Epson WF-110 Manuale utente

WF-110

Quick Guide

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Connecting to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Loading Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Using the Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Mobile and Voice-activated Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Replacing Ink Cartridges and the Maintenance Box. . . . . . . . . . . . . . . . . . . 10

Travel and Handling Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Where to Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Guide rapide

Renseignements de départ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connexion à un ordinateur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Chargement du papier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Utilisation du panneau de commande . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Impression mobile et à commande vocale. . . . . . . . . . . . . . . . . . . . . . . . . . 26

Chargement de la pile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Remplacement des cartouches d’encre et de la boîte de maintenance . . . 27

Conseils pour le déplacement et la manipulation de l’imprimante . . . . . . . . 28

Résolution de problèmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Comment obtenir de l’aide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Avis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

2Getting Started

Getting Started

IMPORTANT: Before using this product, make sure you read these instructions and the

safety instructions in the online User’s Guide.

Note: This printer is designed for use with Epson®cartridges only, not third-party cartridges

or ink. For important ink information, visit www.epson.com/epsonink (U.S.) or

www.epson.ca/epsonink (Canada) or see your printer box.

Your WF-110 wireless mobile printer includes these special features:

■Lightweight but rugged design for professional-quality documents and photos

■A built-in battery that you can charge from the USB port

■An optional external battery (part number C12C934941) for extended printing time

■Easy printing from a variety of mobile devices, including smartphones and tablets

Follow the instructions in this section to unpack the printer, charge the battery, install ink,

and install software.

Unpacking

Remove any tape or packing materials, but do not open ink cartridge packages until you

are ready to install the ink. Cartridges are vacuum packed to maintain reliability.

English

Printer

Ink cartridges

Micro USB cable

Power cord

and adapter

Replacement

maintenance box

Software CD

Getting Started 3

Turning on and Configuring

1. Connect the power cord and adapter, but do not connect the printer to your

computer yet.

Note: Plugging in the printer charges the battery. You can print a few pages after

charging for 5 minutes; the battery is fully charged after about 2.5 hours. You can also

charge the battery using the micro USB cable, as described on page 10.

2. Open the cover and turn on the printer.

3. Select your language on the LCD screen, then press OK.

Note:

■You can change this setting later using the product’s control panel. For more

information, see the online User’s Guide.

■If an error message appears, turn off the product and check that no protective material

has been left inside the product.

4Getting Started

Installing Ink

Caution: Keep the ink cartridges out of the reach of children and do not drink the ink.

Note: The included initial cartridges are designed for reliable printer setup and cannot be

used as replacement cartridges or resold. After setup, the remaining ink is available for

printing.

1. Unpack the ink cartridges and remove the yellow tape.

2. Remove the caps, but be careful not to touch the areas shown below.

Note: Save the caps so you can recap ink cartridges before storing or disposing of

them.

3. Open the inner cover.

4. Insert the cartridges at a slight angle as shown, then press into place. Make sure the

black cartridge is on the left and the color cartridge is on the right.

Getting Started 5

5. Close the inner cover and press OK to begin charging the ink. Ink charging takes

about 4 minutes.

Caution: Don’t turn off the printer or raise the inner cover while the printer is charging

or you’ll waste ink.

6. When you see a completion message on the printer’s LCD screen, ink charging is

complete. Press OK to return to the home screen.

Note: As part of setup, your product’s serial number will be sent to a secure Epson server so

that you can be eligible to participate in programs we may offer from time to time, including

the Epson ink replenishment program. You will have a separate opportunity to consent to

participating in such programs.

Installing Software

Note:

■If you are using a Mac or your computer does not have a CD/DVD drive, an Internet

connection is required to obtain the product software.

■To print from a Chromebook™, go to www.epson.com/support/gcp (U.S.) or

www.epson.ca/support/gcp (Canada) for instructions.

■From a Windows®computer, you can also print using the basic driver built into the

printer. See page 6 for instructions. To print from a mobile device, see page 9.

