Öko Santo Super

2573-4 KA

Fridge

Operating Instructions

Dear customer,

Before placing your new refrigerator/freezer into operation please

read these operating instructions carefully. They contain important

information for safe use, for installation and for care of the appliance.

Please keep these operating instructions for future reference. Pass

them on to possible new owners of the appliance.

Notes which are important for your safety or for the proper functioning

of the appliance are stressed with a warning triangle and/or with

signal words (Warning!, Caution!, Attention!). Please observe the fol-

lowing carefully.

Supplementary information regarding operation and practical applica-

tions of the appliance appear after this symbol.

Tips and notes concerning economical and environmentally sound

use of the appliance are marked with the cloverleaf.

The operating instructions contain instructions for the correction of

possible malfunctions by the user in the section "What to do if ...". If

these instructions should not be sufficient, our customer service

department is always available to you.

Printed on paper manufactured with environmentally sound processes.

who thinks ecologically acts accordingly ...

Contents

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Appliance Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . 6

Disposal of old Appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remove transport safeguard . . . . . . . . . . . . . . . . . . . . . . . . . .6

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ....7

Your refrigerator needs air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Rear spacers . . ...................................... 8

Rehingeing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Prior to Initial Start–Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Control panel ....................................... 11

Starting up and temperature regulation .................11

Interior Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Storage shelves . . . . ..................................12

Door rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...........12

Fresh food refrigeration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Defrosting .........................................13

Switching off the appliance ........................... 14

Cleaning and Care ..................................14

Energy Saving Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

What to do if .......................................16

Correcting Malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Changing the light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Regulations, Standards, Guidelines . . . . . . . . . . . . . . . . . . . . 18

2222 061-71

Safety

The safety aspects of our refrigerators/freezers comply with accepted

technical standards and the GermanAppliance Safety Law. Neverthe-

less, we consider it our obligation to make you aware of the following

safety information:

Intended use

• The refrigerator is intended for use in the home. It is suitable for the

cooling. If the appliance is used for purposes other than those inten-

ded or used incorrectly, no liability can be accepted by the manu-

facturer for any damage that may be caused.

•Alterations or changes to the appliance are not permitted for reasons

of safety.

• If you use the refrigerator in a commercial application or forpurposes

other than the cooling, freezing or frozen storage of foods,please

observe all valid legal regulations for your application.

Prior to initial start–up

• Check the refrigerator for transport damage. Under no circumstance

should a damaged appliance be plugged in! In the event of damage,

please contact the vendor.

Refrigerant

The refrigerant isobutane (R600a) is contained within the refrigerant

circuit of the appliance, a natural gas with a high level of environ-

mental compatibility, which is nevertheless flammable.

• During transportation and installation of the appliance, be certain

that none of the components of the refrigerant circuit become dama-

ged.

• If the refrigerant circuit should become damaged:

– avoid open flames and sources of ignition;

– thoroughly ventilate the room in which the appliance is situated.

Safety of children

• Packaging (e.g. wraps, polystyrene) can be dangerous for children.

There is a risk of suffocation! Keep packaging material away from

children!

• Please make old appliances unusable prior to disposal. Pull out the

mains plug, cut off the mains cable, break or remove spring or bolt-

catches, if fitted. By doing this you ensure that children cannot lock

themselves in the fridge when playing (there is risk of suffocation!)or

get themselves into other dangerous situations.

• Often children cannot recognise the hazards present in household

appliances. It is therefore important that you ensure adequate

supervision and never let children play with the appliance!

Daily Operation

• Containers with flammable gases or liquids can leak at low tempe-

ratures. There is a risk of an explosion! Do not store any containers

with flammable materials such as, for example, spray cans, fire

extinguisher refill cartridges etc in the refrigerator/freezer.

• Bottles and cans must not be placed in the freezer compartment.

They can burst when the contents freeze, high carbonate content

drinks can even explode! Never store lemonade, juices, beer, wine,

sparkling wine etc. in the freezer compartment. Exception: high

alcohol content spirits can be stored in the freezer compartment.

• Do not put ice creams or ice cubes in the mouth immediately after

removal from the freezer compartment. Very cold ice can freeze to

the lips or tongue and cause injury.

