ENLUH-302
SuperSpeed USB 3.0 PCIe Adapter
User’s Manual
1
ABOUT THIS MANUAL
This manual is designed for use with the SuperSpeed USB 3.0 PCIe Adapter. Information in this
document has been carefully checked for accuracy; however, no guarantee is given to the
correctness of the contents. The information in this document is subject to change without notice.
The manufacturer does not make any representations or warranties (implied or otherwise)
regarding the accuracy and completeness of this document and shall in no event be liable for
any loss of profit or any commercial damage, including but not limited to special, incidental,
consequential, or other damage.
SAFETY INSTRUCTIONS
Always read the safety instructions carefully:
Keep this User’s Manual for future reference.
Keep this equipment away from humidity.
If any of the following situations arises, get the equipment checked by a service technician:
The equipment has been exposed to moisture.
The equipment has been dropped and damaged.
The equipment has obvious sign of breakage.
The equipment has not been working well or you cannot get it to work according to the User’s
Manual.
COPYRIGHT
This document contains proprietary information protected by copyright. All right are reserved. No
part of this manual may be reproduced by any mechanical, electronic or other means, in any
form, without prior written permission of the manufacturer.
2
Table of Contents
1. INTRODUCTION ..................................................................................................................3
FEATURES..................................................................................................................................3
PACKAGE CONTENTS..................................................................................................................3
SYSTEM REQUIREMENTS.............................................................................................................3
2. INSTALLATION....................................................................................................................4
WINDOW 7/XP /WINDOWS VISTA ...............................................................................................4
3. HARDWARE INSTALLATION..............................................................................................9
4. INSTALLATION VERIFICATION........................................................................................11
WINDOW XP.............................................................................................................................11
WINDOW VISTA/WINDOWS 7.....................................................................................................12
5. SPECIFICATION ................................................................................................................13
6. REGULATORY COMPLIANCE ..........................................................................................13
FCC CONDITIONS.....................................................................................................................13
CE ..........................................................................................................................................13
3
1. Introduction
Encore Electronics’ SuperSpeed USB 3.0 PCIe adapter adds two USB 3.0 ports to your desktop
computer. The data transfer rate is at an amazing speed up to 5 Gbps — 10 times faster than
USB 2.0 (480 Mbps). Now, you can connect to the latest USB devices, such as external hard
drives, Blu-ray burners, external video adapters and camcorders.
The SuperSpeed USB 3.0 PCIe adapter is ideal for professionals who need high-performance
storage devices and people who enjoy watching HD videos. ENLUH-320 has advanced power
management feature. ENLUH-320 also is backward compatible with USB 2.0 and USB 1.1.
Features
Up to 10X Faster than USB 2.0
Less File Transfer Time
Backward Compatibility
More Efficient Power Usage
Better Device Stability with Increased Power Output
Package Contents
SuperSpeed USB 3.0 PCIe Adapter x 1
Quick Installation Guide x 1
Driver CD x 1
System Requirements
Windows-based (WindowsXP, WindowsVista, Windows7) computer with available
PCI express slot.
※Notice: Mac systems do not support this USB 3.0 2-port PCIe Adapter
4
2. Installation
You will need to install the driver for your SuperSpeed USB 3.0 PCIe adapter first. Please follow
the procedures as below.
Window 7 / XP / Windows Vista
1. Insert the provided Driver into CD-ROM. The following screen will show up and please
choose the correct product model, ENLUH-302.
5
2. Click “Driver Setup” to install driver, then press Next to continue.
6
3. After reading End-User License Agreement, please select “I accept the terms in the
License Agreement” and click Next.
4. Please click Browse to choose the Destination Folder. After that, please click Next.
7
5. Click Install to install NEC Electronics USB 3.0 Host Controller Driver.
6. It will take a while to install the Driver.
Notice: The Software Installation may pop-up during installation. Please click Continue
Anyway to complete the installation.
8
7. Please click Finish to complete the NEC Electronics USB 3.0 Host Controller Driver.
*Actual strings depend on your operation system. These screen shots are from
Windows XP and might vary slightly for each operation system.
Note: Please refer to next chapter to get more information about installing PCIe adapter.
9
3. Hardware Installation
1. Turn off your computer, unplug the power cord from your computer, and then remove the
cover of the computer.
2. Plug the PCIe adapter into the PCIe slot of your computer.
3. Plug the power connector from your computer's internal power supply to the
SuperSpeed 3.0 PCIe adapter.
4. Put the cover back, plug the power cord back to your computer, and then turn on your
computer.
For Window XP
1. When inserting SuperSpeed USB 3.0 2-Port PCIe Adapter into the slot, the following screen
will show up. Please choose “Yes, this time only” and click Next.
