Electro-Voice ELX112P Manuale utente

Electro-Voice Live X Series Powered Owner’s Manual 15

Speci cations

1Full Space Measurement, Boost Mode, Full-Range Mode.

2Half Space Measurement, Boost Mode

3Max SPL is measured at 1m using broadband pink noise at maximum ampliﬁer output.

Model

(Part Number)

ELX112P

(120V - F01U170820)

(230V - F01U170817)

ELX115P

(120V - F01U170821)

(230V - F01U170818)

ELX118P

(120V - F01U170822)

(230V - F01U170819)

Freq. Response (-3 dB): 60 Hz - 18 kHz156 Hz - 18 kHz142 Hz - 100 Hz2

Freq. Range (-10 dB): 50 Hz - 20 kHz144 Hz - 20 kHz132 Hz - 130 Hz2

Max. Measured SPL3: 132 dB 134 dB 134 dB

Coverage (Horiz. x Vert.): 90° x 50° Omnidirectional

Power Handling: 1000W 700W

LF Transducer: (1) EVS-12K, 305mm (12”) Woofer (1) EVS-15K, 381mm (15”) Woofer (1) EVS-18K, 457mm (18”) Woofer

HF Transducer: DH-1K, 39mm (1.5”) Titanium Diaphragm Compression Driver N/A

Crossover Frequency: 1.7 kHz 100 Hz

Connectors: (2) XLR/TRS Combo Jacks, (1) Stereo RCA,

(1) XLR Link Output

(1) XLR/TRS Combo Jack,

(1) XLR Link Output

Enclosure Material: 9-ply, 15mm Plywood, Internally Braced, with Texured Paint

Grille: 18GA Steel with Black Powdercoat

Dimensions (H x W x D): 607mm x 362mm x 340mm

(23.89” x 14.25” x 13.41”)

708mm x 432mm x 382mm

(27.89” x 17.02” x 15.05”)

661mm x 507mm x 574mm

(26.02” x 19.98” x 22.60”)

Net Weight: 18.8 kg (41.6 lbs) 24.3 kg (53.7 lbs) 31.7 kg (69.7 lbs)

Shipping Weight: 23.2 kg (51.3 lbs) 29.5 kg (65.1 lbs) 39.3 kg (86.6 lbs)

Accessories:

TSS-1, Aluminum Tripod Stand

TSP-1, Tripod Kit, Includes (2) Tripod Stands and Carrying Case

ASP-1, Steel Subwoofer Stand

ASP-1, Steel Subwoofer Stand
