Hz – 20 kHz
Size: 6.0 mm * 2.7 mm
Sensitivity: -42 ± 3 dB (call mic)
Impedance: 2.2 kΩ
Supply Voltage: 3 V
Current Consumption: Max 0.5 mA
1
Leatherette Head Beam
Adjustable Headband
Protein Memory Foam Earmuffs
Detachable Microphone
Microphone Port
Type-C Audio Port
Light On/Off Button
Mic Mute Button
Volume Control Wheel
USB Audio Cable
3.5 mm Audio Cable
Y Extension Cable
Product Overview
1
3
4
9
10
11
5
7
8
2
6
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
2
12
Operation Guide
Light On/Off Button:
Volume Control Wheel:
x1
Single click: Light on/off
Mic Mute Button:
Scroll downwards: Volume -
Scroll upwards: Volume +
Up: Microphone on
Down: Microphone off
3
Click
x1
Main Features
0º
30º
60º
-60º
90º
-90º
60º
-60º
30º
0º
-30º
-30º
1. Immersive 7.1 Surround Sound
Before enjoying the 7.1 virtual surround sound, please make sure your
USB audio output is connected to the headset. Then you need to
download the EKSA Surround 7.1 driver from our official website
(https://www.eksa.net/download).
Note: EKSA Surround 7.1 driver only supports Windows system.
4
2. All-Platform Compatibility
The package includes two independent audio cables with different
interfaces. This gaming headset is widely compatible with PS®5, PS®4,
Xbox® One, Nintendo Switch™, PC, laptops, macOS, mobile devices, etc.
Nintendo Switch™
PC/macOS/Laptop
PS®4/PS®5
Xbox One® S/X mobile devices
Type-C interface
USB interface
3.5 mm interface
PS®4/PS®5
The first step
Please plug the
audio cable into
the headset first
The second step
Then plug the other side of the
audio cable into the device
USB Sound Settings
Windows®
macOS
Microphone Settings:
Audio Settings:
Follow the steps below to ensure your EKSA E900 Pro headset is the
default audio device.
[Control Panel]
[System Preferences] [Sound]
[Input] [EKSA E900 Pro]
[EKSA E900 Pro]
[Sound]
[Playback]
[EKSA E900 Pro (Set as Default Device)]
[Recording]
[Hardware and Sound]
[Control Panel]
[Sound]
[EKSA E900 Pro (Set as Default Device)]
[Output]
5
[Hardware and Sound]
[Settings]
[Sound]
[Microphone - Input Device - Headset (EKSA E900 Pro)]
[Adjust Microphone Level]
[Audio Output - Output Device - Headset (EKSA E900 Pro)]
[Switch Output Device Automatically]
[Volume - Headphones]
How to Use
PlayStation® 4 / PlayStation® 5:
Connect your PS®4/PS®5 directly using the USB or 3.5 mm audio
cable, and then follow the following steps to check the audio settings
to ensure that your PS®4/PS®5 automatically switches audio for
playback and microphone.
PS®4
6
PS®5
[Settings]
[Devices]
[Audio Devices]
[Output Device - Headset (EKSA E900 Pro)]
[Input Device - Headset (EKSA E900 Pro)]
[Volume Control (Headphones)]
[Adjust Microphone Level]
[Switch Output Device Automatically]
7
Guide for Xbox® Users
The controller has a 3.5 mm jack:
no adapter is required
The controller doesn't have a 3.5 mm
jack: a Microsoft adapter is required
(not included)
Xbox One® S/X controller Xbox® One controller (old version)
Xbox One® S/X:
To work on the NEW version of the Xbox One® S/X controller, you can
directly connect your headset to the controller via the 3.5 mm audio
cable.
Note:
1. The headset is not compatible with Xbox® 360.
2. Old version of Xbox® One needs a Microsoft adapter (not included).
How to Use
FAQ
8
Q1: My headset has no audio / I cannot hear anything from
my headset.
A: (1) First, ensure you’ve plugged the headset correctly into your
device. If that doesn’t work, check your audio settings to ensure
that you enable your speakers and don’t mute your device, then
check the volume of your device and headphone to ensure it is
at a proper level.
(2) Unplug the audio cable and reinsert it; wipe off the stains
or dust on the interface; reconnect the headset to your
device and check whether the microphone works properly now.
Q2: I cannot use the headset's microphone when connecting
to my computer.
A: (1) Go to Control Panel > Hardware and Sound > Sound. Disable the
onboard microphone on your computer, and make the Headset
Microphone default.
(2) Check that the microphone is not muted.
A: (1) Check that the microphone is not muted.
(2) Make sure that your headset is the default audio device through
the audio settings. Please refer to page 5 for more specific
sound setting methods.
(3) Make sure your device is compatible with the headset. The E900
Pro headset is not compatible with Xbox® 360, and the Old
version of Xbox® One needs an extra Microsoft adapter
(not included).
(4) If these have been confirmed and the headset is compatible with
the device, but the headset's microphone still cannot work,
Q3: The person on the other end of the call cannot hear me.
