Elite Screens QuickFold Q100V Manuale utente

059 www.elitescreens.com

Manual ScreensElectric ScreensFixed Frame ScreensQuickFold Series

001

www.elitescreens.com

Manual Screens Electric Screens Fixed Frame Screens QuickFold Series

QuickFold Series

• Portable Presentation Screen for Pro

• QuickFold Portable Presentation Screen

• Strong, lightweight and portable folding aluminum

fixed-frame screen for multi-media conference/classroom

presentations

• Standard Matte White (Gain 1.1) screen material

• Optional rear projection screen material (Gain 2.2)

• Sealed edge detachable frame design with material

snap button attachments and corner pull cords to

extend product life with prolonged use

• Easy setup and teardown design with no tools required

• Adjustable frame height can be raised or lowered at

8" increments for various presentations

• Lightweight and durable aluminum traveling case is

wheeled for easy transport, storage and shipping for

tradeshows and traveling presentations

• 150" plus-sized models come with AT legs for additional

support while larger 180" & 200" models include SAT

heavy support buttresses as well

• Available in 72" to 200" sizes in a 4:3 aspect ratio

• Two year Manufacturer’s parts & labor warranty

Standard AT Legs come with 150" and larger

models. Additional SAT buttresses for 180" and

200" also included.

001 www.elitescreens.com

Manual ScreensElectric ScreensFixed Frame ScreensQuickFold Series

060

www.elitescreens.com

Manual Screens Electric Screens Fixed Frame Screens QuickFold Series

Locking mechanism on the metal

storage case ensures safety

during the storage and shipping

Strong Corner-Guard provides

additional protection during

transport and storage

Patented aluminum frame connections ensure

structural integrity with constant use.

Choose either CineWhite Front Projection or our new Wraith Veil Rear Projection Material

Light weight and durable

aluminum traveling case is

wheeled for easy transport,

storage and shipping

061 www.elitescreens.com

Manual ScreensElectric ScreensFixed Frame ScreensQuickFold Series

001

www.elitescreens.com

Manual Screens Electric Screens Fixed Frame Screens QuickFold Series

QuickFold Series

• Portable Presentation Screen for Pro

• QuickFold Portable Presentation Screen

See what the Experts said about CineWhite & CineGrey Material

“I found that it had a decent reflectivity to it, but didnít suffer too much from hot spotting (which obviously you would expect

from a lower gain screen), nor did it have any sparkles or other anomalies to it. Elite certainly has a good idea here. Good

performance, good build quality, and good features in a screen, for a lower price point.

AV Science, NY

By comparison, the Firehawk®screen tends to reject

ambient light from the side, a little better than the

ezFrame by Elite. (All's fair - an equivilent Firehawk fixed

wall projector screen is much over double the price. Color

was virtually identical, but yellows did appear just a touch

stronger than on the Firehawk®. This was very close and

not an issue. Overall color was very good.with a 100"

16:9 Elite ezFrame screen selling for about half of a

Da-Lite Cinema Contour with ProTrim (their fancy flourish

border), and barely a 1/3 of a Stewart Luxus Deluxe, it

allows home theater people to own an attractive looking

fixed wall screen, with good performance, at a price that

simply isn't available from the larger established brands.

Art Feierman / Projectorreviews.com

Nominal View View View View Travel Travel Overall Overall Net Net Gain Screen AT Legs/SAT

Model Diagonal Height Width Height Width Case Dim. Height Height Wt. Wt. (Front/ Material Legs

(in) (in) (cm) (cm) Dim. (cm) (in) (cm) (lbs.) (Kgs) Rear)

Q72V 72" (4:3)" 43.25 58 109.9 147.3 49.5x10.4x11.8 125.7x26.4x30 56 142.2 56 25.4 1.1 / 2.2 CineWhite N/A

Q84V 84" (4:3)" 50 67 127.0 170.2 49.5x10.4x11.8 125.7x26.4x30 59 149.9 59 26.8 1.1 / 2.2 CineWhite N/A

Q100V 100" (4:3)" 60 80 152.4 203.2 49.5x10.4x11.8 125.7x26.4x30 62.3 158.2 62.3 28.3 1.1 / 2.2 CineWhite N/A

Q120V 120" (4:3)" 72 96 182.9 243.8 50.5x12.3x12.3 128x31x31 66 167.6 66 29.9 1.1 / 2.2 CineWhite N/A

Q150V 150" (4:3)" 90 120 228.6 304.8 52.3x12.3x12.3 133x31x31 77 195.6 77 34.9 1.1 / 2.2 CineWhite AT Legs / NA

Q180V 180" (4:3)" 108 144 274.3 365.8 63.8x12.4x15.3 162x32x39 108.25 275.0 108.25 49.1 1.1 / 2.2 CineWhite AT Legs / SAT Legs

Q200V 200" (4:3)" 120 160 304.8 406.4 63.8x12.4x15.3 162x32x39 108.24 274.9 108.24 49.1 1.1 / 2.2 CineWhite AT Legs / SAT Legs

QuickFold Portable Front Projection Screen, inlcudes Aluminum Traveling Wheel Case
