EKSA H1 Plus Manuale utente
User Manual
H1 Plus
EN
EKSAtelecom H1 Plus Wireless Headset
EKSA PC Adapter
Type-C Charging Cable
Replacement Ear Pad
Carry Pouch
User Manual
①
②
③
④
⑤
⑥
Package Contents
Specifications
Headset Bluetooth Version: 5.0
Effective Wireless Range: 30 m / 99 ft
Adapter Bluetooth Version: 5.2
Effective Wireless Range: 10 m / 32 ft
Music Time: ≈57 hours (70% volume)
Talk Time: ≈30 hours (70% volume)
Charging Time: ≈1.5 hours
Speaker Diameter: 40 mm
Impedance: 32 Ω ± 15%
Sensitivity: 114 ± 3 dB
Frequency Response: 20 Hz – 20 kHz
Size: 2.7 mm * 1.85 mm
Sensitivity: -25 ± 1 dB
Frequency Response: 100 Hz – 10 kHz
Impedance: 2.2 kΩ
Polar Pattern: Omnidirectional
Mic: EKSAtelecom VoicePure Technology
1
User Manual
H1 Plus
Product Overview
2
3
4
1
2
5
6
8
9
10
11
7
Call Indicator
EKSAtelecom VoicePure Technology
Type-C Charging Port
Volume +
Bluetooth Indicator
Multi-Function Button (MFB)
Volume -
Mic Mute Button
Charging Indicator
EKSA PC Adapter
Replacement Ear Pad
7
6
4
8
39
2
1
1110
5
Remove
Install
Operation Guide
Multi-Function Button:
Press for 3 seconds: Headphone on/off
Click: Play/Pause
Triple Click: Voice Assistant/Siri
Volume Button:
Click: Volume + / -
x1
x1
Press for 2 seconds
to next/previous track
2″
Mic Mute Button:
Siri
Click: Microphone on/off
x1
x3
3
3″
Call Functions
x1 Answer
Reject
Double Click
x1
Click
Press for 2 seconds
Click
Hang up
Amy
Redial:
Call Handling:
Redial your last
call number
2″
x2
4
Call Functions
Three-Way Calling:
Amy
00:10
On the phone
New call Tom
Amy
x1
Click
x2
Double Click Press for
2 seconds
2″
Answer a new
call and hang
up your
current call
Tom Amy Tom Amy TomAmy
Keep your
current call and
reject a new call
Tom Amy
Keep your
current call
Answer a
new call
Three-way calling mode
During a three-way call
Switch between two calls
5
Double Click
x2
Bluetooth Pairing
EKSA-H1 Plus
EKSA-H1 Plus
EKSA-H1 Plus
1. Turn on EKSAtelecom H1
Plus, until its Bluetooth
indicator flashes alternately
between red and blue,
indicating that the headset
is in pairing mode.
2. Turn on the Bluetooth of your device, activate the search feature, and
select "EKSA-H1 Plus". After pairing, the Bluetooth indicator flashes
slowly in blue light with a voice prompt "your headset is connected",
confirming a successful connection.
3. To connect to a new device, turn off the Bluetooth of the currently paired
device and follow the above steps to connect successfully to a new device.
Note:
1. Keep the distance between the EKSAtelecom H1 Plus and your device within 1 meter.
2. If necessary, the pin code to complete pairing is "0000".
3. While in pairing state, if a connection cannot be established within 10 minutes, the
headset will turn off automatically.
4. When the headset is turned on again, it will connect to the last connected device
automatically.
6
Mobile
Phone:
3″
device A device B
7
Bluetooth Pairing
1. Plug the EKSA PC adapter into your PC's USB port. The adapter
will turn on automatically with a name of "EKSA PC Adapter"
displaying on your computer.
7
PC:
USB-A interface
Type-C interface
(Not included)
If you want to connect the headset to a PC, you can use the EKSA
PC adapter provided in the package. Then, you can enjoy the call
function and compatibility of the third-party software of the PC.
Follow the steps below to get it done.
8
Bluetooth Pairing
2. When enabled, the indicator on the EKSA PC adapter will flash a
blue light, which indicates that it is in pairing mode. Then, put the
headset on pairing mode and place it as close to the EKSA PC
adapter as possible (within 8 inches). The headset will automati-
cally connect to the EKSA PC adapter.
Note: It takes about 20 seconds to establish a connection between the headset and a PC for
the first time. Suppose the connection is unsuccessful, please unplug the adapter and
plug it back into the PC. Then restart the headset's pairing mode and reconnect to your
computer.
USB-A interface
Type-C interface
Indicator flashes in blue light
Indicator flashes in blue light
(Not included)
3. After the headset is successfully connected, the Bluetooth
indicator on the headset will slowly flash a blue light while the
EKSA PC adapter's indicator will always be blue.
Dual Pairing
EKSA-H1 Plus
OFF
1. After successfully connecting the EKSAtelecom H1 Plus to device
A, turn off the Bluetooth of device A. The headset’s Bluetooth
indicator flashes in red and blue alternately to signify pairing mode.
2. Turn on the Bluetooth of device B, activate search mode, and
connect to "EKSA-H1 Plus".
3. Turn on the Bluetooth of device A to connect with "EKSA-H1 Plus".
This puts both devices A and B in a simultaneous connection with
"EKSA-H1 Plus".
9
device A
device A
device B device B
