The EU-T300C. The right choice

for smaller kiosks

Compact and cost-effective, the

EU-T300C kiosk printer is ideal for

smaller kiosks and basic kiosk print-

ing applications. Built with Epson’s

industry-leading printing technol-

ogy and quality, the EU-T300C has

proven its reliability in both indoor

and outdoor environments.

Wide range of features

The EU-T300C is a complete drop-

in printing solution and comes

with all the features you need most

including: print speeds up to six

inches per second, use of the same

standard 80mm paper roll as POS

printers and support for 2.4mil

receipt paper to 7mil ticket stock.

Other high-quality features include

easy paper loading with semiauto-

matic loading function, near-end

paper sensor, and a modular design

for easy maintenance.

Compatible and ready-to-go

The Epson EU-T300C kiosk printer

comes with Windows®drivers, a built-

in USB interface and a command

protocol based on the ESC/POS

standard. In addition, it features flash

memory for logos and graphics.

Industry-leading reliability

and service

The EU-T300C has an MCBF of

37 million lines, an autocutter life

of 1 million cuts, a rugged all-metal

chassis and remote status monitoring

for centralized maintenance. All of

which adds up to a low total cost of

ownership. And it is covered under

Epson’s ExpressCareSM service pro-

gram to ensure that you get the best

service available when you need it.

Proven in the marketplace

Epson kiosk printers are being used

successfully worldwide for a wide

variety of kiosk applications from

banking and quick-service restau-

rants to entertainment and retail.

The Epson EU-T300C is a fast, reliable drop-in

printing solution designed specifically for smaller

kiosks and basic applications.

The EU-T300C printer features best-in-class components,

high-quality thermal printing, industry-leading reliability,

support for a variety of paper stock and easy installation all

at a great price.

Modular Kiosk Thermal Mechanism

• Small, compact size 5.5"W x 7"D x 5"H

• Uses standard 80mm POS paper roll

• Fast printing speeds up to 6 inches per second

• Supports 2.4mil receipt paper to 7mil ticket stock

• Easy paper loading with semiautomatic loading

function

• Modular design for easy maintenance

• USB interface

• Wide range of cost-effective service options

Epson

EU-T300C

Kiosk Printer

Epson EU-T300C Kiosk Printer

Modular Kiosk Thermal Mechanism

Kiosk Specifications EU-T300C Series

Epson America, Inc. • 3840 Kilroy Airport Way • Long Beach, CA 90806 • (562) 290-5304 • http://pos.epson.com

Corporation. ExpressCare is a service mark of Epson America, Inc. All other trademarks are the property of their respective owners.

Specifications are subject to change without notice.

SD-DSKIOSK300CA

General Description Thermal Kiosk Printer

Dimensions (W x D x H) 5.5" x 7.0" x 5.0"

Weight 2.5kg (5.5lbs)

Power input 24 vdc

Construction All steel chassis and high quality components

Environmental 0–55 deg C, 10–80% humidity

Certification CSA/TUV/UL/CE

Printer Printing speed 150mm/sec. (5.9 inches/sec.)

Paper widths 80mm (3.1 inches) standard, widths from 58mm–82.5mm available

Paper thickness 56–183um (2.4–7mil)

Number of dots 640 dots–80mm to 82.5mm

Dot density 8 dots/mm (203 dpi)

Electrical Head motor: 24 vdc ±10%, Circuit 5 vdc ±5% (supplied by board)

Print speed control for low power consumption model

Sensors Paper end, black mark and paper low: photosensor;

Platen open, cutter blade position: micro-switch; Print head temperature: thermresistor

Reliability

Mechanism (MCBF) 37 million lines

Thermal head 100km/100 million pulses

Autocutter Exceeds 1.0 million cuts

Control Board Power supply Uses PS-180, low-cost 24 vdc power supply

CPU 32-bit 20 MHz Toshiba TMP 94 Series

Firmware 4 Mbit flash ROM, host or network upgradeable

User memory 192k usable for non-volatile for downloadable logos and special characters

Thermal Historical control

Paper feed Semiautomatic loading or manual, back feed is possible

Software compatibility Epson industry standard ESC/POS®

, WIN 95/98/2000/NT 4.0/XP, Linux and

exclusive Windows Status Monitor Program (API)

Interface USB interface

Paper Supply Maximum roll size 83mm (3.3) inch outside diameter, uses standard POS roll

Paper loading Semi-auto load

Sensors Paper out, Black mark, Paper low

Part Numbers EUT-300C-001 C41D393001

PS-180 power supply C825343
