Epson FX-870 Manuale utente

User’s Guide Update

Please update your User’s Guide with the following information.

These page-length settings have been added to your printer:

5.5, 7, 17, 14, 8, 6, 4, 3.5, and 3 inches.

See “Default-Setting Mode” in Chapter 3 for the groups of

available printer features. The page length feature has been

deleted from Group 1 and now appears in a new group

(Group 1 Extension). See the following table for a complete

list of Group 1 Extension settings.

Group 1 Extension Settings

Page length

11, 12, 8.5, 70/6(A4), 5.5, 7, 17, 14, 8, 6, 4,

3.5, and 3 inches

Changing Group 1 Extension default settings

Make sure the printer is turned off.

To enter the Group 1 Extension default-setting mode, turn

on the printer while you hold down the FONT and

PAPER FEED

buttons. The printer beeps once.

Load single-sheet or continuous paper. The printer then

automatically loads the paper and prints a quick

reference.

4004313

CO1 -00

Group

Feature

Page

length

Exter

FONT

light

OFF

Press the

FONT

button to select the page length. The

FONT,

CONDENSED,

and

READY

lights turn on, off, or blink to

show your selection.

For example, if you select 8 inches, the FONT light is on and

the CONDENSED

and

READY lights

are off.

After you

have

made your selection, exit the Group 1

Extension default-setting mode by turning off the printer.

Note:

If you want to check the new default settings, enter the

default-setting mode again and print the quick reference. After

that, turn off the printer to exit the default-setting mode.

FCC Compliance Statement

For United States Users

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio or television reception. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause interference to radio and television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures.

.Reorient or relocate the receiving antenna.

.Increase the separation between the equipment and receiver.

.Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

.Consult the dealer or an experienced radio/TV technician for help.

WARNING

The connection of a non-shielded equipment interface cable to this equipment will

invalidate the FCC Certification of this device and may cause interference levels

which exceed the limits established by the FCC for this equipment. It is the

responsibility of the user to obtain and use a shielded equipment interface cable

with this device. If this equipment has more than one interface connector, do not

leave cables connected to unused interfaces. Changes or modifications not expressly

approved by the manufacturer could void the user’s authority to operate the

equipment.

For Canadian Users

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus as set out in the radio interference regulations of the

Canadian Department of Communications.

Le present appareil numerique

n’emet

pas de bruits radioelectriques depassant les

limites applicables aux appareils numeriques de

Classe

B prescrites dans

reglement sur

brouillage radioelectrique

edict6

par

Minis&e

des

Communications du Canada.

Important Safety Instructions

Read all of these instructions before you set up your printer.

Follow all warnings and instructions marked on the printer.

Unplug the printer from the wall outlet before you clean it, and

use a damp cloth for cleaning, not liquid or aerosol cleaners.

Do not use your printer near water or spill any liquid on it.

Do not place the printer on an unstable cart, stand, table or other

surface that may allow the printer to fall.

Do not block any slots or openings in the cabinet. These are

provided for the ventilation necessary to ensure reliable

operation and protection from overheating. Placing the printer

on a bed, sofa, rug, or other similar surface may block the

openings. Also, do not place the printer in a built-in installation

unless proper ventilation is provided.

Never place the printer near or over a radiator or heat register.

Use the type of power source indicated on the label. If you are

not sure of the type of power available, consult your dealer or

local power company.

This printer may be equipped with a plug having a third

(grounding) pin, which fits only into a grounding-type outlet.

This is a safety feature. If you are unable to insert the plug into

the outlet, have an electrician replace your obsolete outlet. Do

not defeat the purpose of the grounding-type plug.

