Operatingmanual

Tumbledryer

T5290

TypeN2...

4389215-50/EN

Operatingmanualinoriginallanguage2011.06.21

Contents

1SafetyPrecautions.............................................................................................................5

2Programdescription...........................................................................................................7

2.1General.......................................................................................................................7

2.2Programdescription...................................................................................................7

2.3Optionbuttons............................................................................................................9

2.4Load............................................................................................................................9

3Handling.............................................................................................................................10

3.1Tostartthemachine...................................................................................................10

3.2Tostartacoinoperatedmachine...............................................................................11

3.3Additionalfunctions....................................................................................................12

3.4Whenprogramhasended..........................................................................................12

4Errorcodes.........................................................................................................................13

5Maintenance.......................................................................................................................14

5.1General.......................................................................................................................14

5.2Everyday....................................................................................................................14

5.3Theareaunderthelter.............................................................................................15

5.4Freshairintake...........................................................................................................15

5.5Machineswithresidualmoisturecontrol(RMC).........................................................16

5.6Maintenancetobecarriedoutbyqualiedservicepersonnel....................................16

Themanufacturerreservestherighttomakechangestodesignandcomponentspecications.

SafetyPrecautions5

1SafetyPrecautions

Themachineisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryor

mentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervisionor

instructionconcerninguseoftheappliancebyapersonresponsiblefortheirsafety.

Childrenshouldbesupervisedtoensurethattheydonotplaywiththemachine.

Themachineisnottobeusedifindustrialchemicalshavebeenusedforcleaning.

Donotdryunwasheditemsinthemachine.

Itemsthathavebeensoiledwithsubstancessuchascookingoil,acetone,alcohol,petrol,kerosene,spot

removers,turpentine,waxesandwaxremoversshouldbewashedinhotwaterwithanextraamount

ofdetergentbeforebeingdriedinthemachine.

Itemssuchasfoamrubber(latexfoam),showercaps,waterprooftextiles,rubberbackedarticlesand

clothesorpillowsttedwithfoamrubberpadsshouldnotbedriedinthemachine.

Fabricsoftenersorsimilarproductsshouldbeusedasspeciedbythefabricsoftenerinstructions.

Thenalpartofadryingcycleoccurswithoutheat(cooldowncycle)toensurethattheitemsareleftata

temperaturethatensuresthattheitemswillnotbedamaged.

Removeallobjectsfrompocketssuchaslightersandmatches.

WARNING.Neverstopthemachinebeforetheendofthedryingcycleunlessallitemsarequicklyremoved

andspreadoutsothattheheatisdissipated.

Adequateventilationhastobeprovidedtoavoidthebackowofgasesintotheroomforappliances

burningotherfuels,includingopenres.

Exhaustairmustnotbedischargedintoauewhichisusedforexhaustingfumesfromappliancesburning

gasorotherfuels.

Themachinemustnotbeinstalledbehindalockabledoor,aslidingdoororadoorwithahingeonthe

oppositesidetothatofthemachine.

Ifthemachinehasalinttrapthishastobecleanedfrequently.

Thelintmustnotbeaccumulatedaroundthemachine.

Gasheatedtumbledryer:

Themachineisnottobeinstalledinroomscontainingcleaningmachineswithperchloroethylene,

TRICHLOROETHYLENEorCHLOROFLUOROCONTAININGHYDROCARBONSascleaningagents.

Ifyoucansmellgas:

•Donotswitchonanyequipment

•Donotuseelectricalswitches

•Donotusetelephonesinthebuilding

•Evacuatetheroom,buildingorarea

•Contactthepersonresponsibleforthemachine

AllexternalequipmentwhichisconnectedtothemachinemustbeCE/EMC-approvedandconnectedusing

anapprovedshieldedcable.

6SafetyPrecautions

Inordertopreventdamagetotheelectronics(andotherparts)thatmayoccurastheresultofcondensation,

themachineshouldbeplacedinroomtemperaturefor24hoursbeforebeingusedforthersttime.

Programdescription7

2Programdescription

2.1General

Themachineisequippedwithanumberofprogramsadaptedtotherangeofusetowhichthe

machineisintended.

