Energy GBL5.8K3 Manuale utente

About this manual

This manual is intended for the GSMARTE GBL5.8K3 Energy Storage battery, but

the hybrid inverter and any other equipment is not included. The GSMARTE hot line

（0086）

-400-101-8585 and https://www.gsmarte.com/ are both available if you want to

get additional information.

Statement

Compliant to Best Practice Guide for Battery Storage Equipment—Electrical Safety

Requirements- version 1- Pre-assembled integrated battery energy storage system

equipment – Method 1 mandatory requirements and Optional requirements – a), c), e),

f), g), h), i), j), k), l), m), n), o), p), q).

Contents

About this manual....................................................................................................................... II

Statement.....................................................................................................................................II

1. Safety introduction............................................................................................................. - 1 -

1.1 Important Safety Instructions....................................................................................... - 1 -

1.2 Warnings in this Document.......................................................................................... - 1 -

1.3 Battery handing guide...................................................................................................- 1 -

1.4 Response to emergency situations................................................................................- 2 -

1.4.1 Leaking batteries....................................................................................................- 2 -

1.4.2 Fire.........................................................................................................................- 2 -

1.4.3 Wet battery............................................................................................................ - 2 -

1.4.4 Damaged battery....................................................................................................- 2 -

1.5 Installers........................................................................................................................- 3 -

1.6 Scrap battery................................................................................................................. - 3 -

1.7 Contact information......................................................................................................- 3 -

2. Product Introduction........................................................................................................... - 4 -

2.1 Technical data...............................................................................................................- 4 -

2.2 Exploded views of battery............................................................................................ - 5 -

2.3 Indicator and ports........................................................................................................ - 5 -

2.3.1 Indicator.................................................................................................................- 5 -

2.3.2 Ports....................................................................................................................... - 6 -

2.4 Communication interface plat（DVC-A2voltage）....................................................- 7 -

2.5 How it works................................................................................................................ - 8 -

2.6 Feature.......................................................................................................................... - 8 -

3. Guidance for disconnection of batteries during shipment.................................................. - 8 -

4.Installation Prerequisites......................................................................................................- 9 -

4.1 Installation location...................................................................................................... - 9 -

4.2 Installation clearance.................................................................................................. - 10 -

4.3 Installation process..................................................................................................... - 10 -

4.4 Installation materials...................................................................................................- 11 -

4.5 Tools........................................................................................................................... - 12 -

4.6 Safety instruments...................................................................................................... - 12 -

4.7 Making network cable................................................................................................ - 12 -

4.8 Storage........................................................................................................................ - 12 -

5. Battery Installation........................................................................................................... - 13 -

5.1 Unpacking...................................................................................................................- 13 -

5.2 Package items............................................................................................................. - 14 -

5.3 Checks before installation.......................................................................................... - 15 -

5.4 Installation the battery................................................................................................ - 15 -

5.5 Cable connections.......................................................................................................- 18 -

5.5.1 Connect the communication cable from inverter................................................ - 18 -

5.5.2 Connecting the power cables for battery............................................................. - 18 -

5.6 Parallel connection..................................................................................................... - 19 -

5.6.1 Communication cable connect between batteries................................................- 19 -

5.6.2 Power cables connect between batteries..............................................................- 20 -

6. Configuration....................................................................................................................- 21 -

6.1 Configure device WIFI...............................................................................................- 21 -

6.2 Register your account................................................................................................. - 23 -

6.3 Setting for communication interface.......................................................................... - 24 -

6.4 Settings for CAN /485 bus pins..................................................................................- 27 -

7.Commissioning..................................................................................................................- 27 -

7.1 Commissioning battery...............................................................................................- 27 -

7.2 Power on strategy....................................................................................................... - 28 -

7.3 Shutting down battery.................................................................................................- 28 -

8. Troubleshooting................................................................................................................- 28 -

9. Maintenance......................................................................................................................- 29 -

10. Appendix- RED Declaration.......................................................................................... - 31 -

- 1 -

1. Safety introduction

1.1 Important Safety Instructions

This manual contains important instructions for:

GBL5.8K3 Energy Storage product and this manual must be followed when installing

and using this product.

