ENERMAX CLUSTER UCCL12 Manuale utente

BATWING Blades Single Blade

HALO Frame Normal Frame

More area available to produce more airflow.

More airflow gets inside of frame through HALO Frame cut-outs.

V.S

Item

Dimension(mm)

Function

Bearing Type

Blades

Noise Level (dBA)

Speed Range (RPM)

(CFM)

(m /h)

Air Pressure(mm-H2O)

Lifetime

LED

Certifications

UCCL8

80(w)x80(h)x25(d)

7 Blades

8 －19

500 －2000

11.32 －32.40

19.23 －55.05

0.517 －1.8000

UCCL9

92(w)x92(h)x25(d)

7 Blades

8 －19

500 －2000

13.23 －38.30

22.48 －65.07

0.512 －1.795

UCCL12

120(w)x120(h)x25(d)

9 Blades

8 －14

500 －1200

26.51 －53.02

45.04 －90.08

0.483 －1.073

PWM　Technology

TWISTER Bearing Technology

BATWING Blade Design

100,000 hrs

White with on/off function

Airflow 3

BATWING Blade Design

HALO Frame

CLUSTER

differ from illustrations. Omissions and printing errors excepted. Content of delivery might differ in different countries or areas.Some trademarks may be claimed

as the property of others.

UCCL8 / 9 / 12

www.enermax.com forum.enermax.com

PWM Technology

Total Control

Ball

Magnetic

Coil Coil

Flexible

Magnet

Flexible

Magnet

100K Hours Lifetime

Lower noise than Sleeve bearing

Longer lifetime than 2-ball bearing

Magnetic Design without oil

Bearing Type

Patented FAIRY Frame structure with

Aluminum for enhanced stability

Detachable water-resistant blades for easy

cleaning

White LIGHTNING LED with on/off function

Isolator-mounts for shockproofness and

easy installation

Fan Blades

Detachable PWM

Connector

“TWISTER” Bearing Technology with double

lifetime than 2-ball bearing

BATWING Blade Design and Carved HALO

Frame for extra 20% ~ 30% airflow

PWM fan speed control to keep your system

silent and cool all the time

*UCCL12 with 9 blades.

*UCCL9 and UCCL8 with 7 blades.

Accessories

Note:

The PWM control requires PWM-enabled motherboard and connection.

PWM control function will not work, if using 4-pin adaptor to connect with

power supply or being connected to 3-pin connector on motherboard.

UCCL8 / 9 / 12

CLUSTER

differ from illustrations. Omissions and printing errors excepted. Content of delivery might differ in different countries or areas.Some trademarks may be claimed

as the property of others.

www.enermax.com forum.enermax.com

BATWING Blades Single Blade

HALO Frame Normal Frame

More area available to produce more airflow.

More airflow gets inside of frame through HALO Frame cut-outs.

V.S

Item

Dimension(mm)

Function

Bearing Type

Blades

Noise Level (dBA)

Speed Range (RPM)

(CFM)

(m /h)

Air Pressure(mm-H2O)

Lifetime

LED

Certifications

UCCL8

80(w)x80(h)x25(d)

7 Blades

8 －19

500 －2000

11.32 －32.40

19.23 －55.05

0.517 －1.8000

UCCL9

92(w)x92(h)x25(d)

7 Blades

8 －19

500 －2000

13.23 －38.30

22.48 －65.07

0.512 －1.795

UCCL12

120(w)x120(h)x25(d)

9 Blades

8 －14

500 －1200

26.51 －53.02

45.04 －90.08

0.483 －1.073

PWM　Technology

TWISTER Bearing Technology

BATWING Blade Design

100,000 hrs

White with on/off function

Airflow 3

BATWING Blade Design

HALO Frame

CLUSTER

differ from illustrations. Omissions and printing errors excepted. Content of delivery might differ in different countries or areas.Some trademarks may be claimed

as the property of others.

UCCL8 / 9 / 12

www.enermax.com forum.enermax.com

PWM Technology

Total Control

Ball

Magnetic

Coil Coil

Flexible

Magnet

Flexible

Magnet

100K Hours Lifetime

Lower noise than Sleeve bearing

Longer lifetime than 2-ball bearing

Magnetic Design without oil

Bearing Type

Patented FAIRY Frame structure with

Aluminum for enhanced stability

Detachable water-resistant blades for easy

cleaning

White LIGHTNING LED with on/off function

Isolator-mounts for shockproofness and

easy installation

Fan Blades

Detachable PWM

Connector

“TWISTER” Bearing Technology with double

lifetime than 2-ball bearing

BATWING Blade Design and Carved HALO

Frame for extra 20% ~ 30% airflow

PWM fan speed control to keep your system

silent and cool all the time

*UCCL12 with 9 blades.

*UCCL9 and UCCL8 with 7 blades.

Accessories

Note:

The PWM control requires PWM-enabled motherboard and connection.

PWM control function will not work, if using 4-pin adaptor to connect with

power supply or being connected to 3-pin connector on motherboard.

UCCL8 / 9 / 12

CLUSTER

differ from illustrations. Omissions and printing errors excepted. Content of delivery might differ in different countries or areas.Some trademarks may be claimed

as the property of others.

www.enermax.com forum.enermax.com
