EKSA STAR ENGINE E5000 Pro Manuale utente
Language Guide
English
日本語Français
Deutsch
Русский
Español
Italiano
Português
Türkçe
1
8
15
22
29
36
43
50
57
EN
Packing List
Specifications
Speaker Diameter: 50mm
Impedance: 55Ω±15%
Sensitivity: 112dB±3dB
Frequency Response: 20Hz-20kHz
Sensitivity: -42dB±3dB
Call Mic: Unidirectional
Noise Identifying Mic: Omnidirectional
Mic: AI-Powered Environmental Noise
Cancellation
1User Manual
①②③④⑤⑥⑦⑧EKSA Star Engine Gaming Headset
Detachable Microphone
Microphone Foam Cover
Carry Pouch
User Manual
3.5mm Audio Cable
Type-C Audio Cable
USB to USB-C Extender
1. Leather Head Beam
2. Adjustable Headband
3. Soft Extra-Large Earmuffs
4. Detachable Microphone
5. Microphone Port
6. Type-C Audio Port
7. Multi-Function Button (MFB)
8. Mic Mute Button
9. Volume Control Wheel
Product Overview
1234956782
Operation Guide
Multi-Function Button:
Volume Control Wheel:
3″
x1
Press for 3 seconds: LED Light on/off
Tap: Sound Mode Switch
Mic Mute Button:
Scroll upward: Volume +
Scroll downward: Volume -
Tap: Microphone on/off
x1 3(1) 7.1 Surround Sound: “surround sound on"
(2) Stereo Sound: “surround sound off”
Features HzdB0º30º60º-60º90º-90º60º-60º30º0º-30º-30º1. Immersive 7.1 Surround Sound
1.1The built-in powerful 50mm magnetic neodymium driver and 7.1
surround sound chip bring you an immersive gaming experience. Plug
in a Type-C or USB audio cable to enjoy the 7.1 surround sound by
default.
1.2You can also download the 7.1 driver from our official website to set
your preferred sound effect. (https://www.eksa.net/download)
Note:EKSA's 7.1 surround sound driver supports Windows only.
2.AI-Powered Environmental Noise Cancellation
The cutting-edged AI-powered environmental noise cancellation
technology can effectively eliminate up to 96% of background noise,
ensuring clear in-game chats. The caller's position will be accurately
calculated through a dual microphone array (a call microphone and a
noise-identifying microphone), thereby protecting the target voice.
1.11.2Noise
Identifying Mic
Call Mic
Environmental Noise
Call Voice
AI
Crystal-Clear Call Voice
4
Features
3. All-Platform Compatibility
Three separate audio cables with different interfaces are included in
the packing box. This gaming headset is widely compatible with PS®5,
PS®4, Xbox® One, Nintendo Switch™, PC, Laptop, Mac, and mobile
devices, etc.
4. One Key Sound Mode SwitchThis button is on the ear shell, allowing you to switch from 7.1 surround
sound to game mode or stereo to music mode. It is straightforward and
convenient to operate.
Note: when switching the sound mode, you will hear a "surround sound on/off" voice prompt.
7.15Nintendo Switch™
PC/Mac/Laptop
PS®4/PS®5Xbox® One S/X
mobile devices
Type-C interface
Type-C Audio Cable USB interface
Type-C to USB interface
3.5mm interface
PS®4/PS®5
USB Sound Setting
PC:
Mac:
[USB PNP Sound Device]
[System Preferences]
Follow the steps below to ensure your EKSA Star Engine headset is the
default audio device.
[Sound]
[Input] [USB PNP Sound Device]
[USB PNP Sound Device]
[Hardware and Sound]
[Sound]
[Set as Default Device]
[Output]
6[Control Panel]
How to Use?
Guide for Xbox®Users
The controller has a 3.5mm jack:
no adapter is required
The controller doesn't have a 3.5mm jack:
a Microsoft adapter is required
[Settings]
[Audio Devices]
[Output to Headphones]
[All Audio]
[Settings]
[Audio Devices]
[Output to Headphones]
[All Audio]
PlayStation® 4:
Xbox® One S/X:
If you want to connect this EKSA headset to an Xbox® One S/X, you'll need an
extra Microsoft adapter (not included in the box).
Steps for USB:
Steps for 3.5mm:
To get the best when using a PS®4, connect one end of the Type-C cable to
your headset and the other end with a USB extension cable. Then directly
connect your PS®4 controller with the USB interface, and follow the steps
below. 7
JP
梱包リスト仕様スピーカー直径：50mmインピーダンス：55Ω±15％感度：112dB±3dB周波数：20Hz-20kHz感度：-42dB±3dB通話マイク：単一指向性ノイズ識別マイク：全方向性マイク：AI搭載の環境ノイズキャンセリング8User Manual
①②③④⑤⑥⑦⑧EKSAスターエンジンゲーミングヘッドセット着脱式マイクマイクカバーキャリーポーチ取扱説明書3.5mmオーディオケーブルType-CオーディオケーブルUSBからUSB-C変換ケーブル