Do not put your printer where the cord will be walked on.

lIf you use an extension cord, make sure that the total of the

ampere ratings on the products plugged into the extension cord

does not exceed the extension cord’s ampere rating. Also, make

sure that the total of all products plugged into the wall outlet

does not exceed 15 amperes.

lNever push objects of any kind into your printer because they

may touch dangerous voltage points or short out parts that

could result in a risk of fire or electric shock.

lExcept as specifically explained in the user’s manual, do not

attempt to repair the printer yourself. This could expose you to

dangerous voltage points or other risks. Refer all servicing in

those compartments to service personnel.

lUnplug the printer from the wall outlet and have it repaired by a

qualified service person under the following conditions:

When the power cord or plug is damaged or frayed

If liquid has been spilled into it

If it has been exposed to rain or water

If it does not operate normally when the operating

instructions are followed. Adjust only those controls that are

covered by the operating instructions since improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the printer to normal operation.

If it has been dropped or the cabinet has been damaged

If it exhibits a distinct change in performance, indicating a

need for service.

Where United States Users Can Get Help

Epson America provides local customer support and service

through a nationwide network of authorized Epson dealers and

Service Centers.

Epson also provides the following support services through the

Epson Consumer Resource Center at (800) 922-8911:

Assistance in locating your nearest Authorized Epson Reseller or

Service Center

Technical assistance with the installation, configuration, and

operation of Epson products

Epson technical information library fax service

Product literature with technical specifications on our current

and new products

Sales of ribbons, supplies, parts, documentation, and accessories

for your Epson product

Customer Relations.

For United Kingdom Users

Epson product guarantee

Under the law, goods sold must comply with their description and

must be of merchantable quality and fit for their purpose or

correspond with any sample.

This guarantee does not affect the seller’s legal obligation or the

rights of the consumer in the “consumer transactions” under any

Statute, including Sections 12 to 15 of the Sales of Goods Act, 1979.

All Epson Products, other than OEM products, are fully guaranteed

against faulty operation or performance for a period of ONE YEAR

from date of purchase by the user of the product.

All claims under this guarantee MUST be supported by evidence of

purchase, normally the bill of sale invoice, and it is the responsibility

of the claimant to furnish such proof. Epson (UK) Limited does not

issue or operate any form of guarantee registration card.

Claims are made by the user returning the product to the supplier

from whom it was purchased or, if this is impractical, to any Epson

supplier who also handles the same product. In the event of any

difficulty, users are requested to contact the Service Co-ordinator

Manager at Epson (UK) Limited.

Epson (UK) Limited, or Epson Appointed Distributors, will at their

discretion repair or replace part or all of the product to provide, in

their judgement, a satisfactory performance of the product

consistent with its age and apparent usage.

This guarantee covers the cost of both the parts and labour required

to correct any malfunction of the equipment, but specifically

excludes: wear and tear, consumables, physical damage due to

incorrect use or misuse and damage or faulty operation due to

unauthorized and inexpert repair,

The guarantee is restricted to the performance of the product alone,

and Epson (UK) Limited does not accept responsibility for any

consequential loss or damage, nor claimed or implied performance,

when the product is used in any combination with other equipment

or program software.

Product guarantee may be invalidated as a result of excessive or

inappropriate use, use in adverse environment or in conditions

outside the specifications or if the product has been subjected to

unapproved modifications.

The guarantee does not cover visits to the user’s premises or the

repair or commissioning of the product on site.

Use of options

Epson (UK) Limited shall not be liable against any damages or

problems arising from the use of any options or consumable

products other than those designated as Original Epson Products or

Epson Approved Products by Epson (UK) Limited.

Safety information

Warning:

This appliance must be earthed. Refer to rating plate for

voltage and check that the appliance voltage corresponds to the

supply voltage.

Important:

The wires in the mains lead fitted to this appliance are

coloured in accordance with the following code:

Green and yellow - Earth

Blue - Neutral

Brown - Live

As the colours of the wires in the mains lead of this appliance may

not correspond with the coloured markings identifying the

terminals in your plug, proceed as follows:

The green and yellow wire must be connected to the terminal in the

plug which is marked with the letter E or with the earth symbol

(&)

or coloured green or green and yellow.

The blue wire must be connected to the terminal in the plug marked

with the letter N or coloured black.

