Quick Start Guide

EVE602, EVE614 Series

Dear Customer,

Thank you for purchasing an Electrolux oven. You’ve chosen a product that brings with it

decades of professional experience and innovation. Intuitive and seamless, it has been

designed with you in mind. We want to give you the tools to make great tasting food and

to enrich your home life.

Welcome to Electrolux.

Ready

This is a Quick Start Guide. Please refer to user manual online

for detailed information and installation.

To access your detailed user manual online, simply scan the QR code on

your smart phone.

For more detailed information and installations guide refer to user manuals

at electrolux.com.au/support/manuals/

Before you start, please make sure:

OYour oven has been correctly installed

by a qualiﬁed person.

OYour oven has power and is switched on.

OYou’ve removed all relevant packaging.

Set Now let’s get your oven ready to use:

45 6

1Oven ‘ON’ light

2Timer display

3Heating light

4Function selector knob

5Touchpad

6Temperature selector knob

Get to know your oven control panel:

Most of the packaging

materials can be recycled.

Please dispose of them at

your local recycling centre

or in your own recycling bin.

1 2 3

Condition the oven

(to burn oﬀ any residue)

New appliances can have oil or residue left from

manufacturing. You will need to heat your oven for

30 minutes before using it for the ﬁrst time.

1. Turn the function selector knob to FAN BAKE.

2. Using the temperature selector, set the oven to 180°C

and heat for approximately 30 minutes. Make sure

your room is well ventilated during this time.

Set!

Installing the oven accessories

1. Install telescopic slides to the side racks

(EVE614 only). Refer to installation guide

supplied with oven slides.

2. Insert side racks

1. Insert the rear peg into the rear access hole,

ensuring peg is fully inserted.

2. Then insert the front peg into the front access

hole and push in ﬁrmly.

Set the time

You must set the time before you can operate your oven.

1. After the appliance has been electrically connected,

‘12:00’ will be displayed and the clock icon will ﬂash.

2. Use the timer + and - to set the time.

3. 5 seconds after the last change, the clock icon will

disappear, conﬁrming the time has been adjusted.

NOTE: The clock has a 24 hour display

3. To ﬁt a shelf:

1. Locate the detents on the side wires

of the shelf, these should be towards

the oven back wall. See image below.

2 Align the shelf to the same rail

positions on both sides and slide

the shelf in between the guide rails.

3. When fully inserted the shelf should not

interfere with the closed oven door.

Detent

4. Fit shelf to telescopic slides

(EVE614 only)

1. Push the shelf along the

top of the slide until it hits the

back post.

Back postShelf

2. Drop the front of the shelf onto the

slide ensuring it sits behind the front

post of the slide.

Front post Shelf

3. When fully inserted the shelf

should not interfere with the closed

oven door.

Go! You’re ready to use your new Electrolux appliance. A few tips from us:

Choose the right program for the best result

Refer to your full user manual for other oven functions.

Rapid Heat Cooking frozen pre-cooked foods such as savoury pastries, pizzas, frozen dinners,

meat pies and fruit pies

Fan Bake Cooking on multiple shelves at once, reheating foods and complete meals.

Bake +Steam

Adding steam to your baking program can lift your baking skills to a whole new level.

The Bake +Steam function uses a touch of steam to create a richer and glossier

colour, a crispier crust and soft delicious texture for your home-baked goods.

Bake/Pizza Baking a single tray of biscuits, scones, muﬃns, cakes, slices, casseroles, baked

puddings, roasts and delicate egg dishes.

Fan Grill

Large cuts of meat, which gives you a result that is similar to ‘rotisserie’ cooked meat.

When using ‘Fan Grill’ it is not necessary to turn food over during the cooking cycle.

Set temperature to 180°C. Fan grill with the oven door closed.

Grill Boost

Tender cuts of meat, steak, chops, sausages, ﬁsh, cheese toasties and other quick

cooking foods. For best results preheat your grill for 3 minutes to help seal in the

natural juices for a better ﬂavour. Grill with the oven door closed.

Remember to pre-heat each time

For best cooking results pre-heat the oven. Pre-heating allows the oven to reach the required temperature quickly

and eﬃciently as well as cook food at the correct temperature for the entire cook time. Recommended pre-heat

time is 30 mins for baking and 3 minutes for grilling.

Set your temperature

1. To set the temperature, turn the temperature selector in a clockwise direction to the desired setting.

2. An indicator light in the display will turn on and the oven will begin to heat.

3. Once the food is cooked, turn the temperature selector back in an anti-clockwise direction.

The desired cooking function must be selected before the oven will turn on.

Need more help?

To access your detailed user manual online,

simply scan the QR code on your smart phone.

Easily register your product with your smartphone for quick access

to all services and downloads

E_QSG_EVE602_EVE614_A4_Jun20 A20803401 Rev A

(Assy ANC A20803301 Rev A)

Electrolux Home Products Australia

telephone: 13 13 49

fax: 1800 350 067

email: customercare@electrolux.com.au

web: electrolux.com.au

Electrolux Home Products New Zealand

telephone: 0800 436 245

fax: 0800 225 088

email: customercare@electrolux.co.nz

web: electrolux.co.nz

Locate the label on the inside of your product door

Photograph the camera icon, including the 4 dots (

00000000000

)

Text image to 0488 446 622 (AUS only) or upload at electrolux.com.au/photoregister

Step 1

Step 2

Step 3

Easy register with your smartphone

1. Photograph the camera icon, including the 4 dots(

00000000000

2. Then text it to 0488 446 622 (AUS only) or upload it at

www.electrolux.com.au/photoregister

00000000000

EXAMPLE
