Elo TouchSystems Entuitive 1925L Series Manuale utente

Elo Entuitive Touchmonitor

User Guide

19"LCD Desktop Touchmonitor

1925L Series

Revision A

P/N 008585

Elo TouchSystems, Inc.

1-800-ELOTOUCH

www.elotouch.com

iii

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means, including, but not

limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written

permission of Elo TouchSystems.

Disclaimer

The information in this document is subject to change without notice. Elo TouchSystems makes no

representations or warranties with respect to the contents hereof, and specifically disclaims any

implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves

the right to revise this publication and to make changes from time to time in the content hereof

without obligation of Elo TouchSystems to notify any person of such revisions or changes.

Trademark Acknowledgments

IntelliTouch, SecureTouch, AccuTouch, Entuitive, and MonitorMouse are trademarks of Elo

TouchSystems, Inc.

Other product names mentioned herein may be trademarks or registered trademarks of their

respective companies. Elo TouchSystems claims no interest in trademarks other than its own.

Chapter 1

Introduction 1

Precautions . . . . . . . . . . . . . . . . . . . . 1

About the Product . . . . . . . . . . . . . . . . . 1

Chapter 2

Installation and Setup 3

Unpacking Your Touchmonitor. . . . . . . . . . . 3

Product Overview . . . . . . . . . . . . . . . . . 4

Main Unit . . . . . . . . . . . . . . . . . . . . 4

Rear View . . . . . . . . . . . . . . . . . . . 4

Side View. . . . . . . . . . . . . . . . . . . . 5

Base Bottom View . . . . . . . . . . . . . . . 5

Touch Interface Connection . . . . . . . . . . . . 6

Serial/USB Connection. . . . . . . . . . . . . 6

Step 1-Routing the Cables . . . . . . . . . 8

Step 2-Connecting the Video Cables . . . . 9

Step 3-Connecting the Serial or USB

Touchscreen Cable . . . . . . . . . . . . 10

Step 4-Connecting the Speaker Cable . . 11

Step 5-Connecting the Power Cable . . . 11

Tilt Lock Function . . . . . . . . . . . . . 12

Optimizing the LCD Display . . . . . . . . . . . 12

VESA Mount on Your Touchmonitor. . . . . . . 13

Rear Mount Template . . . . . . . . . . . . 14

Front Mount Template . . . . . . . . . . . . 14

Front Mount for Horizontal Surface. . . . . . 15

Mounting the Base . . . . . . . . . . . . . . . 16

Security . . . . . . . . . . . . . . . . . . . . . 17

Installing the Driver Software . . . . . . . . . . 18

Installing the Serial Touch Driver for Windows

XP, Windows 2000, Me, 95/98 and NT 4.0 . 19

Installing the Serial Touch Driver for MS-DOS

and Windows 3.1 . . . . . . . . . . . . . 20

Installing the USB Touch Driver . . . . . . . 21

Installing the USB Touch Driver for Windows

XP, Windows 2000, Me and 98 . . . . . . 21

Chapter 3

Operation 23

About Touchmonitor Adjustments . . . . . . . . 23

Using the On-Screen Display (OSD) Menus . . 23

Side Bezel Buttons . . . . . . . . . . . . . . . 24

OSD Menu Function. . . . . . . . . . . . . . . 25

Chapter 4

Troubleshooting 27

Solutions to Common Problems . . . . . . . . 27

Appendix A

Native Resolution 29

Appendix B

Touchmonitor Safety 31

Care and Handling of Your Touchmonitor. . . . 32

Appendix C

Technical Specifications 33

Compatible Video Modes . . . . . . . . . . . . 33

Touchmonitor Specifications . . . . . . . . . . 34

19" LCD Touchmonitor (ET192XL-XXWA-1)

Dimensions . . . . . . . . . . . . . . . . . . 39

Regulatory Information 43

Warranty 47

Index 49

Table of Contents

1-1

CHAPTER

HAPTER

NTRODUCTION

Congratulations on your purchase of an Elo TouchSystems Entuitive

touchmonitor. Your new touchmonitor combines the reliable performance of

Elo’s touch technology with the latest advances in LCD display design. This

combination of features creates a natural flow of information between a user

and your touchmonitor.

Precautions

Follow all warnings, precautions and maintenance as recommended in this

user’s manual to maximize the life of your unit. See Appendix B for more

information on touchmonitor safety.

About the Product

Your LCD Desktop Touchmonitor is a 19" XGA TFT color display with the

following features:

• Direct analog RGB input

• 19" diagonal screen size

• 16.7 million displayable colors

• 1280 x 1024 resolution

• SXGA/XGA/ SVGA/ VGA/VESA/ Mac compatible

• 31kHz~80 horizontal scan

• 56~75Hz refresh rate

1-2 Elo Entuitive Touchmonitor User Guide

• Auto adjustment capability

• High quality full screen re-scaling

• Multilingual OSD menus in 11 languages: English, French, German,

Spanish, Italian, Swedish, Finnish, Danish, Portuguese, Dutch and Japanese

• Serial or USB touch interface (USB requires Windows 98, 2000, Me and

XP.)

• Built in speakers with volume control thorough OSD

• Patented touch technology of Elo TouchSystems

• VESA DDC 1/2B data communication

• VESA DPMS power saving

• Stand with minimum 95° angle of tilt.

• Cable management device

• VESA flat panel monitor physical mounting interface (M4x 100mm)

• OSD and Power button lockouts

• Wall mountable with existing stand

• VESA 100 mm M5 threaded holes on bottom of stand for securing to desk or

other surface, i.e. table top

• Cable strain reliefs for all cables

For full Product Specifications refer to Appendix C.

2-3

CHAPTER

HAPTER

NSTALLATION AND

ETUP

This chapter discusses how to install your LCD touchmonitor and how to install

Elo TouchSystems driver software.

Unpacking Your Touchmonitor

Check that the following 10 items are present and in good condition:

LCD Display

User Guide-on CD,

Quick Install Guide

Speaker Cable

Monitor power cable

European monitor power cable

Analog video cable

Serial cableUSB touchscreen cable

(US/Canada)

Software

Quick Install Guide

DVI-D video

cable

and software CD

RCA cable S-video cable

2-4 Elo Entuitive Touchmonitor User Guide

Product Overview

Main Unit

Rear View

LCD Display

Stand

Bottom cut-out

2-5

Side View

Base Bottom View

72.2

100.0

69.2

100.0

User Controls

Select

2-6 Elo Entuitive Touchmonitor User Guide

Touch Interface Connection

OTE

Your interface cables may have been pre-connected to your monitor at the factory.

Your touchmonitor comes with one of the following touchscreen connector

cables: Serial (RS-232) cable or USB cable. (For Windows 98, 2000, Me and

XP systems only.)

To set up this display, please refer to the following figures and procedures:

Serial/USB Connection

The following illustrations guide you step by step in connecting your

touchmonitor using a serial or USB cable connection.

CAUTION

Before connecting the cables to your touchmonitor and PC, be sure that the computer

and the touchmonitor are turned off.

Figure 2.1

Touchmonitor and Cables

European monitor

power cable

Monitor

power cable

(US/Canada)

Serial touchscreen

cable

Speaker cable

Video cable

(Analog, DVI-D, NTSC (RCA)

and S-video)

USB touchscreen cable
