GB
DESCRIPTION
The receiver (fig. 1) is used for wireless control of eight elec-
tric appliances using the BOSys®line transmitters (tab. 1).
It is a built in receiver. Power supply and outputs are assem-
bled with screwless terminals.
FUNCTIONS OF THE RECEIVER
ON
Upon each pressing of the transmitter button, the relay of the
receiver will close and remain closed.
OFF
Upon each pressing of the transmitter button, the relay of the
receiver will open and remain open.
ON/OFF - SINGLE BUTTON MODE
Press the transmitter button to alternately close and open the
relay of the receiver.
ON/OFF - TWO-BUTTON MODE
Press the transmitter upper button to close the relay of the re-
ceiver.
Press the transmitter lower button to open the relay of the re-
ceiver.
PUSH
The relay of the receiver will remain closed for the time of
pressing the transmitter button (limited to 25s at the transmit-
ter).
TIMER
Upon pressing of the transmitter button, the relay of the re-
ceiver will close for a preset time period.
LED indication:
Flashing RF Signal LED indicates signal reception.
Continuously lit CH1 to CH8 LED indicates active output.
Flashing NO CODE LED indicates empty memory of the re-
ceiver.
Continuously lit BAT./EXT. LED indicates connection of an ex-
ternal transmitter.
Flashing BAT./EXT. LED indicates, that the battery of the last
transmitting transmitter is flat.
COMMISSIONING
- Fix the receiver as following:
a) Screw it down using two screws in cover corners (max.
Ø 5 mm, screw head max. Ø 9 mm).
b) Or use two sliding strips 6mm wide in holes on the back
side if the receiver.
c) Or just lie it on the lower ceiling free.
- Connect the receiver. Power supply and outputs are assem-
bled with screwless terminals.
Put the supplied antenna into the ANT terminal and place it far
from power cables and metal objects.
- Get ready the transmitter.
Note:
If there is a trouble with a range, it is possible to connect an
external receiver Rx Ext or Rx GP + transmitting antenna GP
433 (fig. 2 - external receiver is not included).
Caution:
The connection (disconnection) between the receiver and the
appliance may be performed by qualified person only.
A) How to record the transmitter in the receiver memory
(ON, OFF, ON/OFF, PUSH functions):
- Push the receiver button PROG once. The LED REC gets
lit.
- By means of the receiver button CHANNEL select the chan-
nel (channels). A short push of the button CHANNEL selects
the channel, a long push of the button CHANNEL confirms the
choice.
- Push the receiver button PROG once. Three LEDs
EXT./BAT., NO CODE and CODE get lit.
- By repeated short pushes of the button PROG, select the
function. It is determined by the combination of the three
LEDs (see the print on the receiver).
- Push the selected button (buttons) on the transmitter twice
(long push).
- Correct record is confirmed by LEDs REC and CODE
flashing.
B) How to record the transmitter in the receiver memory
in TIMER function:
- Push the receiver button PROG once. The LED REC gets
lit.
- By means of the receiver button CHANNEL select the chan-
nel (channels). A short push of the button CHANNEL selects
the channel, a long push of the button CHANNEL confirms the
choice.
- Push the receiver button PROG once. Three LEDs
EXT./BAT., NO CODE and CODE get lit.
- By repeated short pushes of the button PROG, select the
function TIMER. The function is determined by the combina-
tion of the three LEDs (see the print on the receiver).
- Push the selected transmitter button twice (long push). The
receiver will automatically switch to the time-setting mode.
The LED REC continues to lit, one of the LEDs sor min
starts to flash. (LED sindicates settings of seconds, LED min
indicates settings of minutes.)
- By repeated short pushes of the button PROG set the lit
combination of the three LEDs to correspond to the required
time value (1 s to 60 min.) showed on the receiver print
(fig. 3).
- Long push of the PROG button confirms the selected time
slot.
- Correct record is confirmed by LEDs REC and CODE
flashing.
C) How to delete one transmitter out of all channels
- Push the button PROG on the receiver twice. The LED
CODE and LEDs of all channels CH1 to CH8 lit.
- Push the button (buttons) of the transmitter you need to de-
lete twice (long push).
- The LEDs REC and CODE flashing confirms, that the
transmitter has been deleted from all channels of the receiver.
D) How to delete one transmitter out of an individual channel
- Push the button PROG on the receiver twice. The LED
CODE and LEDs by all channels CH1 to CH8 lit.
- By means of the receiver button CHANNEL select the chan-
nel (channels). A short push of the button CHANNEL selects
the channel, a long push of the button CHANNEL confirms the
choice.
- Push the button (buttons) of the transmitter you need to de-
lete twice (long push).
- The LEDs REC and CODE flashing confirms, that the
transmitter has been deleted from the selected channel (chan-
nels) of the receiver.
E) How to delete all transmitters
- Push the receiver button PROG for more than 10 s.
- After that the LED NO CODE starts flashing.
E) Direct outputs control –service mode
- By means of the receiver button CHANNEL, select the
channel (channels) you need to switch on. A short push of the
button CHANNEL selects the channel, a long push of the but-
ton CHANNEL confirms the choice.
- Push the receiver button PROG. The relay of the selected
channel (channels) switches on.
Hereby, ENIKA.CZ. s.r.o., declares that the device Rx8 S3 is
in compliance with the essential requirements and other rele-
vant provisions of Directive 1999/5/ES.
Prohlášení o shodě
Výrobce: ENIKA.CZ s.r.o.
190 00 PRAHA 9, Pod Harfou 933/86
IČO: 28218167
tímto prohlašuje, že výrobek
typové označení: Rx8 S3
specifikace: ---
druh výrobku: osmikanálový přijímač
přijímací frekvence: 433,92 MHz
citlivost: -114 dBm
- je ve shoděse základními požadavky NV 426/2000 Sb. v platném znění
- odpovídá základním požadavkům a dalším ustanovením evropské direktivy
1999/5/ES
(R&TTE) (Směrnice o radiových zařízeních a telekomunikačních
koncových zařízeních a vzájemném uznávání jejich shody)
- splňuje požadavky těchto norem a předpisů:
rádiové parametry: ČSN EN 300220-3:2000
EMC: ČSN EN 60669-2-1: 01 ed.2
ČSN EN 55014-1
ČSN EN 61000-3-2: 01
ČSN EN 61000-3-3: 97
elektrická bezpečnost: ČSN EN 60 669-2-1: 01 ed.2
čl. 8, 12, 13, 15, 16, 20, 21, 23, 24
Toto prohlášení je vydáno na výhradní odpovědnost výrobce.
V Nové Pace dne 16.09.2008 ing. Vladimír Militký,
řízení sytému jakosti
