UUsseerrMMaannuuaall

ERC 39392 S

Fridge

electrolux 3

Welcome to the world of Electrolux

You’ve chosen a first class product from Electrolux, which hopefully will provide

you with lots of pleasure in the future. Electrolux ambition is to offer a wide variety

of quality products that would make your life even more comfortable. You can look

at some examples on the cover in this manual. But now it’s time to study this

manual and start using and enjoying the benefits from your new machine. We

promise that it’ll make your life a little easier. Good luck!

4electrolux

The following symbols are used in this manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

General information and tips

Environmental information

The symbol on the product or on its packaging indicates that this product

may not be treated as household waste. Instead it should be taken to the

appropriate collection point for the recycling of electrical and electronic equipment.

By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could

otherwise be caused by inappropriate waste handling of this product. For more

detailed information about recycling of this product, please contact your council,

your household waste disposal service or the shop where you purchased the

product.

electrolux 5

CONTENTS

Safety IInformation 6

Use 99

Cleaning the interior 9

Control panel 9

Display 10

First switch on 10

Switching off 10

Temperature regulation 10

Functions menu 11

Ambient Temperature Function 11

Child Lock Function 11

Shopping Function 11

Eco Mode Function 12

Use of the fridge Compartment 12

Holiday Function “H” 12

Fresh food refrigeration 12

Movable shelves 13

Positioning the door shelves 13

Bottle rack 13

Health aand ssafety gguidelines 14

Maintenance 115

Internal cleaning 15

External cleaning 15

When the appliance is not in use 15

Defrosting 16

Interior light 16

Something nnot wworking 17

Technical sspecifications 118

Installation 19

Positioning 19

Rear spacers 20

Electrical connection 20

Shelf holders 21

Door reversibility 22

Guarantee/Customer SService 24

Service aand SSpare PParts 24

Customer CCare 25

European GGuarantee 26

www.electrolux.com 27

6electrolux

SAFETY INFORMATION

It is most important that this

instruction book should be retained

with the appliance for future reference.

Should the appliance be sold or

transferred to another owner, or

should you move house and leave the

appliance, always ensure that the

book is supplied with the appliance in

order that the new owner can be

acquainted with the functioning of the

appliance and the relevant warnings.

If this appliance featuring magnetic

door seals is to replace an older

appliance having a spring lock (latch)

on the door or lid, be sure to make

that spring lock unusable before you

discard the old appliance. This will

prevent it from becoming a death-trap

for a child.

These warnings are provided in the

interest of safety. You must read them

carefully before installing or using the

appliance.

General Safety

• This appliance is designed to be

operated by adults. Children

should not be allowed to tamper

with the controls or play with the

product.

• It is dangerous to alter the

specifications or modify this

product in any way.

• Before any cleaning or

maintenance work is carried out,

be sure to switch off and unplug

the appliance.

• This appliance is heavy. Care

should be taken when moving it

• Ice lollies can cause frost burns if

consumed straight from the

appliance.

••Take uutmost ccare wwhen hhandling

your aappliance ssoaasnnot ttoccause

any ddamages ttotthe ccooling uunit

with cconsequent ppossible ffluid

leakages.

• The aappliance mmust nnot bbellocated

close ttorradiators oorggas ccookers.

• Avoid pprolonged eexposure ooftthe

appliance ttoddirect ssunlight.

• There mmust bbeaadequate vventilation

round tthe bback ooftthe aappliance

and aany ddamage ttotthe rrefrigerant

circuit mmust bbeaavoided.

• For ffreezers oonly ((except bbuilt-iin

models): aaniideal llocation iistthe

cellar oorbbasement.

• Do nnot uuse oother eelectrical

appliances ((such aasiice ccream

makers) iinside oofrrefrigerating

appliances.

Service/Repair

• Any electrical work required to

install this appliance should be

carried out by a qualified electrician

or competent person

• This product should be serviced by

an authorized Service Centre, and

only genuine spare parts should be

used.

• Under no circumstances should

you attempt to repair the appliance

yourself. Repairs carried out by

inexperienced persons may cause

injury or more serious

malfunctioning. Refer to your local

electrolux 7

Service Centre, and always insist

on genuine spare parts.

• This appliance contains

hydrocarbons in its cooling unit;

maintenance and recharging must

therefore only be carried out by

authorized technicians.

Use

• The domestic refrigerators and

freezers are designed to be used

specifically for the storage of edible

foodstuffs only.

• Best performance is obtained with

ambient temperature between

+18°C and +43°C (class T); +18°C

and +38°C (class ST); +16°C and

+32°C (class N); +10°C and +32°C

(class SN). The class of your

appliance is shown on its rating

plate.

Warning: when the ambient

temperature is not included within

the range indicated for the class of

this appliance, the following

instructions must be observed:

when the ambient temperature

drops below the minimum level, the

storage temperature in the freezer

compartment cannot be

guaranteed; therefore it is advisable

to use the food stored as soon as

possible.

• Frozen food must not be re-frozen

once it has been thawed out.

• Manufacturers’ storage

recommendations should be strictly

adhered to. Refer to relevant

instructions.

• The inner lining of the appliance

consists of channels through which

the refrigerant passes. If these

should be punctured this would

damage the appliance beyond

repair and cause food loss. DO

NOT USE SHARP INSTRUMENTS

to scrape off frost or ice. Frost may

be removed by using the scraper

provided. Under no circumstances

should solid ice be forced off the

liner. Solid ice should be allowed to

thaw when defrosting the

appliance.

