Part Description Q'ty Part Description Q'ty
1 BASE FRAME 1 42 BEARING <6000ZZ> 1
2 FRONT POST 1 43 BEARING <6003ZZ> 2
3 SADDLE POST 1 44 BEARING <6300ZZ> 1
4 HANDLEBAR 1 45 BEARING <6203ZZ> 2
5 FRONT FOOT 1 46 Bearing-One Way 1
6 REAR FOOT 1 47 C12 CLIP 1
7 CRANK (L/R) 1 48 C10 CLIP 2
8 PEDAL (L/R) 1 49 C8 CLIP 2
9 CRANK COVER 2 50 Hex Nut(3/8"xT3mm) 1
10 MOVING WHEEL 2 51 Hex Nut(M6) 5
11 STABILIZER COVER 4 52 Hex Nut(3/8") 2
12 QUICK RELEASE KNOB 1 53 BELT 6PJ 1
13 SADDLE SUPPORT TUBE INSERT 1 54 Lock Nut (M8) 5
14 SEAT 1 55 C17 CLIP 2
15 COMPUTER 1 56 Flat Washer(10x20x1.0mm) 1
16 END CAP OF HANDLEBAR 2 57 Tension Cable 2
17 Foam Handgrip 2 58 Hex Head Bolt(M5x15mm) 8
18 HAND PULSE SENSOR 2 59 Round Philips Head Self Tapping Screw 4
19 CHAIN COVER (L) 1 60 Flat Washer(8x22x1.5mm) 2
20 CHAIN COVER ® 1 61 Plastic Spacer(M10x24x0.3mm) 2
21 FRONT POST COVER 1 62 Hex Head Shoulder Bolt(M6x18mm) 4
22 Height Adjusting Ring 1 63 Hex Head Shoulder Bolt(M8x25mm) 1
23 Jockey Wheel Bracket 1 64 Hex Head Shoulder Bolt(M6x65mm) 1
24 Jockey Wheel 1 65 AXLE FOR MAGNETIC HOLDER 1
25 MAGNETIC HOLDER BRACKET 1 66 Hex Head Shoulder Bolt(M8x25mm) 2
26 FLYWHEEL AXLE 1 67 Round Allen Head Bolt(M8x45mm) 4
27 FLYWHEEL 1 68 Spring Washer(8mm) 10
28 SMALL PULLEY 1 69 Flat washer(8mm) 10
29 BELT FOR GENERATOR 1 70 Motor Power Code 1
30 AXLE FOR PULLEY 1 71 Flat Washer(10x30x2.0mm) 1
31 Small Pulley Wheel 1 72 Hand wheel-Female 1
32 MAGNET 1 73 Carriage Bolt(M8x83mm) 1
33 MAGNETIC HOLDER 1 74 Saddle Forward/Back Adjustment Assembly 1
34 SPRING 1 75 Oval Internal End Cap 2
35