• Do not touch frozen food with wet hands. Your hands could freeze

to the food.

• Do not operate any electrical appliances in the refrigerator/freezer

(e.g. electric ice cream makers, mixers etc.).

• Before cleaning the appliance, always switch off the appliance and

unplug it, or pull the house fuse or switch off the circuit breaker.

• When unplugging always pull the plug from the mains socket, do not

pull on the cable.

In case of malfunction

• If the a malfunction occurs on the appliance, please look first in the

"What to do if ..." section of these instructions. If the information

given there does not help, please do not perform any further repairs

yourself.

• Refrigerators/freezers may only be repaired by qualified service

engineers. Improper repairs can give rise to significant hazards. If

your appliance needs repairing, please contact your specialist dea-

ler or our Customer Service.

Disposal

Appliance Packaging Information

All materials are environmentally sound! They can be dumped or bur-

ned at an incinerating plant without danger!

About the materials: The plastics can be recycled and are identified

as follows:

>PE< for polyethylene, e.g. the outer covering and the bags in the

interior.

>PS< for polystyrene foam, e.g. the pads, which are all free of chlo-

rofluorocarbon.

The carton parts are made from recycled paper and should be dispo-

sed of at a waste-paper recycling collection location.

Disposal of old Appliances

For environmental reasons, refrigeration appliances must be dispo-

sed of properly. This applies to your old appliance, and - at the end of

its service life - for your new appliance as well.

Warning! Before disposing of old appliances make them inoperable.

Remove plug from mains, sever the power cable, remove or destroy

any snap or latch closures. This eliminates the danger that playing

children lock themselves into the appliance (danger of suffocation!) or

place themselves into other life-endangering situations.

Disposal:

• The appliance may not be disposed of with domestic waste or bulky

refuse.

• The refrigerant circuit, especially the heat exchanger at the back of

the appliance, may not be damaged.

• Information concerning collection schedules or locations can be

obtained from the local disposal authorities or town hall.

Remove transport safeguard

The appliance and the interior fittings are protected for transport.

• Remove all adhesive tape and packing pieces from the interior of

the appliance.

You can remove any remnants of adhesive using white spirit.

Installation

Installation Location

The appliance should be set up in a well ventilated, dry room.

Energy use is affected by the ambient temperature. The appliance

should therefore

– not be exposed to direct sunlight;

– not be installed next to radiators, cookers or other sources of heat;

– only be installed at a location whose ambient temperature corre-

sponds to the climate classification, for which the appliance is desi-

gned.

The climate classification can be found on the serial plate, which is

located at the left on the inside of the appliance.

The following table shows which ambient temperature is correct for

each climate classification: each climate classification:

Climate classification ffor an ambient temperature of

SN +10 bis +32 °C

N +16 bis +32 °C

ST +18 bis +38 °C

T +18 bis +43 °C

If installation next to a source of heat is unavoidable, the following

minimum clearances must be maintained at the sides of the applian-

ce:

– for electric cookers 3 cm;

– for oil and coal fired ranges 30 cm.

If these clearances cannot be maintained a heat insulating pad is

required between the cooker and the refrigeration appliance.

If the refrigeration appliance is installed next to another refrigerator or

freezer a clearance of 5 cm at the sides is required, in order to pre-

vent the formation of condensation on the outside of the appliance.

PR185

Your appliance needs air

For safety reasons, minimum ven-

tilationmust be as shown Fig.

Attention: keep ventilation ope-

nings clear of obstruction;

NP005

100 mm10 mm

10 mm

Rehingeing the door

The side at which the door opens can be changed from the right side

(factory adjustment) to the left side, if the installation site requires.

Warning! When changing the side at which the door opens, the

appliance may not be connected to the mains. Remove plug from the

mains beforehand.

Procced as follow:

1. Remove the clip-in ventilation grille

(D).

2. Remove the bottom hinge (E) by

unscrewing the two fixing screws.

3. Slide the bottom door off the centre

hinge (H).

Rear spacers

In the bag with the documentation,

there are two spacers which must

be fitted.

slacken the screws and insert the

spacer under the screw head, then

re-tighten the screws.

PR153

4. Remove the centre hinge and slide

the top door off pin (D); unscrew

pin (D) and refit it on the opposite

side.

