Electrolux ESI 63020 Manuale utente

user manual

ESI 63020

dishwasher

117991 56/0en 22-01-2007 12:24 Pagina 1

http://www.markabolt.hu/

We were thinking of you

when we made this product

117991 56/0en 22-01-2007 12:24 Pagina 2

http://www.markabolt.hu/

welcome to the world of Electrolux electrolux 3

Thank you for choosing a first class product from Electrolux, which

hopefully will provide you with lots of pleasure in the future. The

Electrolux ambition is to offer a wide variety of quality products

that make your life more comfortable. You find some examples on

the cover in this manual. Please take a few minutes to study this

manual so that you can take advantage of the benefits of your new

machine. e promise that it will provide a superior User

Experience delivering Ease-of-Mind. Good luck!

elcome to the world of Electrolux

117991 56/0

117991 56/0en 22-01-2007 12:24 Pagina 3

http://www.markabolt.hu/

Safety information 5

Product description 7

Control panel 8

First use 11

Daily use 15

ashing programmes 26

Care and cleaning 27

Something not working 29

Technical data 32

Hints for test institutes 34

Installation 35

Environment concerns 39

Guarantee/Customer Service 40

Contents

The following symbols are used in this manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

General information and tips

Environmental information

4electrolux contents

117991 56/0en 22-01-2007 12:24 Pagina 4

http://www.markabolt.hu/

safety information electrolux 5

In the interest of your safety and to

ensure the correct use, before

installing and first using the

appliance, read this user manual

carefully, including its hints and

warnings. To avoid unnecessary

mista es and accidents, it is

important to ensure that all people

using the appliance are thoroughly

familiar with its operation and

safety features. Save these

instructions and ma e sure that

they remain with the appliance if it

is moved or sold, so that everyone

using it through its life will be

properly informed on appliance use

and safety.

Correct use

●This dishwasher is only intended

for washing household utensils

suitable for machine washing.

●Do not put any solvents in the

dishwasher. This could cause an

explosion.

●Knives and other items with sharp

points must be loaded in the

cutlery basket with their points

down or placed in a horizontal

position in the upper basket.

●Only use products (detergent, salt

and rinse aid) suitable for

dishwashers.

●Avoid opening the door whilst the

appliance is in operation, hot

steam may escape.

●Do not take any dishes out of the

dishwasher before the end of the

dishwashing cycle.

Safety information

●After use, isolate the appliance

from the power supply and turn off

the water supply.

●This product should be serviced

only by an authorised service

engineer, and only genuine spare

parts should be used.

●Under no circumstances should

you attempt to repair the machine

yourself. Repairs carried out by

inexperienced persons will cause

injury or serious malfunctioning.

Contact your local Service Force

Centre. Always insist on genuine

spare parts.

General safety

●Dishwasher detergents can cause

chemical burns to eyes, mouth and

throat. Could endanger life!

Comply with the safety instructions

of the dishwasher detergent

manufacturer.

●The water in your dishwasher is

not for drinking. Detergent

residues may still be present in

your machine.

●Ensure that the door of the

dishwasher is always closed when

it is not being loaded or unloaded.

In this way you will avoid anybody

tripping over the open door and

hurting themselves.

●Do not sit or stand on the open

door.

Child safety

●This appliance is designed to be

operated by adults. Don’t allow

children to use the dishwasher

unsupervised.

117991 56/0en 22-01-2007 12:24 Pagina 5

http://www.markabolt.hu/

6electrolux safety information

For electrical and water connection

carefully follow the instructions

given in specific paragraphs.

●Keep all packaging well away from

children. There is risk of

suffocation.

●Keep all detergents in a safe place

out of children’s reach.

●Keep children well away from the

dishwasher when the door is open.

Installation

●Check your dishwasher for any

transport damage. Never connect

a damaged machine. If your

dishwasher is damaged contact

your supplier.

●All packaging must be removed

before use.

●Any electrical and plumbing work

required to install this appliance

must be carried out by a qualified

and competent person.

●For safety reasons it is dangerous

to alter the specifications or

attempt to modify this product in

any way.

●Never use the dishwasher if the

electrical supply cable and water

hoses are damaged; or if the

control panel, work top or plinth

area are damaged such that the

inside of the appliance is freely

accessible. Contact your local

Service Force centre, in order to

avoid hazard.

●All sides of the dishwasher must

never be drilled to prevent damage

to hydraulic and electric

components.

117991 56/0en 22-01-2007 12:24 Pagina 6

http://www.markabolt.hu/

product description electrolux 7

Product description

Upper basket

ater hardness dial

Salt container

Detergent dispenser

Rinse aid dispenser

Rating plate

Filters

Lower spray arm

Upper spray arm

117991 56/0en 22-01-2007 12:24 Pagina 7

http://www.markabolt.hu/

8electrolux control panel

Control panel

Programme mar er

On/Off indicator light

Programme nob

Start/cancel button

Delay start button

Indicator lights

117991 56/0en 22-01-2007 12:24 Pagina 8

http://www.markabolt.hu/

control panel electrolux 9

The salt and rinse aid indicator

lights are never illuminated while a

washing programme is running

even if filling with salt and/or rinse

aid is necessary.

The salt indicator light on the

control panel can remain

illuminated for 2-6 hours after the

salt has been replenished,

assuming the dishwasher remains

switched on. If you are using salts

that ta e longer to dissolve then

this can ta e longer. The function

of the machine is not affected.

Wash

Indicator lights

Dry

Illuminates when the washing and rinsing

phases are running.

Illuminates when the drying phase is running.

End of programme Illuminates when a washing programme has

ended. It also has added functions of visual

signalling as:

- the setting of the water softener,

- intervention of an alarm due to the

malfunction of the machine.

Salt Illuminates when the special salt has run out.

Rinse aid Illuminates when the rinse aid has run out.

117991 56/0en 22-01-2007 12:24 Pagina 9

http://www.markabolt.hu/

10 electrolux control panel

Programme nob and On/Off

indicator light

●The selection of a washing

programme occurs by turning the

programme knob clockwise or

anticlockwise, until the programme

marker, placed on the knob,

corresponds with the desired

washing programme indicated on

the control panel.

The On/Off indicator light

illuminates (position ON)

●To switch off the appliance turn the

programme knob until the

programme marker corresponds

with the On/Off indicator light.

The On/Off indicator light turns off

(position OFF).

ith the programme knob it is also

possible to set the level of the water

softener.

117991 56/0en 22-01-2007 12:24 Pagina 10
