Elmo QNW4000 Manuale utente

Visualizing technology since 1921

New Weather-Resistant CCD color camera with

the surpassing features including;

QNW4000

Weather-Resistant Day & Night Color Camera

Weather-resistant camera housing

Built-in vari-focal full auto iris lens (f=2.8 5.8mm) for easy set up

New mechanical Day/Night function : Color in day, B&W at night for

24-hour viewing

480TV lines horizontal-resolution

Backlight & white balance controls



PROFILE

All dimensions in mm (inches)

ELMO CO., LTD.

Additional technical information is available from any of the following subsidiary companies;

Printed in Japan(S)10/2002

PRINTED ON RECYCLED PAPER

6-14, Meizen-cho, Mizuho-ku,

Nagoya, 467-8567 Japan

E-mail:[email protected]

75(3.0")

84(3.3")

230(9.1")

Note: Design and specifications are subject to change without prior notice.

Dimensions and weight are approximate.

SPECIFICATIONS

OPTION

AC24V 10%, 60Hz

Approx. 5.0W

1/4" Color interline-transfer CCD

768(H) 494(V)

NTSC

NTSC 2:1 interlaced

Line-lock/Internal

480TVL(H), 350TVL(V)

More than 49dB

1 lx (F1.4) Day&Night control-OFF,Sens-Up-ON

0.1 lx (F1.4) Day&Night control-ON,Sens-Up-ON

Built-in

AT W

Provided (factory-set at OFF)

Provided (factory-set at ON)

1/4" Vari-focal lens(Built-in)

F=1.4, f=2.8 to 5.8mm

Provided(volume adjustment)

VBS 1.0Vp-p 750hm

VBS 1.0Vp-p 750hm RCA pin jack(Built-in)

84 75 200mm (3.3 3.0 9.1 inches)

1.2kg (2.6 lbs)

Power Source

Power Consumption

Pick-up Device

Effective Picture element

TV System

Scanning System

Sync.System

Resolution

S/N ratio

Minimum Subject Illumination

AGC

White Balance

Sense-up

Backlight control

Day&Night control

Lens

Auto Iris

Iris Level Adjustment

Video Output

Monitor Output

Dimensions

Weight

Shading cover SS-20 Code:9871

Distributed by

E02036

1/4" Weather-Resistant Day & Night Color Cameras QNW4000
