Epson Stylus Color 660 Manuale utente

EPSONStylusCOLOR660

Color ink jet printer

SEJ99005



SERVICE MANUAL

SERVICE MANUALSERVICE MANUAL

SERVICE MANUAL

Notice:

electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of SEIKO EPSON CORPORATION.

The contents of this manual are subject to change without notice.

All effort have been made to ensure the accuracy of the contents of this manual. However, should any errors be detected, SEIKO EPSON

would greatly appreciate being informed of them.

The above not withstanding SEIKO EPSON CORPORATION can assume no responsibility for any errors in this manual or the consequences

thereof.

EPSON is a registered trademark of SEIKO EPSON CORPORATION.

General Notice: Other product names used herein are for identification purpose only and may be trademarks or registered trademarks of their

respective owners. EPSON disclaims any and all rights in those marks.

PRECAUTIONS

Precautionary notations throughout the text are categorized relative to 1)Personal injury and 2) damage to equipment.

DANGER

Signals a precaution which, if ignored, could result in serious or fatal personal injury. Great caution should be exercised in

performing procedures preceded by DANGER Headings.

WARNING

Signals a precaution which, if ignored, could result in damage to equipment.

The precautionary measures itemized below should always be observed when performing repair/maintenance procedures.

DANGER

1. ALWAYS DISCONNECT THE PRODUCT FROM THE POWER SOURCE AND PERIPHERAL DEVICES PERFORMING ANY MAINTENANCE

OR REPAIR PROCEDURES.

2. NOWORK SHOULD BE PERFORMED ON THE UNIT BY PERSONS UNFAMILIAR WITH BASIC SAFETY MEASURES AS DICTATED FOR

ALL ELECTRONICS TECHNICIANS IN THEIR LINE OF WORK.

3. WHEN PERFORMING TESTING AS DICTATED WITHIN THIS MANUAL, DO NOT CONNECT THE UNIT TO A POWER SOURCE UNTIL

INSTRUCTED TO DO SO. WHEN THE POWER SUPPLY CABLE MUST BE CONNECTED, USE EXTREME CAUTION IN WORKING ON

POWER SUPPLY AND OTHER ELECTRONIC COMPONENTS.

WARNING

1. REPAIRS ON EPSON PRODUCT SHOULD BE PERFORMED ONLY BY AN EPSON CERTIFIED REPAIR TECHNICIAN.

2. MAKE CERTAIN THAT THE SOURCE VOLTAGES IS THE SAME AS THE RATED VOLTAGE, LISTED ON THE SERIAL NUMBER/RATING

PLATE. IF THE EPSON PRODUCT HAS A PRIMARY AC RATING DIFFERENT FROM AVAILABLE POWER SOURCE, DO NOT CONNECT IT

TO THE POWER SOURCE.

3. ALWAYS VERIFY THAT THE EPSON PRODUCT HAS BEEN DISCONNECTED FROM THE POWER SOURCE BEFORE REMOVING OR

REPLACING PRINTED CIRCUIT BOARDS AND/OR INDIVIDUAL CHIPS.

4. IN ORDER TO PROTECT SENSITIVE MICROPROCESSORS AND CIRCUITRY, USE STATIC DISCHARGE EQUIPMENT, SUCH AS ANTI-

STATIC WRIST STRAPS, WHEN ACCESSING INTERNAL COMPONENTS.

5. REPLACE MALFUNCTIONING COMPONENTS ONLY WITH THOSE COMPONENTS BY THE MANUFACTURE; INTRODUCTION OF

SECOND-SOURCE ICs OR OTHER NONAPPROVED COMPONENTS MAY DAMAGE THE PRODUCT AND VOID ANY APPLICABLE EPSON

WARRANTY.

PREFACE

This manual describes basic functions, theory of electrical and mechanical operations, maintenance and repair procedures of Stylus COLOR 660.

The instructions and procedures included herein are intended for the experienced repair technicians, and attention should be given to the precautions

on the preceding page. The chapters are organized as follows:

CHAPTER 1. PRODUCT DESCRIPTIONS

Provides a general overview and specifications of the product.