The brown wire must be connected to the terminal in the plug

marked with the letter L or coloured red.

If damage occurs to the plug, replace the cord set or consult a

qualified electrician.

Replace fuses only with a fuse of the correct size and rating.

Tips for Printing on Single Sheets

There are a few things you should know about printing on single

sheets as opposed to continuous paper. When you print on single

sheets, you may notice that your printer prints the first page of your

file correctly but then prints too low on the next page, or that it

prints the last few lines from one page onto the next.

These differences in print position are easy to adjust; you can simply

change some of the settings in your application program as

described below to get the right results.

When you install an application program, you normally need to

identify the printer you are using. Make sure you choose the

correct printer. See Chapter 1 for the right printer to choose.

Many programs include an option to set the maximum lines per

page. If your program has a lines-per-page setting and you are

using standard 8.5 x 11-inch paper, set the lines per page to 61.

Note: To find the right lines-per-page setting for paper that is not

8.5 x 11 inches, create a test document using your application

program. Set your top and bottom margins to 0 and then create a

file of numbered lines from 1 to 66. When you print your file,

notice the last number printed on the first page. This is your

maximum lines-per-page setting.

If your program doesn’t have a lines-per-page setting, try

decreasing the top margin or increasing the bottom margin, or

both, until you get the results you want.

You can also try adjusting the form length setting. For a

standard 8.5 x 11-inch page, try setting the form length at 10

inches.

Some programs also let you indicate whether you are using

single sheets or continuous paper. Make sure you choose single

sheets.

Altri manuali per FX-870

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Epson Stampante

Epson

Epson R2400 - Stylus Photo Color Inkjet Printer Manuale utente

Epson

Epson STYLUS PHOTO R240 Series Istruzioni per il montaggio

Epson

Epson WF-6590 series Manuale di istruzioni

Epson

Epson TM-T20 II Manuale utente

Epson

Epson WorkForce WF-3520DWF Guida utente

Epson

Epson FX 890 Manuale utente

Epson

Epson Stylus PX810FW SERIES Istruzioni per il montaggio

Epson

Epson Stylus Pro 9000 - Print Engine Manuale utente

Epson

Epson Workforce Pro WF-C8690DWF Manuale utente

Epson

Epson C383001 - Stylus 777 Color Inkjet Printer Istruzioni operative

Epson

Epson PLQ-35 Manuale utente

Epson

Epson EcoTank ET-15000 Series Manuale utente

Epson

Epson SX410 Manuale di istruzioni

Epson

Epson WP-4011 Manuale utente

Epson

Epson ActionPrinter 3250 Istruzioni di installazione e manutenzione

Epson

Epson LQ-590 Manuale utente

Epson

Epson Stylus COLOR 3000 Manuale utente

Epson

Epson SC-F10000Series Guida utente

Epson

Epson ColorWorks C7500 Manuale utente

Epson

Epson EPL-7500 Manuale utente

Epson

Epson ET-2810 Series Manuale utente

Epson

Epson 980N - Stylus Color Inkjet Printer Manuale di istruzioni

Epson

Epson C11C694201 - PictureMate Dash PM 260 Color Inkjet... Manuale utente

Epson

Epson 2200 - Stylus Photo Color Inkjet Printer Dimensioni

Manuali Stampante popolari di altre marche

Lexmark

Lexmark 1400 Series Manuale

Canon

Canon i70 Series Manuale utente

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Canon

Canon LASER SHOT LBP-1210 Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Canon

Canon PIXMA PRO-1 Series Manuale utente

Canon

Canon PIXMA G3560 Guida all'installazione

Dell

Dell Color Laser Printer 2130cn Manuale utente

Tektronix

Tektronix Phaser 840 Manuale utente

Canon

Canon CLBR 460ps Manuale utente

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Canon

Canon imagePASS-A2 Manuale utente

Canon

Canon S820D Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente

Ricoh

Ricoh Aficio AP400 Manuale utente

BIXOLON

BIXOLON SRP-352plusV Manuale utente