5. Remove the two plugs, to reveal

the holes for the hinge pivots, and

remount them on the other side.

6. Refit the top door and the centre

hinge (H) on the opposite side.

7. Refit the bottom door.

8. Refit bottom hinge (E) on the

opposite side, using the two

screws previously removed.

9. Remove blanking cover (F) from

ventilation grille (D) by pushing it in

the direction of the arrow and refit

it on the opposite side.

10. Refit ventilation grille (D), clipping

it into place.

11. Unscrew the handle. Refit it on

opposite side after having pierced

the plugs with a punch. Cover the

holes left open with the plugs con-

tained in the documentation pack.

Attention:

After having reversed the opening

direction of the doors check that all

the screws are properly tightened

and that the magnetic seal adhe-

res to the cabinet. If the ambient

temperature is cold (i.e. in Winter),

the gasket may not fit perfectly to

the cabinet. in that case, wait for

the natural fitting of the gasket or

accelerate this process by heating

up the part involved with a normal

hairdrier.

PR24

PR228

D590

Prior to Initial Start–Up

• Please clean the appliance interior and all accessories prior to initial

start-up (see section: “Cleaning and Care”).

Electrical Connection

Any electrical work required to install this appliance should be carried

out by a qualified electrician or competent person.

WARNING – THIS APPLIANCE MUST BE EARTHED

The manufacturer declines any liability should these safety mea-

sures not be observed.

Before switching on, make sure the electricity supply voltage is the

same as that indicated on the appliance rating plate. The rating plate

is inside, on the left.

The appliance is supplied with a 13 amp plug fitted. In the event of

having to change the fuse in the plug supplied, a 13 ampASTA appro-

ved (BS 1362) fuse must be used.

Important!

The wires in the mains lead are coloured in accordance with the fol-

lowing code:

Green and Yellow Earth

Blue Neutral

Brown Live

As the colours of the wires in the mains lead of this appliance may not

correspond with the coloured markings indentifying the terminals in

your plug, proceed as follows:

1. The wire coloured green and yellow must be connected to the termi-

nal marked with the letter „E“ or by the earth symbol or coloured green

and yellow.

2. The wire coloured blue must be connected to the terminal „N“ or

coloured black.

3. The wire coloured brown must be connected to the terminal marked

„L“ or coloured red.

4. Upon completion there must be not cut, or stray strands of wire pre-

sent and the cord clamp must be secure over the outer sheat.

Warning! A cut-off plug inserted into a 13 amp socket is a serious

safety (shock) hazard. Ensure that the cut-off plug is disposed of

safely.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Electrolux Frigorifero

Electrolux

Electrolux RM 4185 Manuale operativo originale

Electrolux

Electrolux ENB3669 Manuale utente

Electrolux

Electrolux WRT18MP5AQM Manuale utente

Electrolux

Electrolux 102318 Manuale utente

Electrolux

Electrolux IK329SA Manuale utente

Electrolux

Electrolux U24089 ERH 3620 X Manuale utente

Electrolux

Electrolux ERB25291W Manuale utente

Electrolux

Electrolux LNT5MF36U0 Manuale utente

Electrolux

Electrolux SMART 726599 Manuale utente

Electrolux

Electrolux ERN31801 Manuale utente

Electrolux

Electrolux French Door Bottom Freezer Manuale utente

Electrolux

Electrolux ER 3110B Manuale utente

Electrolux

Electrolux ER 2522 B Guida rapida

Electrolux

Electrolux Refrigerator Manuale utente

Electrolux

Electrolux ERA 39375 W Manuale utente

Electrolux

Electrolux EN3855MFX Manuale utente

Electrolux

Electrolux ERB 34001W Manuale utente

Electrolux

Electrolux ERD052UBGW Manuale utente

Electrolux

Electrolux CARAVAN AES II RM 6505 Manuale utente

Electrolux

Electrolux ERCP3215AW Manuale utente

Electrolux

Electrolux ER 3300B Manuale utente

Electrolux

Electrolux ER 7659B Guida rapida

Electrolux

Electrolux FREEZER / REFRIGERATOR Manuale utente

Electrolux

Electrolux RM2012 Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente

Teledyne

Teledyne 6712FR and Istruzioni operative
