Brief Operating Instructions

Micropilot FMR53, FMR54

Level radar

These Instructions are Brief Operating Instructions; they do not replace the

Operating Instructions included in the scope of supply.

For detailed information, refer to the Operating Instructions and other

documentation on the CD-ROM provided or visit "www.endress.com/

deviceviewer".

KA01101F/00/EN/01.12

71156033

Table of contents Micropilot FMR53, FMR54

2 Endress+Hauser

Table of contents

1 Important document information ............................... 3

1.1 Document conventions ........................................... 3

2 Basic safety instructions ...................................... 6

2.1 Requirements for the personnel ....................................... 6

2.2 Designated use ............................................... 6

2.3 Workplace safety .............................................. 7

2.4 Operational safety .............................................. 7

2.5 Product safety ................................................ 7

3 Product description ......................................... 8

3.1 Product design ............................................... 8

4 Incoming acceptance and product identification .................... 11

4.1 Incoming acceptance ........................................... 11

4.2 Product identification ........................................... 13

5 Storage, Transport ........................................ 14

5.1 Storage conditions ............................................. 14

5.2 Transport product to the measuring point .................................. 14

6 Installation .............................................. 15

6.1 Installation conditions ........................................... 15

6.2 Measuring conditions ........................................... 22

6.3 Installation in vessel (free space) ...................................... 24

6.4 Installation in stilling well ......................................... 30

6.5 Installation in bypass ............................................ 31

6.6 Vessels with heat insulation ........................................ 32

6.7 Turning the transmitter housing ...................................... 32

6.8 Turning the display module ......................................... 33

6.9 Post-installation check ........................................... 33

7 Electrical connection ....................................... 34

7.1 Connection conditions ........................................... 34

7.2 Connecting the measuring device ...................................... 52

7.3 Post-connection check ........................................... 55

8 Commissioning ........................................... 56

8.1 Display and operating module ....................................... 56

8.2 Operating menu .............................................. 58

8.3 Unlock the device ............................................. 59

8.4 Setting the operating language ....................................... 59

8.5 Configuration of a level measurement .................................... 60

8.6 User-specific applications .......................................... 62

Micropilot FMR53, FMR54 Important document information

Endress+Hauser 3

1 Important document information

1.1 Document conventions

1.1.1 Safety symbols

Symbol Meaning

DANGER

A0011189-EN

DANGER!

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

A0011190-EN

WARNING!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

A0011191-EN

CAUTION!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

A0011192-EN

NOTICE!

This symbol contains information on procedures and other facts which do not result in

personal injury.

1.1.2 Electrical symbols

Symbol Meaning

A0011197

Direct current

A terminal to which DC voltage is applied or through which direct current flows.

A0011198

Alternating current

A terminal to which alternating voltage is applied or through which alternating current flows.

A0017381

Direct current and alternating current

• A terminal to which alternating voltage or DC voltage is applied.

• A terminal through which alternating current or direct current flows.

A0011200

Ground connection

A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.

A0011199

Protective ground connection

A terminal which must be connected to ground prior to establishing any other connections.

A0011201

Equipotential connection

A connection that has to be connected to the plant grounding system: This may be a potential

equalization line or a star grounding system depending on national or company codes of practice.

Important document information Micropilot FMR53, FMR54

4 Endress+Hauser

1.1.3 Tool symbols

A0011219 A0011220 A0013442 A0011221 A0011222

Phillips head

screwdriver

Flat blade

screwdriver Torx screwdriver Allen key Hexagon wrench

1.1.4 Symbols for certain types of information

Symbol Meaning

A0011182

Allowed

Indicates procedures, processes or actions that are allowed.

A0011183

Preferred

Indicates procedures, processes or actions that are preferred.

A0011184

Forbidden

Indicates procedures, processes or actions that are forbidden.

A0011193

Tip

Indicates additional information.

A0011194

Reference to documentation

Refers to the corresponding device documentation.

A0011195

Reference to page

Refers to the corresponding page number.

A0011196

Reference to graphic

Refers to the corresponding graphic number and page number.

