eMachines 250 Manuale utente
eM250 Series
Quick Guide
eM250 Series
© 2009 All Rights Reserved
eMachines eM250 Series Quick Guide
Original Issue: 10/2009
Model number: ___________________________________
Serial number: ___________________________________
Date of purchase: ___________________________________
Place of purchase: ___________________________________
eMachines eM250 Series Notebook PC
1
Quick Guide
Federal Communications Commission
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
The following local Manufacturer /Importer is responsible for this declaration:
Product: Notebook PC
Brand: eMachines
Model Number: KAV60
Machine Type: eM250 series
Name of Responsible Party: Acer America Corporation
Address of Responsible Party: 333 West San Carlos St., San Jose
CA 95110, U. S. A.
Contact Person: Acer Representative
Phone No.: 1-254-298-4000
Fax No.: 1-254-298-4147
October 29, 2009
2
eM250 Series
CE Declaration of Conformity
We,
Acer Incorporated
8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan
Contact Person: Mr. Easy Lai, e-mail:easy_lai@acer.com.tw
And,
Acer Europe SA
Via Cantonale, Centro Galleria 2 6928 Manno Switzerland
Hereby declare that:
Product: Notebook Computer
Trade Name: eMachines
Model Number: KAV60
Machine Type: eM250 series
Is compliant with the essential requirements and other relevant provisions of the following EC directives, and that all the necessary steps have
been taken and are in force to assure that production units of the same product will continue comply with the requirements.
EMC Directive 2004/108/EC as attested by conformity with the following harmonized standards:
-. EN55022, AS/NZS CISPR22, Class B
-. EN55024
-. EN61000-3-2 Class D
-. EN61000-3-3
Low Voltage Directive 2006/95/EC as attested by conformity with the following harmonized standard:
-. EN60950-1
Council Decision 98/482/EC (CTR21):
(Applicable to product with pan- European single terminal connection to the Public Switched Telephone Network (PSTN).)
3
Quick Guide
RoHS Directive 2002/95/EC on the Restriction of the Use of certain Hazardous Substances in Electrical and Electronic Equipment
-. The maximum concentration values of the restricted substances by weight in homogenous material are:
Lead 0.1% Polybrominated Biphenyls (PBB’s) 0.1%
Mercury 0.1% Polybrominated Diphenyl Ethers (PBDE’s) 0.1%
Hexavalent Chromium 0.1% Cadmium 0.01%
Directive 2005/32/EC of the European Parliament and of the Council with regard to Eco-design Requirements.
R&TTE Directive 1999/5/EC as attested by conformity with the following harmonized standard:
• Article 3.1(a) Health and Safety
-. EN60950-1
-. EN62311
• Article 3.1(b) EMC
-. EN301 489-1
-. EN301 489-3 (Applicable to non-bluetooth wireless keyboard mouse set).
-. EN301 489-7
-. EN301 489-17
-. EN301 489-24
• Article 3.2 Spectrum Usages
-. EN300 440-2 (Applicable to non-bluetooth wireless keyboard mouse set).
-. EN300 328
-. EN301 511
-. EN301 893 (Applicable to 5GHz high performance RLAN).
-. EN301 908-1
-. EN301 908-2
Year to begin affixing CE marking 2009.
Easy Lai /Manager
Regulation Center, Acer Inc.
Oct. 29, 2009
Date
4
eM250 Series
Just for starters
1 2 3
4 5 6
3-1 3-2
3-3
2-1
2-2
Illustrations are for reference only. Actual product specifications may vary.
Ensure that the battery is properly
locked in place, as illustrated in
2-2.
5
Quick Guide
First things first
We would like to thank you for making an eMachines notebook your choice for meeting your mobile computing needs.
Your guides
To help you use your notebook, we have designed a set of guides*:
First off, the Quick Guide helps you get started with setting up your computer.
For more on how your computer can help you to be more productive, please refer to the eMachines System User Guide. This guide contains
detailed information on such subjects as system utilities, data recovery, expansion options and troubleshooting. In addition it contains
warranty information and the general regulations and safety notices for your notebook. It is available in Portable Document Format (PDF) and
comes preloaded on your notebook.
Note: Viewing the file requires Adobe Reader. If Adobe Reader is not installed on your computer, clicking on eMachines System User
Guide will run the Adobe Reader setup program first. Follow the instructions on the screen to complete the installation. For instructions
on how to use Adobe Reader, access the Help and Support menu.
* IMPORTANT NOTICE: Please note that the guides mentioned herein, whether in printed or electronic form, are for your reference
only and except as provided in the specific warranty information contained in the eMachines System User Guide nothing contained in
these guides shall constitute a representation or warranty by Acer with regard to the product you purchased. Acer expressly disclaims
any liability for errors contained in the guides.
6
eM250 Series
Network conguration
This guide will help you configure your LAN and wireless network settings to enable you to connect to the Internet.
Setting up LAN connection
Simply plug in the LAN cable to the Ethernet (RJ-45) port. Please refer to "Left view" on page 8 for the location of the Ethernet port.
Setting up a wireless connection
1. Please switch on the wireless LAN using the switch on the front of your notebook.
2. Click the icon on your system tray and choose the wireless access point you want to connect to.
Inserting a 3G SIM card (only for certain models)
Remove the battery and carefully insert a 3G SIM card into the 3G SIM card slot. Please refer to "Rear & base views" on page 9 for the location
of the 3G SIM card slot.
Quick Guide
7
Your eMachines notebook tour
After setting up your computer as illustrated in the Just for starters
section, let us show you around your new notebook.
Top view
# Icon Item Description
1Webcam Web camera for video communication
2Microphone Internal microphone for sound
recording.
3Display screen Also called Liquid-Crystal Display (LCD),
displays computer output.
4Bluetooth
communication
switch/indicator
Enables/disables the Bluetooth
function.
Indicates the status of Bluetooth
communication.
(only for certain models)
5Status indicators Light-Emitting Diodes (LED) that light
up to show the status of the computer's
functions and components.
6Keyboard For entering data into your computer.
7Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
8Power Indicator Indicates the computer's power status.
9Click buttons
(left, and right)
The left and right buttons function like
the left and right mouse buttons.
10 Wireless LAN/3G
communication
indicator
Indicates the status of Wireless LAN/3G
communication.
(only for certain models)
11 Power button/
indicator
Turns the computer on and off.
8
eM250 Series
Closed front view
# Icon Item Description
1Wireless
communication switch
Enables/disables the wireless function.
Left view
2Ethernet (RJ-45) port Connects to an Ethernet 10/100-based network.
3Ventilation slots and
cooling fan
Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the opening of
the fan.
4External display (VGA)
port
Connects to a display device (e.g., external
monitor, LCD projector).
5USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse).
6Microphone-in jack Accepts input from external microphones.
7Headphone/speaker/
line-out jack
Connects to line-out audio devices (e.g.,
speakers, headphones).
