Electrolux concept counters

Refrigerators with upstand - 3 comp.

Electrolux Professional have designed and produced a complete range of refrigerated

tables, that combines the dual function of worktop and refrigerated table. This versatility

allows notable savings in space whilst offering functional and modular solutions to kitchen

requirements.

728294

• Height-adjustable feet.

• Internal and external

doors, front and side panels

and worktop in 304 AISI

stainless steel.

• Rounded internal corners

for ease of cleaning.

• Refrigerated compartment

designed to accommodate

GN 1/1 containers.

• Digital control panel.

• Suitable to operate in

ambient temperatures up to

+43°C. Temperature range:

-2/+10 °C.

• Forced air circulation for

rapid cooling and an even

temperature distribution.

• Drain outlet and automatic

evaporation of defrost water.

• Access to all components

from the front.

• In compliance with H

requirements.

• C.F.C. and H.C.F.C. free.

• High-density expanded

polyurethane foam 50 mm

in thickness with

cyclopenthane injection.

• Developed and produced

in ISO 9001 and ISO 14001

certified factory.

Electrolux concept counters

Refrigerators with upstand - 3 comp.

Internet: http://www.electrolux.com/foodservice

HBAC0902010-05-28Subject to change without notice

STRUCTURE TO SUPPORT 3 GRIDS(RIGHT+LEFT) 880047 880047 880047 880047

S/S STRUCTURE TO SUPPORT 6 GRIDS (R+L) 880140 880140 880140 880140

PRINTER FOR HACCP BASIC VERSION REFRIG. 881457 881457 881457 881457

LOCK KIT FOR REFRIGERATED TABLES 880130 880130 880130 880130

KIT INTEGRATED HACCP-DIG. REFR. (IR33) 880205 880205 880205 880205

KIT HACCP EKIS 922166 922166 922166 922166

KIT DOOR REVERSIBILITY FOR REF.TABLES 880046 880046 880046 880046

KIT 4 WHEELS (2 W/BRAKE)+4 (40MM)SPACERS 880025 880025 880025 880025

KIT 2 S/S GRIDS GN1/1 FOR REFRIG.TABLES 880139 880139 880139 880139

DRAWER KIT-1/3+2/3 (BOTTLES)-REF.TABLES 880126 880126 880126 880126

3x1/3 DRAWER KIT FOR REFRIGERATED TABLES 880115 880115 880115 880115

2x½ DRAWER KIT FOR REFRIGERATED TABLES 880118 880118 880118 880118

ACCESSORIES

1/1 GN GREY "RILSAN" GRID 3 2 1

INCLUDED ACCESSORIES

Power supply - V, phases, Hz 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50

Net weight - kg. 143 147 151 154

installed-electric 0.34 0.34 0.34 0.34

Power - kW

at evaporation temperature - °C -20 -20 -20 -20

Refrigerant power

Refrigeration power - W 343 343 343 343

Refrigerant quantity - g. 150 150 150 150

Refrigerant type R404a R404a R404a R404a

N° defrost in 24 hrs. 4/20' 4/20 4/20 4/20

Compressor power - HP 1/4 1/4 1/4 1/4

Door hinges 1 Left+1 Right Left

N° and type of door 3 2 1

N° of drawers 2x1/2 4x1/2 6x1/2

Min/Max internal humidity - % 50 50 50 50

Upstand ● ● ● ●

height 543 543 543 543

depth 580 580 580 580

Internal dimensions - mm

height 950 950 950 950

depth/with open doors 700, 1102 700, 1102 700, 1102 700, 1102

width 1721 1721 1721 1721

External dimensions - mm

Cooling unit Built-In Built-In Built-In Built-In

Gross capacity (D.I.N. 8952) - l. 420 420 420 420

Operating mode Ventilated Ventilated Ventilated Ventilated

Operating temperature - min/max °C -2/10 -2/10 -2/10 -2/10

TECHNICAL DATA

HB3PU

728510

HB2P2CU

728532

HB1P4CU

728541

HB6CU

728542

Electrolux concept counters

Refrigerators with upstand - 3 comp.

Internet: http://www.electrolux.com/foodservice

HBAC0902010-05-28Subject to change without notice

EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50

D - Water drain 18mm 18mm 18mm 18mm

LEGEND

HB3PU

728510

HB2P2CU

728532

HB1P4CU

728541

HB6CU

728542

728510, 728542, 728541, 728532