The product is designed and tested in accordance with international safety

requirements IEC 60364, but as with all electrical and electronic equipment, certain

precautions must be observed when installing and/or operating the product. To reduce

the risk of personal injury and ensure the safe installation and operation of the product,

you must carefully read and follow all instructions, cautions and warnings in this

manual.

1.2 Warnings in this Document

A warning describes a hazard to equipment or personnel. It calls attention to a

procedure or practice, which, if not correctly performed or adhered to, could result in

damage to or destruction of part or all of the GSMARTE equipment and/or other

equipment connected to the GSMARTE equipment or personal injury.

Symbol

Description

Caution, risk of electric shock

Heavy enough may cause severe injure

Keep the battery away from open flame or ignition sources

Keep the battery away from children

Do not dispose of the product with household waste

Recycling

Read this manual before installation and operation

For safety reasons, installers are responsible for familiarizing themselves with the

contents of this manual and all warnings before performing installation.

1.3 Battery handing guide

- Use the battery pack only as directed.

- If the battery defective, appears cracked, broken or otherwise damaged, or fails to

operate, contract the GSMARTE hot line immediately.

- Do not attempt to open, disassemble, repair, tamper with, or modify the battery.

The battery pack is not user serviceable.

- To protect the battery and its components from damage when transporting, handle

with care.

- 2 -

- Do not subject it to any strong force.

- Do not insert foreign objects into any part of the battery pack.

- Do not use cleaning solvents to clean the battery.

- The battery shall not be connected directly to SELV circuit.

1.4 Response to emergency situations

The GSMARTE battery is designed with multiple safety strategies to prevent hazards

resulting from failures. However, GSMARTE cannot guarantee their absolute safety

for uncertain situations.

1.4.1 Leaking batteries

If the battery pack leaks electrolyte, avoid contact with the leaking liquid or gas.

Electrolyte is corrosive and contact may cause skin irritation and chemical burns. If

one is exposed to the leaked substance, do these actions:

Inhalation: Evacuate the contaminated area, and seek medical attention immediately.

Eyes contact: Rinse eyes with flowing water for 15 minutes, and seek medical

attention immediately.

Skin contact: Wash the affected area thoroughly with soap and water, and seek

medical attention immediately.

Ingestion: Induce vomiting as soon as possible, and seek medical attention

immediately.

1.4.2 Fire

In case of a fire, make sure that an ABC or carbon dioxide extinguisher is nearby and

does not use water to extinguish the fire.

WARNING

The battery pack may catch fire when heated above 150°C.

If a fire breaks out where the battery is installed, do these actions:

1. Extinguish the fire before the battery catches fire.

2. If the battery has caught fire, do not try to extinguish the fire. Evacuate people

immediately.

WARNING

If the battery catches fire, it will produce poisonous gases. Do not

approach.

1.4.3 Wet battery

If the battery is wet or submerged in water, do not try to access it. Contact

GSMARTE hot line or your distributor for technical assistance.

1.4.4 Damaged battery

If the battery damaged, please contract GSMARTE hot line or your distributor for

help as soon as possible, because damaged battery is dangerous and must be handled

with extreme caution. Damaged battery is not suit for use and may pose a danger to

people or property. If the battery seems to be damaged, return it to GSMARTE or

your distributor.

- 3 -

CAUTION

Damaged battery might export electrolyte or flammable gas, so contact

GSMARTE for advice and information immediately we will deal with it

within 48h.

1.5 Installers

GSMARTE Energy Storage battery is suggested installing by skilled worker or

electrician. A skilled worker is defined as a people who had been trained and qualified

electrician or had all of the following skills and experience:

- Knowledge of the functional principles and operation of on-grid Energy Storage

systems.

- Knowledge of the dangers and risks associated with installing and using electrical

devices and acceptable mitigation methods.

- Knowledge of the installation of electrical devices

- Knowledge of and adherence to this manual and all safety precautions and best

practices.

1.6 Scrap battery

For scrap battery(-ies), please treat with local laws or regulations to recycle or scrap.

1.7 Contact information

Use the contacts below for technical assistance. This phone numbers is available only

during business hours on weekdays.