,…

Series of steps

ÃResult of a sequence of actions

1.1.5 Symbols in graphics

Symbol Meaning

1, 2, 3 ... Item numbers

,…

Series of steps

A, B, C, ... Views

A-A, B-B, C-C, ... Sections

Micropilot FMR53, FMR54 Important document information

Endress+Hauser 5

Symbol Meaning

A0011187

Hazardous area

Indicates a hazardous area.

A0011188

Safe area (non-hazardous area)

Indicates a non-hazardous location.

1.1.6 Symbols at the device

Symbol Meaning

Safety instructions

Observe the safety instructions contained in the associated Operating Instructions.

Temperature resistance of the connection cables

Specifies the minimum value of the temperature resistance of the connection cables.

Basic safety instructions Micropilot FMR53, FMR54

6 Endress+Hauser

2 Basic safety instructions

2.1 Requirements for the personnel

The personnel must fulfill the following requirements for its tasks:

►Trained, qualified specialists must have a relevant qualification for this specific function and

task

►Are authorized by the plant owner/operator

►Are familiar with federal/national regulations

►Before beginning work, the specialist staff must have read and understood the instructions

in the Operating Instructions and supplementary documentation as well as in the

certificates (depending on the application)

►Following instructions and basic conditions

2.2 Designated use

Application and measured materials

The measuring device described in these Operating Instructions is intended for the

continuous, contactless level measurement of liquids, pastes and sludge. Because of its

operating frequency of about 6 GHz, a maximum radiated pulsed power of 12.03 mW and an

average power output of 0.024 mW, the operation is completely harmless to humans and

animals.

Observing the limit values specified in the "Technical data" and listed in the Operating

Instructions and supplementary documentation, the measuring device may be used for the

following measurements only:

►Measured process variables: level, distance, signal strength

►Calculated process variables: Volume or mass in arbitrarily shaped vessels; flow through

measuring weirs or flumes (calculated from the level by the linearization functionality)

To ensure that the measuring device remains in proper condition for the operation time:

►Use the measuring device only for measured materials against which the process-wetted

materials are adequately resistant.

►Observe the limit values in "Technical data".

Incorrect use

The manufacturer is not liable for damage caused by improper or non-designated use.

Verification for borderline cases:

►For special measured materials and cleaning agents, Endress+Hauser is glad to provide

assistance in verifying the corrosion resistance of wetted materials, but does not accept any

warranty or liability.

Residual risk

The electronics housing and its built-in components such as display module, main electronics

module and I/O electronics module may heat to 80 °C (176 °F) during operation through

heat transfer from the process as well as power dissipation within the electronics. During

operation the sensor may assume a temperature near the temperature of the measured

material.

Danger of burns due to heated surfaces!

►For high process temperatures: Install protection against contact in order to prevent burns.

Micropilot FMR53, FMR54 Basic safety instructions

Endress+Hauser 7

2.3 Workplace safety

For work on and with the device:

►Wear the required personal protective equipment according to federal/national regulations.

2.4 Operational safety

Risk of injury.

►Operate the device in proper technical condition and fail-safe condition only.

►The operator is responsible for interference-free operation of the device.

Conversions to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers.

►If, despite this, modifications are required, consult with the manufacturer.

Repair

To ensure continued operational safety and reliability,

►Carry out repairs on the device only if they are expressly permitted.

►Observe federal/national regulations pertaining to repair of an electrical device.

►Use original spare parts and accessories from the manufacturer only.

Hazardous area

To eliminate a danger for persons or for the facility when the device is used in the hazardous

area (e.g. explosion protection, pressure vessel safety):

►Based on the nameplate, check whether the ordered device is permitted for the intended

use in the hazardous area.

►Observe the specifications in the separate supplementary documentation that is an integral

part of these Instructions.

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which

they are safe to operate.

It meets general safety standards and legal requirements. It also complies with the EC

directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms

this by affixing the CE mark to the device.