CHAPTER 2. OPERATING PRINCIPLES

Describes the theory of electrical and mechanical operations of the product.

CHAPTER 3. TROUBLESHOOTING

Provides the step-by-step procedures for troubleshooting.

CHAPTER 4. DISASSEMBLY AND ASSEMBLY

Describes the step-by-step procedures for disassembling and assembling the

product.

CHAPTER 5. ADJUSTMENTS

Provides Epson-approved methods for adjustment.

CHAPTER 6. MAINTENANCE

Provides preventive maintenance procedures and the lists of Epson-approved

lubricants and adhesives required for servicing the product.

CHAPTER 7. APPENDIX

Provides the following additional information for reference:

• EEPROM Address Map

• Connector Pin Assignments

• Circuit Diagram

Revision Status

Revision Issued Date Description

A August 25, 1999 First Release

CHAPTER

PRODUCTDESCRIPTION

EPSON Stylus Color 66

Revision

Cha

ter 1 Product Descri

tio

1.1 FEATURES

EPSON Stylus Color 660/660

are designed for PC users at home

and low price for hat high performance. Also, Stylus Color 440 printer

has the same high color print quality (720 X 720dpi) as Stylus ProXL,

and

Stylus Color 640,740,660

have the same high color print

quality (1440 X 720) as Stylus Color 600 and Stylus Pro 5000. The

major printer features are;

High color print quality

720 (H) x 720 (V) dpi printing (for Stylus Color 440)

1440 (H) X 720 (V) dpi printing (for Stylus Color 640, 660, 740)

4 color printing (YMCK)

Traditional and New Microwave

Black 64 nozzles, CMY 21 nozzles (for Stylus Color 440)

Black 64 nozzles, CMY 32/color nozzles (for Stylus Color 640,

660)

Black 144 nozzles, CMY 48/color nozzles (for Stylus Color 740)

Built-in auto sheet feeder

Holds 100 cut-sheets (64g/m2)

Holds 10 envelopes

Holds 30 transparency films

Holds 65 special papers

High-speed print

200 cps (for Stylus Color 440, 740)

Normal 200 cps, Draft 400 cps (only for Stylus Color 640, 660)

By using head drive frequency 14.4KHz, printing speed is twice

faster than Stylus Color.

Compact size

429mm (W) x 231mm (D) x 155mm (H) (for Stylus Color 440)

429mm (W) x 231mm (D) x 157mm (H) (for Stylus Color 640,

660)

429mm (W) x 261mm (D) x 157mm (H) (for Stylus Color 740)

Weight: 5.2Kg (for 3 models)

Acoustic noise

Approximately 45 dB (for Stylus Color 440)

Approximately 47 dB (for Stylus Color 640, 660, 740)

Interface

Bi-directional parallel I/F IEEE-1284 level 1 device (for 3

models)

Mac serial I/F up to approx. 1800 kbps (only for Stylus Color

740)

USB (only for Stylus Color 740)

One unit combined black and CMY head

Windows exclusive (for Stylus Color 440, 640, 660)

Standard, NLSP, 5 Scaleable fonts (only for Stylus Color 740)

Stylus Color 660 is the reflesh version based on Stylus

Color 640. The differen e points are as follows;

Following EEPROM Datas

Address Data

*02H: 03H

*72H: 36H

*73H: 36H

*74H: 30H

EPSON Stylus Color 66

Revision

Cha

ter 1 Product Descri

tio

See the Table A-20 to A-26 for EEPROM address map of

EPSON Stylus Color 440/640/740 Servi e Manual.

The rest contents of Product Description is the same as of EPSON

Stylus Color 640/660/740.

CHAPTER

OPERATINGPRINCIPLES

EPSON Stylus Color 66

Revision

Cha

ter 2 O

eratin

Princi

The contents of Operating Principles is the same as of EPSON Stylus

Color 640/660/740.