• Do not place carbonated or fizzy

drinks in the freezer as it creates

pressure on the container, which

may cause it to explode, resulting

in damage to the appliance.Do not

use a mechanical device or any

artificial means to speed up the

thawing process other than those

recommended by the

manufacturer. Never use metal

objects for cleaning your appliance

as it may get damaged.

Installation

• During normal operation, the

condenser and compressor at the

back of the appliance heat up

considerably. For safety reasons,

minimum ventilation must be as

shown in the instructions.

Attention: kkeep vventilation oopenings

clear oofoobstruction.

• Care must be taken to ensure that

the appliance does not stand on

the electrical supply cable.

8electrolux

Important: if the supply cord is

damaged, it must be replaced by a

special cord or assembly available

from the manufacturer or its service

agent.

• If the appliance is transported

horizontally, it is possible that the

oil contained in the compressor

flows in the refrigerant circuit. It is

advisable to wait at least two hours

before connecting the appliance to

allow the oil to flow back in the

compressor.

• There are working parts in this

product which heat up. Always

ensure that there is adequate

ventilation as a failure to do this will

result in component failure and

possible food loss. See installation

instructions.

• Parts which heat up should not be

exposed. Wherever possible the

back of the product should be

against a wall.

Environment

Protection

This aappliance ddoes nnot ccontain

gasses wwhich ccould ddamage tthe oozone

layer, iineeither iits rrefrigerant ccircuit oor

insulation mmaterials. TThe aappliance

should nnot bbeddiscarded ttogether wwith

the uurban rrefuse aand rrubbish. AAvoid

damaging tthe ccooling uunit, eespecially

at tthe rrear nnear tthe hheat eexchanger.

Information oonyyour llocal ddisposal ssites

may bbeoobtained ffrom mmunicipal

authorities. TThe mmaterials uused oontthis

appliance mmarked bbytthe ssymbol

are rrecyclable.

electrolux 9

USE

Cleaning the interior

Before using the appliance for the first

time, wash the interior and all internal

accessories with luke-warm water and

some neutral soap so as to remove

the typical smell of a brand-new

product, then dry thoroughly.

Do nnot uuse ddetergents oor

abrasive ppowders, aastthese wwill

damage tthe ffinish.

Control panel

ABCDE

A - Appliance button ON/OFF

B - Temperature regulation button

C - Temperature and function indicator

D - Function button

E - Confirmation button

10 electrolux

Display

If on the temperature indicated is

the ambient temperature

Positive Temperature indicator

Temperature indicator

If on the Child Lock function is on

If on the Shopping function is on

If on the Eco Mode function is on

First switch on

After plugging the plug into the power

outlet, if the display is not illuminated,

press key (A), to turn the appliance on.

For a correct storage of the food select

the Eco Mode function that guarantee

the following temperature is set:

+5°C in the fridge

• To select a different temperature

see "Temperature regulation".

Important

If the door remains ajar for some

minutes, the internal

lighting will turn off automatically; after

this, the lighting function will be reset

by closing and opening the door itself.

Switching off

The appliance is shut off by pressing

key (A) for more than 1 second. During

this, a countdown of the temperature

from -3 -2 -1 will be shown.

Temperature regulation

The temperature may be regulated by

pressing the key B.

By pressing the key B the current

temperature setting flashes on the

indicator and by pressing the key B

again it is possible to change it.

You can confirm the choice of the

temperature either by pressing the key

E, (you will hear the buzzer) or by

waiting for some seconds (you will not

hear the buzzer).

Then the indicator shows again the

inside compartment temperature.

The newly selected-temperature must

be reached after 24 hours.

After a long period out of use it is not

necessary to set the temperature again

because it remains stored.

Indice

Altri manuali Electrolux Frigorifero

Electrolux

Electrolux ER7620C Manuale utente

Electrolux

Electrolux IK329SAR Manuale utente

Electrolux

Electrolux TC15212 Manuale utente

Electrolux

Electrolux E30EW75GPS - Icon 30" Professional Series Single Electric Wall... Foglio di istruzioni

Electrolux

Electrolux EI24RD65HS - 6.0 cu. Ft. Double Drawer... Manuale di servizio

Electrolux

Electrolux A01061201 Manuale utente

Electrolux

Electrolux ER 7926B Manuale utente

Electrolux

Electrolux LNC7ME32X1 Guida alla configurazione

Electrolux

Electrolux Icon E23CS78GSS Manuale utente

Electrolux

Electrolux ERD176C Manuale utente

Electrolux

Electrolux LTB1AE24U0 Manuale utente

Electrolux

Electrolux LTB1AF28U0 Manuale utente

Electrolux

Electrolux EI28BS36IS Istruzioni per il montaggio

Electrolux

Electrolux TR70/41 Istruzioni operative

Electrolux

Electrolux LNT7ME32M2 Manuale utente

Electrolux

Electrolux ER 7926B Manuale utente

Electrolux

Electrolux ER 7549B Guida rapida

Electrolux

Electrolux 253.72242201 Manuale

Electrolux

Electrolux TK 13712 Manuale utente

Electrolux

Electrolux RCB732E3MB Manuale utente

Electrolux

Electrolux EI23BC36I S Manuale del proprietario

Electrolux

Electrolux ERN1400AOW Manuale utente

Electrolux

Electrolux ER 7626 B Manuale utente

Electrolux

Electrolux ERN 2930 Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente

Teledyne

Teledyne 6712FR and Istruzioni operative
