Electrolux EHI3251BE Manuale di istruzioni

Installation & User manualInduction hob

EHI3251BE,EHI635BE, EHI977BE

Customer Care Center 22

PRODUCT DESCRIPTION

EHI3251BE

1Induction cooking zone

2Induction cooking zone

3Control panel

PRODUCT DESCRIPTION

EHI635BE

1 2

3 4

EHI977BE

1Induction cooking zone

2Induction cooking zone

3Induction cooking zone

4Induction cooking zone

5Control panel

6Induction cooking zone

1 32

4 5 6

1Induction cooking zone

2Induction cooking zone

3Induction cooking zone

4Control panel

5Induction cooking zone

Control panel layouts

Sensor ﬁeld Function

1To activate and deactivate the appliance

2To lock / unlock the control panel

Sets all operating zones to a keep warm setting

3To activate the Bridge function

4To activate and deactivate the Child lock

Control bar To set a heat setting

To increase or decrease the time

To set the timer function

12 3

EHI3251BE

To set the heating zone

9To activate the Power function

Control panel layouts

Sensor ﬁeld Function

1To activate and deactivate the appliance

2To lock / unlock the control panel

Sets all operating zones to a keep warm setting

3To activate the Bridge function

4To activate and deactivate the manual mode of the

Hob2Hood function.

5To activate the Sensefry function

6Control bar To set a heat setting

7To increase or decrease the time

8To set the timer function

9To activate the Power function

10 A heat setting display To show the heat setting

1 2 3 4

57 8 9 10

EHI635BE

PRODUCT DESCRIPTION (CONTINUED)

Control panel layouts

EHI977BE

Sensor ﬁeld Function

1To activate and deactivate the appliance

2To activate the chef function

3To activate the Sensefry function

4To increase or decrease the time

5To set the timer function

6To activate and deactivate the manual mode of the

Hob2Hood function.

7To switch between the modes of the function

8Control bar To set a heat setting

9To activate the Power function

10 To lock / unlock the control panel

11 A heat setting display To show the heat setting

12 Sets all operating zones to a keep warm setting

1 2 3

4 5 6

109 12118

Display Description

The cooking zone is deactivated

The cooking zone operates

Sets all operating zones to a keep warm setting

The automatic heat up function operates

Power function operates

+ digit There is a malfunction

OptiHeat Control (3 step Residual heat indicator) : continue cook / stay warm / residual heat

Lock / The child safety function operates

Not correct cookware or too small or no cookware on the cooking zone

The automatic switch off function operates

Heat setting displays

OptiHeat control (3 step residual heat indicator)

WARNING!

Risk of burns from residual heat!

OptiHeat Control shows the level of the residual heat.

The induction cooking zones make the heat necessary

for cooking directly in the bottom of the cookware. The

glass ceramic is hot from the heat of the cookware.

OPERATING INSTRUCTIONS

On and off

Touch for 1 second to activate or deactivate the

appliance.

Automatic switch off

The function deactivates the appliance automatically if:

•All cooking zones are deactivated ( ).

•You do not set the heat setting after you activate the

appliance.

•You spill something or put something on the control

panel for more than 10 seconds, (a pan, a cloth, etc).

An acoustic signal sounds after some time and the

appliance deactivates. Remove the object or clean the

control panel.

•The appliance becomes too hot (e.g. when a

saucepan boils dry). Before you use the appliance

again, wait for the cooking zone to cool down.

•You use incorrect cookware. The symbol comes

on and the cooking zone deactivates automatically

after 2 minutes.

•You do not deactivate a cooking zone or change the

heat setting. After some time comes on and the

appliance deactivates. See the table below.

Automatic switch off times

Heat setting

Stops after 6 hours 5 hours 4 hours 1.5 hours

The heat setting

Touch the control bar at the heat setting. Change to the

left or the right, if it is necessary. Do not release before you

have a correct heat setting. The display shows the heat

setting.

Bridge function

IMPORTANT!

Use the Bridge Function with the

Inﬁnite Plancha accessory1).

The Bridge Function connects the two left side cooking

zones under the accessory and they operate as one.

First set the heat setting for one of the cooking zones.

To activate the Bridge Function, touch To set or change

the heat setting, touch one of the control sensors. To

deactivate the Bridge Function, touch The cooking

zones operate independently.