Itisrecommendettofollowthecarelabellingofthegarmentasfaraspossible.

Forbestpossibledryingresultitisadvisabletodrygarmentsofthesamequalityforeachdrying

cycle.

Note!

Donottumbledrywoolorsilk.

2.2Programdescription

Therearetwotypesofprograms,automaticprogramsandtimeprograms.

Automaticprogramshasmoisturedetectionandwillstopautomatically.

Timeprogramshasnomoisturedetectionandwillstopwhenthepresettimehasended.

Thefollowingprogramscanbeavailable:

AutomaticprogramsDescription

Normaltemp.Cottonandterry.

Normal/mediumtemperature.

Theprogramwillstopwhenselecteddryness/optionisachieved(Extradry,DryorIrondry).

Lowtemp.Synthetic,viscose,polycottonanddelicatefabrics.

Lowtemperature.

Theprogramwillstopwhenselecteddryness/optionisachieved(Extradry,DryorIrondry).

TimeprogramsDescription

Normaltemp.Cottonandterry

Differentdryingtimescanbeselected.

Theprogramwillstopwhenthetimeisup.

Lowtemp.Synthetic,viscose,polycotton,downanddelicatefabrics.

Differentdryingtimescanbeselected.

Theprogramwillstopwhenthetimeisup.

NoheatingAiringbedspreads,duvetsandbedclothes

Differentdryingtimescanbeselected.

Theprogramwillstopwhenthetimeisup.

8Programdescription

Forsomemarkets,adifferentsetofautomaticprogramscanbeavailable:

AutomaticprogramsDescription

Normaltemp.

Extradry

Denimandterry.

Normaltemp.

Dry

Cottonandterry.

Normaltemp.

Irondry

Cotton

Lowtemp.

Extradry

Viscoseandpolycotton.

Lowtemp.

Dry

Syntheticanddelicatefabrics

Lowtemp.

Irondry

Synthetic,viscoseandpolycotton

Microfibre

Forcoinoperatedmachinesthefollowingprogramscanbeavailable:

TimeprogramsDescription

Hightemp.Cottonandterry.

Theprogramwillstopwhenthetimeisup.

Normaltemp.Cottonandterry

Theprogramwillstopwhenthetimeisup.

Lowtemp.Synthetic,viscose,polycotton,downanddelicatefabrics.

Theprogramwillstopwhenthetimeisup.

NoheatingAiringbedspreads,duvetsandbedclothes

Theprogramwillstopwhenthetimeisup.

Exampleofsyntheticfabrics:polyester,polyamide,polyacrylicandelastan.

Programdescription9

2.3Optionbuttons

Thefollowingoptionscanbeavailable:

OptionbuttonDescription

ExtradryThroughdryingofthickormultilayeredfabrics.

Dryingstopswhenextradry.

DryReadytoputincupboard/closet.Throughdryingoffabricsofeven

thicknesses.

Dryingstopswhendry.

IrondryDamp.Readyforironing.Forthintextileswhicharetobeironed.

Dryingstopswhenirondry.

QuickprogramTheprogramwillbereadyasquickaspossible.

EcoprogramDriesusinglessenergy.

CareprogramDryingofsensitivefabrics.Onlysuitableforusewithsmallloads.

Note!

Fortimeprogramsnooptionsareavailable.

2.4Load

Foranoptimalresultitisrecommendedtoloadthemachinetohalf.

10Handling

3Handling

Loadthegoodsintothemachineaccordingtorecommendationsandclosethedoor.

Makesurethelteriscleanandcleanifnecessary.

g.7178

①

3.1Tostartthemachine

Selectthedesiredprogrambyturningthecontrolknob.

Therearetwotypesofprograms,automaticprogramsandtimeprograms.

Automaticprogramshasmoisturedetectionandwillstopautomatically.

Timeprogramshasnomoisturedetectionandwillstopwhenthepresettimehasended.

Automaticprograms

Forautomaticprogramsitispossibletoselect“Quickprogram”,“Ecoprogram”or“Care

program”bypressingoneofthebuttons.“Quickprogram”ispreselected.

Quickprogram

Ecoprogram

Careprogram
