Enphase Energy System with IQ Battery 5P Owner’s Guide
Enphase Energy System
with IQ Battery 5P
Owner’s Guide
2
Enphase Energy System with IQ Battery 5P Owner’s Guide
To ensure optimal performance and reliability and to
meet warranty requirements, the Enphase Energy
System must be installed according to the instructions in
the respective product quick install guides.
The Enphase Energy System equipment is intended to
operate with an internet connection. Maintaining an
internet connection is important, not only for updating
software and rmware but also for measuring the health
of the system. Failure to maintain an internet connection
may have an impact on the warranty.
In addition, features like live status monitoring, energy
and power monitoring, work when the system has an
active internet connection.
Visit https://enphase.com/en-gb/warranty/uk for full
terms and services.
Product information is subject to change without notice.
All trademarks are recognized as the property of their
respective owners. User documentation is updated
frequently.
Check the Enphase website (https://enphase.com/en-
gb/installers/resources/documentation) for the latest
information.
Warranty
Other information
This manual is intended for use by owners of Enphase
Energy Systems with IQ Battery 5P.
Audience
Visit https://enphase.com/en-gb/patents for Enphase
patent information. © 2023 Enphase Energy. All rights
reserved.
Enphase, the e and CC logos, IQ, and certain other
marks listed at https://enphase.com/trademark-usage-
guidelines are trademarks of Enphase Energy, Inc. in the
US and other countries. Data subject to change.
Waste electrical products (including batteries)
should not be disposed of with household
waste. Refer to your local codes for disposal
requirements.
Environmental protection
ELECTRONIC DEVICES: DO NOT THROW AWAY.
Do not install or use the Enphase Energy System
equipment if the equipment is damaged.
3
Enphase Energy System with IQ Battery 5P Owner’s Guide
Contents
System information 6
Key components 6
Component introduction 7
IQ Battery 5P 7
IQ Gateway 7
Communications Kit 7
System block diagram 8
System monitoring and
management 11
Enphase App 11
Enphase web application 11
Know your smart prole 10
Charge battery from the grid mode 12
System care 13
Troubleshooting 14
Safety information 23
Revision history 25
4
Enphase Energy System with IQ Battery 5P Owner’s Guide
Enphase Energy System
with IQ Battery 5P
5
Enphase Energy System with IQ Battery 5P Owner’s Guide
Enphase Energy System
IQ MICROINVERTERS
IQ BATTERY 5P ENPHASE APP
6
Enphase Energy System with IQ Battery 5P Owner’s Guide
System information
IQ Battery 5P stores energy and dispatches it when
you need it. IQ Battery 5P is built on a distributed
architecture platform. This modular design means you
can quickly and easily expand your system as your
needs grow.
IQ Battery 5P
The Enphase App is a mobile app where you can monitor
and control your system status from wherever you
are and know exactly how much energy your solar PV
system is producing. You can generate reports on energy
production by day, week, month, or year.
Enphase App
Under each solar panel lies an Enphase microinverter that
converts DC power generated by the panel into AC power
that your home can use.
IQ Microinverters
The brain of the Enphase Energy System is Enphase
IQ Gateway. The IQ Gateway collects production and
performance data from IQ Series Microinverters and IQ
Battery 5P, manages your system, and communicates
with the Enphase cloud.
IQ Gateway
Key components
Current Transformers measure the current owing
through the system. The Enphase Energy System uses one
CT to measure the solar power generated on your roof
and one CT to measure the electricity consumption of
your entire home. These currents measured are fed to the
IQ Gateway.
Current Transformers
An accessory used to enable communication between IQ
Battery 5P and IQ Gateway. This device connects to IQ
Gateway via USB cable and IQ Batteries are connected to
this device via control cables.
Communications Kit
7
Enphase Energy System with IQ Battery 5P Owner’s Guide
IQ Battery 5P is an AC-coupled storage system with an energy
capacity of 5.0 kWh. It houses two major components inside
the cabinet which make the IQ Battery 5P powerful and
reliable:
• The battery packs, internal to IQ Battery 5P, store energy
for later use, such as night-time or lower solar production
circumstances. IQ Battery 5P can supply up to 3.2 kVA of
power to the loads in your home.
• The IQ Microinverters, internal to IQ Battery 5P, convert
stored DC energy into usable AC electricity for your home,
ensuring reliable power supply by sharing the load.
IQ Battery 5P communicates through wired communication to
the Communications Kit that then communicates through USB
to the IQ Gateway.
IQ Gateway collects production and performance data
from your Enphase Energy System. It then transmits the
data to the Enphase Cloud through Ethernet or Wi-Fi to
make it visible in the Enphase App. The IQ Gateway also
houses advanced algorithms that control and optimise
your Enphase Energy System for the best performance.
The IQ Gateway uses a Communications Kit as an
accessory to enable communication with IQ Battery 5P.
IQ Battery 5P
IQ Gateway and Communications Kit
Component
introduction
8
Enphase Energy System with IQ Battery 5P Owner’s Guide
The power supply to your home can either be single-phase or three-phase.
A single-phase power supply is a two-wire alternating current (AC) circuit with Line and Neutral.
A three-phase power supply is a four-wire AC circuit with Line 1, Line 2, Line 3, and Neutral.
A typical home power supply has a voltage of 230 V (L-N) and frequency of 50 Hz.
Below you can nd a simplied representation of your Enphase Energy System.
System block diagram
9
Enphase Energy System with IQ Battery 5P Owner’s Guide
System monitoring
and management Instructions to activate your Enphase App account
are sent to you at the email address you provided to
your installer. Look for an email with the subject line
“Activate Your Online Solar Monitoring Account.” from
donotreply@enphaseenergy.com. You will also receive
monthly emails from this address. Be sure to unblock
this address from your spam or junk mail lters. Read
the Enphase App terms of service at https://enphase.
com/en-gb/legal/terms-of-service.
Make, use, save, and export your own power right from the
palm of your hand with the Enphase App. You can quickly and
easily monitor and control your Enphase Energy System and
modify system settings directly from the Enphase App.
NOTE: Internet connectivity for your Enphase Energy System
is essential to keep your system updated and provide accurate
information on the Enphase App.
The mobile application is available for both iOS
and Android devices. You can install the latest
version of Enphase App from the App Store or Play
Store.
You can access the Enphase App using your
internet browser on your desktop or mobile device.
Log in to the Enphase App at https://enlighten.
enphaseenergy.com.
Enphase App
Enphase web application
Getting started
10
Enphase Energy System with IQ Battery 5P Owner’s Guide
Know your smart prole
Your Enphase Energy System features a Self-Consumption smart prole, which helps maximising usage of solar and storage
power at your home.
Self-Consumption prole always prioritises your consumption or storage of your produced solar energy. It enables you to
use as much as possible of your generated energy at your own home.
This prole is only available for Enphase Energy Systems that include compatible Enphase IQ Batteries.
