Electrolux TWSL6IE300 Manuale utente
CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................6
3. PRODUCT DESCRIPTION................................................................................ 8
4. CONTROL PANEL............................................................................................. 9
5. FIRST TIME START-UP.....................................................................................9
6. USING THE TOUCH SCREEN........................................................................ 11
7. WI-FI - CONNECTIVITY SETUP................................................................ 12
8. BEFORE FIRST USE....................................................................................... 14
9. PROGRAMMES............................................................................................... 14
10. OPTIONS........................................................................................................17
11. DAILY USE..................................................................................................... 18
12. MACHINE SETTINGS.................................................................................... 22
13. HINTS AND TIPS........................................................................................... 24
14. CARE AND CLEANING..................................................................................25
15. TROUBLESHOOTING....................................................................................27
16. TECHNICAL DATA.........................................................................................30
17. ACCESSORIES..............................................................................................32
18. QUICK GUIDE................................................................................................33
19. GUARANTEE ................................................................................................ 35
GET IT ON
electrolux.com/app
www.electrolux.com2
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
- Read the supplied instructions.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
ENGLISH 3
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Children of less than 3 years should be kept away
unless continuously supervised.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, this should
be activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•If the tumble dryer is put on top of a washing machine,
use the stacking kit. The stacking kit, available from
your authorized vendor, can be used only with the
appliance specified in the instructions, supplied with
the accessory. Read it carefully before installation
(Refer to the Installation leaflet).
•The appliance can be installed as freestanding or
below the kitchen counter with correct space (Refer to
the Installation leaflet).
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from being
fully opened.
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
www.electrolux.com4
•WARNING: The appliance must not be supplied
through an external switching device, such as timer, or
connected to a circuit that is regularly switched on and
off by a utility.
•Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
•Ensure good air ventilation in the located room to
avoid the backflow of unwanted gases into the room
from appliances burning gas or other fuels, including
open fires.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Do not exceed the maximum load of 8 kg (refer to the
"Programme chart" chapter).
•Do not use the appliance if items have been soiled
with industrial chemicals.
•Wipe away lint or packaging debris that has
accumulated around the appliance.
•Do not run the appliance without a filter. Clean the lint
filter before or after each use.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers
should be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
•Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
ENGLISH 5
•Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
•WARNING: Never stop a tumble dryer before the end
of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature can be less
than 5°C or higher than 35°C.
• The floor area where the appliance is
to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical
when being moved.
• The rear surface of the appliance
must be put against the wall.
• When the appliance is in its
permanent position, check that it is
fully level with the aid of a spirit level.
If it is not, adjust the feet accordingly.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the
E.E.C. Directives.
2.3 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• This appliance is for household use
only.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• Only dry fabrics which are applicable
to dry in the tumble dryer. Follow the
instructions on the fabric label.
• If you have washed your laundry with
a stain remover start an extra rinse
cycle before you start the dryer.
• Do not drink or prepare food with the
condensed water/distilled water. It can
cause health problems to people and
pets.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
tumble dryer.
www.electrolux.com6
2.4 Internal light
WARNING!
Risk of injury.
• Visible LED radiation, do not look
directly into the beam.
• The LED lamp is dedicated to drum
lighting. This lamp cannot be reused
for other lighting purposes.
• To replace the internal light, contact
the Authorised Service Centre.
2.5 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• To prevent damage to the cooling
system be careful when you clean the
appliance.
2.6 Compressor
WARNING!
Risk of damage to the
appliance.
• The compressor and its system in the
tumble dryer is filled with the special
agent which is free from fluoro-chloro-
hydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
ENGLISH 7
3. PRODUCT DESCRIPTION
1 2
8
3
4
5
6
7
10
9
1Water container
2Control panel
3Internal light
4Appliance door
5Filter
6Rating plate
7Airflow slots
8Condenser lid
9Condenser cover
10 Adjustable feet
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
www.electrolux.com8
4. CONTROL PANEL
2
4 3
1
1Program dial
2Touch screen
3Start/Pause button
4On/Off button with
Auto Off
function
5. FIRST TIME START-UP
When you turn on your dryer for the first
time, the Start-up Screen (shows the
Electrolux logo and the time ) appears on
the touch screen and plays each time
you turn on the dryer.