Product description Micropilot FMR53, FMR54

8 Endress+Hauser

3 Product description

3.1 Product design

3.1.1 Micropilot FMR53

1 1

2 5

4 4

A0016790

å 1 Design of the Micropilot FMR53 (6 GHz)

1Electronics housing

2 Flange

3 Inactive length

4 Active part of the antenna

5 Process connection (Thread)

Micropilot FMR53, FMR54 Product description

Endress+Hauser 9

3.1.2 Micropilot FMR54

1 1 1

4 2

3 5

A0016815

å 2 Design of the Micropilot FMR54 (6 GHz)

1Electronics housing

2 Flange

3 Horn antenna

4 High temperature antenna fitting

5 Planar antenna

Product description Micropilot FMR53, FMR54

10 Endress+Hauser

3.1.3 Electronics housing

Esc

–+E

123

A0012422

å 3 Design of the electronics housing

1Electronics compartment cover

2 Display module

3 Main electronics module

4 Cable glands (1 or 2, depending on instrument version)

5 Nameplate

6 I/O electronics module

7 Terminals (pluggable spring terminals)

8 Connection compartment cover

9 Grounding terminal

Altri manuali per Micropilot FMR53

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Endress+Hauser Radar

Endress+Hauser

Endress+Hauser Micropilot FMR67B Specifiche tecniche

Endress+Hauser

Endress+Hauser Levelflex FMP55 Specifiche tecniche

Endress+Hauser

Endress+Hauser PROFIBUS PA Micropilot FMR53 Specifiche tecniche

Endress+Hauser

Endress+Hauser Micropilot M FMR245 Manuale utente

Endress+Hauser

Endress+Hauser Micropilot FMR20 Manuale utente

Endress+Hauser

Endress+Hauser Levelflex FMP50 Istruzioni per l'installazione

Endress+Hauser

Endress+Hauser HART Micropilot S FMR533 Manuale utente

Endress+Hauser

Endress+Hauser Levelflex FMP56 Manuale

Endress+Hauser

Endress+Hauser Micropilot FMR67B PROFINET with Ethernet-APL Specifiche tecniche

Endress+Hauser

Endress+Hauser Micropilot FMR51 Manuale utente

Endress+Hauser

Endress+Hauser Micropilot FMR51 Manuale utente

Endress+Hauser

Endress+Hauser Micropilot FMR53 Specifiche tecniche

Endress+Hauser

Endress+Hauser Micropilot NMR81 Istruzioni per l’uso

Endress+Hauser

Endress+Hauser Levelflex FMP55 Manuale utente

Endress+Hauser

Endress+Hauser Micropilot M FMR245 Manuale utente

Endress+Hauser

Endress+Hauser Micropilot FMR67B Manuale utente

Endress+Hauser

Endress+Hauser Micropilot FMR63B Manuale utente

Endress+Hauser

Endress+Hauser Micropilot FMR51 Specifiche tecniche

Endress+Hauser

Endress+Hauser Levelflex FMP53 PROFIBUS PA Specifiche tecniche

Endress+Hauser

Endress+Hauser Micropilot FMR51 Manuale

Endress+Hauser

Endress+Hauser Levelflex FMP53 FOUNDATION Fieldbus Specifiche tecniche

Endress+Hauser

Endress+Hauser Levelflex FMP53 Manuale utente

Endress+Hauser

Endress+Hauser FOUNDATION Fieldbus Micropilot FMR51 Specifiche tecniche

Endress+Hauser

Endress+Hauser Micropilot FMR67B Manuale utente

Manuali Radar popolari di altre marche

SAW D2L

SAW D2L Valentine One Gen2 Manuale utente

Raymarine

Raymarine Raytheon R20X Manuale utente

Simrad

Simrad CA34 Manuale utente

ECHOMAX

ECHOMAX Active-X-Band Manuale utente

AGD

AGD 340 Manuale utente

Kustom Signals

Kustom Signals Eagle 3 Manuale utente

SYMEO

SYMEO STU Manuale utente

Axis

Axis D2110-VE Manuale utente

MALA

MALA MIRA Manuale utente

Emerson

Emerson ROSEMOUNT 5300 Manuale utente

Rosemount

Rosemount 5300 Series Manuale utente

TERMA

TERMA SCANTER 5102 Manuale utente

GSSI

GSSI UtilityScan Manuale utente

Acconeer

Acconeer A111 Manuale utente

Crosley

Crosley CR37 Manuale utente

AGD

AGD 318 Manuale utente

Cobra

Cobra SLR 650G Manuale utente

Faselase

Faselase D10 Manuale utente