China

Australia

Phone

number

+(0086)400-101-8585

Phone

number

+61-039-021-7788

Address

No.23 Xingke Middle

Road,Meilin

Street,Ninghai

County,Ningbo

City,Zhejiang

Province,China

Address

Unit 35,15Ricketts Road.Mount

Waverley,Victoria,3149,Australia

Importer(EUR)

Phone number

+49 911 95649069

Address

Neumeyerstr. 28-34,90411 Nürnberg│Germany

E-mail:[email protected];[email protected]

- 4 -

2. Product Introduction

2.1 Technical data

Model

GBL5.8K3

Total Energy*

5.8kWh

Usable Energy(DC)*

5.3kWh

Nominal Charge/Discharge Power

2.75kW

Peak Power(Only discharge)

7kW for 5seconds

Constant Current(Only discharge)

100A

Voltage

42-54Vd.c

Nominal Voltage

48Vd.c

Nominal Current

57A

Max. Charge Voltage

54.0V

Recommended Peukert Setting(Off-grid)

1.05

Max. Recommended DOD (Off-grid)

90%

Operating Condition

Indoor or outdoor

Operating Temperature

From -10~50℃

Dimension(L*W*H)

650*480*258 mm

Max. Transmission Power

<20dBm

Weight

70kg

Humidity

4-100%

Pollution Degree

Over Voltage Category

Cooling Type

Natural cooling

Case Material

Metal

Color

White

Installation

Mounting/Free Standing

IP rating

IP 65

Protective Class

Max. Number of Parallel Connection

Warranty

10 years battery warranty

Life Span

>15 years

Communication

CAN/ RS485

Protection Mode

Triple hardware protection

Battery Protection

Over-current/Over-voltage/Short circuit/

Safety

Cell UL 1973

Pack TUV(IEC 62619, IEC 62040-1)

Hazardous Material Classification

Transportation

UN 38.3

Max. Charge Power

2.75kW

Max. Discharge Power

2.75kW

Max. Charge Current

57A

Max. Discharge Current

57A

- 5 -

Fault Current

Charge 100A>3s,Disharge 135A>3s,

WIFI Frequency Range

2400MHz-2483MHz

Testing conditions based on temperature 25℃ at the beginning of life.

*Total Energy/Usable Energy measured under specific conditions from GSMARTE 0.2C CC-CV

2.2 Exploded views of battery

2.3 Indicator and ports

2.3.1 Indicator

There are four LED indicators on the front of the battery to show its operating status.

Table 2-1 Designations on the battery

Item

Designation

Definition

Fault

Battery no power output or input

- 6 -

Discharge

Battery is charging

Charge

Battery is discharging

Standby

Battery is in a warning state, see troubleshooting in Chapter 6

2.3.2 Ports

2.3.2.1 The left side of power cable connectors and communication cable

1 Handle

2 Power cable sockets

3. CAN/485

2.3.2.2 The right side of power cable connectors and communication cable

Indice

Altri manuali Energy Pacco batterie

Energy

Energy GOLDEN SIGMA SU340U170KC Manuale utente

Manuali Pacco batterie popolari di altre marche

Acumentrics

Acumentrics PACK-POWER SYSTEM Manuale utente

ACDC Dynamics

ACDC Dynamics SPF12-50 Manuale utente

Aegis

Aegis ABL-72020P Manuale utente

Dyness

Dyness TowerESS Manuale utente

Growatt

Growatt APX 5.0P-S0-US Manuale utente

EGO

EGO BAX1300 Manuale utente

CyberPower

CyberPower BCA Series Manuale utente

Intermec

Intermec 700 Series Manuale utente

Dometic

Dometic PLB40 Manuale utente

V-TAC

V-TAC VT-48280-W2 Manuale utente

Valence

Valence RT Manuale utente

Nikon

Nikon MB-D14 Manuale utente

IOGear

IOGear GBP24V Series Manuale utente

Inventus Power

Inventus Power PROTRXion S-12V100-TRX-HD Manuale utente

Clas Ohlson

Clas Ohlson PW-290A Manuale utente

EINHELL

EINHELL MULTI-Ah Power X-Change Plus Manuale utente

Samsung

Samsung EB-U3300 Manuale utente

ECTIVE

ECTIVE LC Series Manuale utente
