Electrolux DBGL1032CN Manuale utente

DBGL1032CN

DBGL5432CN

DBGL7732CN

KFG726R

KFG726X

LFG716W

LFG716X

LFG719R

LFG719W

LFG719X

EN Cooker Hood User Manual

CONTENTS

1. SAFETY INFORMATION AND INSTALLATION................................................ 2

2. PRODUCT DESCRIPTION................................................................................ 3

3. DAILY USE......................................................................................................... 3

4. CARE AND CLEANING......................................................................................4

5. ENVIRONMENTAL CONCERNS....................................................................... 6

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.electrolux.com/support

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

1. SAFETY INFORMATION AND INSTALLATION

WARNING!

Refer to the separate

Installation Instructions

booklet for Safety

Information and Installation.

Read carefully the Safety

chapters before any use or

maintenance of the

appliance.

www.electrolux.com2

2. PRODUCT DESCRIPTION

2.1 Control panel overview

2 3 4 5 6 71

Function Description

1Hob²Hood Indicator of the function to control hood from hob.

2Lamp Turns the lights on and off.

3First speed / Off The motor switches to first speed level. Second

press turns off the appliance.

4Second speed The motor switches to second speed level.

5Third speed The motor switches to third speed level.

6Maximum speed The motor switches to maximum speed level.

7Filter notification Reminds to change or clean the charcoal filter and

clean the grease filter.

3. DAILY USE

3.1 Using the hood

Check the recommended speed

according to the table below.

While heating up food, cooking with covered pots.

While cooking with covered pots on multiple cook‐

ing zones or burners, gentle frying.

While boiling, frying big quantities of food without

a lid, cooking on multiple cooking zones or burn‐

ers.

While boiling, frying big quantities of food without

a lid, big humidity. The hood operates on maxi‐

mum speed. After 6 minutes the appliance returns

to previous setting.

It is recommended to leave

the hood operating for

approximately 15 minutes

after cooking.

To operate the hood:

1. Press the first speed button to

switch on the appliance.

ENGLISH 3

2. If needed, press the light button to

illuminate the cooking surface.

3. If needed, change the speed by

pressing the desired button.

To turn off the appliance press the first

speed button again.

3.2 Hob²Hood function

It is an automatic function which

connects the hob with a hood. Both the

hob and the hood have an infrared signal

communicator. Speed of the fan is

defined automatically on basis of mode

setting and temperature of the hottest

cookware on the hob. You can also

operate the fan using the hob manually.

The function can be activated from panel

of the hob.

For more information how to

use the function refer to the

hob user manual.

3.3 Filter notification

Filter alarm reminds to change or clean

the charcoal filter and clean the grease

filter. The filter indicator is turned on

for 30 seconds if the grease filter must

be cleaned. The filter indicator flashes

for 30 seconds if the charcoal filter must

be replaced or cleaned.

Refer to cleaning the grease

filter in care and cleaning

chapter.

Refer to cleaning the

charcoal filter or replacing

the charcoal filter in care and

cleaning chapter.

To reset the function press the button

for 3 seconds.

To activate or deactivate function:

1. To activate function press the button

for 3 seconds.

If the function is activated, the indicator

flashes two times.

2. To deactivate function press the

button for 3 seconds.

If the function is deactivated, the

indicator flashes ones.

3.4 Remote-control

The appliance can be controlled with a

remote-control. Visit local supplier to buy

the remote-control.

The connection is originally enabled.

To connect or disconnect remote-

control:

1. Switch off the appliance.

2. Press the for 3 seconds.

The indicator on control panel flashes

twice if function is enabled and once if

disabled.

4. CARE AND CLEANING

4.1 Notes on cleaning

Cleaning

Agents

Do not use abrasive detergents and brushes.

Clean the surface of the appliance with a soft cloth with warm water

and a mild detergent.

After cooking some parts of appliance can get hot. To avoid stains

appliance must be cooled down and dried with clean cloth or paper

towels.

Clean stains with a mild detergent.

www.electrolux.com4

Keep the hood

clean

Clean the appliance and grease filters each month. Clean the inte‐

rior and grease filters carefully from fat. Fat accumulation or other

residue may cause fire.

Follow the instructions for cleaning the accessories when filter noti‐

fication is on. Refer to Filter notification in daily use chapter.

Grease filters can be washed in a dishwasher.

The dishwasher must be set to a low temperature and a short cy‐

cle. The grease filter may discolour, it has no influence on the per‐

formance of the appliance.

Charcoal filter

The time of saturation of the charcoal filter varies depending on the

type of cooking and the regularity of cleaning the grease filter. The

activated charcoal filter is not washable, cannot be regenerated

and must be replaced approximately every 4/6 months of operation,

or more frequently for particularly heavy usage.

4.2 Cleaning the grease filter

Filters are mounted with the use of clips

and pins on the opposite side.

To clean the filter:

1. Press the handle of the mounting clip

on the filter panel underneath the

hood (1).

2. Slightly tilt the front of the filter

downwards (2), then pull.

Repeat the first two steps for all filters.

3. Clean the filters using a sponge with

non abrasive detergents or in a

dishwasher.

The dishwasher must be set

to a low temperature and a

short cycle. The grease filter

may discolour, it has no

influence on the

performance of the

appliance.

4. To mount the filters back follow the

first two steps in reverse order.

Repeat the steps for all filters if

applicable.

4.3 Replacing the charcoal filter

WARNING!

The charcoal filter is non-

washable!

To replace the filter:

1. Remove the grease filters from the

appliance.

Refer to "Cleaning the grease filter" in

this chapter.

2. Press the front edge in slot towards

the bottom part of the filter. Slightly

tilt the front of the filter downwards.

3. To install a new filter, perform the

same steps in reverse order.

In any case, it is necessary to replace

the filters at least every four months.

ENGLISH 5

4.4 Replacing the lamp

This appliance is supplied with a LED

lamp and separate control gear (LED

driver). These parts can be replaced by a

technician only. In case of any

malfunction refer to "Service" in the

"Safety Instructions" chapter.

5. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol .

Put the packaging in relevant containers

to recycle it. Help protect the

environment and human health by

recycling waste of electrical and

electronic appliances. Do not dispose of

appliances marked with the symbol

with the household waste. Return the

product to your local recycling facility or

contact your municipal office.

www.electrolux.com6

www.electrolux.com/shop

867351952-B-472022
