Elmo TNC4604 Manuale utente

Visualizingtechnologysince1921

TNC4604

COLOR CCD VIDEO CAMERA

(with an optional lens)

●0.7 lx high sensitivity and less-smear picture with the latest EXview HAD CCD

●480TVL(H) of high resolution

●50dB signal to noise ratio

●Advanced DSP circuitry

●1/100,000 sec. Maximum shutter speed

●Easy back focus adjustment

●Built-in lsolation, AES, BLC, Selectable WB

●Camera accepts both 24VAC and 12VDC

●2.36×2.36×3.54" (60x60x90mm) compact body design

EXview HAD CCD is a registered trademark of Sony Corporation.

4000 SERIES COLOR CCD CAMERA WITH HIGH-RESOLUTION,

HIGH-SENSITIVITY, HIGH S/N, DUAL VOLTAGE,

COMPACT BODY AND EXview HAD CCD.

NEW

The CCD Revolution

EXview HAD CCD

Sensor

Thisproductismanufacturedat

theISO9002certifiedfactoryof

ELMOCO.,LTD.

Q00034

COLOR CCD VIDEO CAMERA TNC4604

6-14, Meizen-cho, Mizuho-ku,

Nagoya, 467-8567 Japan

E-mail:[email protected]

ELMO CO., LTD.

Additional technical information is available from any of the following subsidiary companies;

Printed in Japan(S)08/2000

SPECIFICATIONS

PROFILE

NOTE:・Designandspecificationsaresubjecttochangewithoutpriornotice.

・Dimensionsandweightareapproximate.



Powersource

Pick-updevice

Effectivepictureelement

Digitalsignalprocessing

TVsystem

Sync.system

Resolution



S/Nratio

Minimumillumination

AGCswitch

Whitebalance

Backlightcompensation

AESswitch

Irisslector

Lensmount

Videooutput

Lensbackadjustment

Dimensions

Mass/weight

AC24V/DC12V

1/3"ColorinterlinetransferEXviewHADCCD

768（H）x494（V）

Yes

NTSC

Line-lock/Internal

480TVlines（H）

350TVlines（V）

50dB

0.7lx（F1.2）

Built-in

Auto/Manual

Built-in

CS

BNC

Built-in

60x60x90mm（2.36x2.36x3.54"）

300g(0.66lbs)

Distributed by

Alldimensionsinmm(inches)

90（3.54"）

60（2.36"）