After the animation plays, you are guided
through the initial setup procedure.
13.45
5.1 Language setup
1. Scroll the list of languages up or
down to find the language you want
to use and press it.
English
Deutch
Svenska
Italiano
Francais FR
IT
EN
DE
SV
Language1/4
2. To accept the language tap on OK, if
you want to change it tap onChange.
English
You’ve chosen:
Language2/4
Change OK
ENGLISH 9
5.2 Time setup
1. Scroll the bar of hours and minutes to
the right or left to set the current time.
0124 02
0159 00
Clock 01:00
h
min
Clock3/4
2. To select the time tap on the clock
bar.
0124 02
0159 00
Clock 01:00
h
min
Clock3/4
3. To accept the time tap on OK, if you
want to change it tap onChange.
18:45
Current time:
Clock4/4
Change OK
5.3 More Settings
After you accept the current time, the
More Settings screen pop-up.
More settings to get the best results
from this machine will follow. Set
them now or later?
More Settings
Cancel OK
If you tap on Cancel, the program list
appears and in a few seconds it will
change in to the summary screen. The
dryer is ready to use.
Cottons
Machine Settings
Refresh
Synthetics
Mixed
1h50min
Cupb.
30min
More
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
If you tap on OK, proceed to next
settings.
Water Hardness
1. For optimal performance set the
water hardness by pressing Change
or press OK to leave the default
Medium water hardness.
For optimal performance set what
kind of water you have; soft, medium
or hard. Keep medium?
Water Hardness1/2
Change OK
2. To change default value scroll the
bar to the right or left, to set the water
hardness: Hard, Medium or Soft.
Medium
MedWater Hardness
Water Hardness1/2
3. To select the value press the Water
Hardness bar.
www.electrolux.com10
Indice
Lingue:
Altri manuali Electrolux Asciugatrice
Electrolux
Electrolux EFDE210TIW Manuale utente
Electrolux
Electrolux EIED50LIW Istruzioni per l'installazione
Electrolux
Electrolux T5130 Manuale utente
Electrolux
Electrolux TK GL5 E Manuale utente
Electrolux
Electrolux EIMED60JRR0 Manuale utente
Electrolux
Electrolux GLEQ642AS Manuale utente
Electrolux
Electrolux Affinity Istruzioni per il montaggio
Electrolux
Electrolux EDH3685PDW Manuale utente
Electrolux
Electrolux EDH9000W3 Manuale utente
Electrolux
Electrolux Compass Pro TD6-37LAC Manuale utente
Electrolux
Electrolux EDE56150W Manuale utente
Electrolux
Electrolux TWSL4E300 Manuale utente
Electrolux
Electrolux IQ-TOUCH EIGD55H IW Manuale utente
Electrolux
Electrolux QuickDry QDC Manuale utente
Electrolux
Electrolux EDV705H3WB Manuale utente
Electrolux
Electrolux TW L4 E Manuale utente
Electrolux
Electrolux EDH3498RDE Manuale utente
Electrolux
Electrolux ZANUSSI ZDC 5350 W Manuale utente
Electrolux
Electrolux EDC 67130W Manuale utente
Electrolux
Electrolux EIMED55IIW - 27" Electric Dryer Manuale di servizio
Manuali Asciugatrice popolari di altre marche
BOMANN
BOMANN WT 5019 Manuale utente
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Manuale utente
Asko
Asko T793C Manuale utente
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuale utente
Frigidaire
Frigidaire CAQE7077KW0 Manuale del proprietario
Bosch
Bosch WTX8HKM9SN Manuale utente