Firmware Update Notice: Epson periodically provides firmware updates to address issues

of security, performance, minor bug fixes and ensure your printer functions as designed.

Your printer was designed to work only with genuine Epson ink cartridges, therefore some

updates may affect the functionality of third-party ink.

1. Make sure the printer is not connected to your computer.

Windows: If you see a Found New Hardware screen, click Cancel and disconnect the

micro USB cable.

2. Insert the printer CD (Windows only) or download and run your printer’s software

package. For the latest software, visit:

www.epson.com/support/wf110 (U.S.) or www.epson.ca/support/wf110 (Canada)

3. Follow the instructions on the computer screen to run the setup program.

6Connecting to a Computer

4. When you see the Select Your Connection screen, select one of the following and

follow the on-screen instructions:

■Wireless connection

In most cases, the software installer automatically attempts to set up your wireless

connection. If setup is unsuccessful, you may need to enter your network name

(SSID) and password.

■Direct USB connection

Use the micro USB cable that came with the printer.

Note: You can also print wirelessly using Wi-Fi Direct®, as described on page 7.

Connecting to a Computer

Your printer provides several ways to connect, both at home and on the road:

■Connect to your computer using the micro USB cable and the WF-110 software

installed on the computer, as described on page 5.

■Connect to a Windows computer using the micro USB cable and the built-in basic

driver.

1. Disconnect the printer from your computer.

2. On the printer’s control panel, select Menu > WF-110 Basic Driver. Then press

OK.

3. Connect the printer to your computer using the micro USB cable, as shown

above, then press OK on the printer’s control panel.

4. Open Computer or My Computer on your system, then double-click EPSON >

SETUP.

5. Follow the on-screen instructions to install the driver.

Loading Paper 7

■Connect wirelessly to your computer.

If you installed the software as described on page 5 and selected wireless connection,

you can print using your home or office Wi-Fi network.

If you are away from your home or office network you can use Wi-Fi Direct, which

lets you connect up to 8 devices.

1. On the printer’s control panel, select Wi-Fi Setup > Wi-Fi Direct.

2. Follow the on-screen instructions until the SSID and password are displayed.

3. On your computer or other device, select the SSID and enter the password.

Loading Paper

1. Open the cover and slide the edge guide to the left.

2. Load up to 20 sheets of plain paper behind the tabs, then slide the edge guide against

the paper if necessary.

Note: You can load up to five sheets of Epson photo paper, one sheet of Epson

Premium Presentation Paper Matte, or one sheet of legal-size paper. For instructions on

loading special paper or envelopes, see the online User’s Guide.

3. Confirm the paper setting on the printer’s control panel.

4. Make sure there is room in front of the printer for your printed pages, so they don’t

fall on the floor.

8Using the Control Panel

Using the Control Panel

To save energy, the screen goes dark after several minutes of inactivity. Press any button to

turn it back on. To adjust the sleep timer, select Menu > Printer Setup > Sleep Timer.

The LCD screen shows the printer status:

Note: The initial maintenance box is partly filled after ink charging.

You may see the following icons on the screen:

Icon Meaning

The printer is connected to a Wi-Fi (wireless) network.

The printer is connected with Wi-Fi Direct (Simple AP) mode.

There is a battery problem. Go to Menu > Battery.

The battery is charging.

The ink cartridge is low or maintenance box is nearly full.

The ink cartridge is expended.

Turn on and off

Cancel operation or return

to previous screen

Select menu

items

LCD screen

Battery status

Network status

Ink

levels Maintenance

box level

Mobile and Voice-activated Printing 9

Mobile and Voice-activated Printing

■Print directly from your iOS device. Simply connect your printer and device to the

same network and tap the action icon to select the print option.

■Print directly from your Android™(v4.4 or later) device*. Simply connect your

printer and device to the same network and tap the menu icon to select the print

option.

■Print from wherever you are, next to your printer or remotely, with Epson Connect™

and Google Cloud Print™. Learn more at www.epson.com/connect (U.S.) or

www.epson.ca/connect (Canada).

■Use voice-activated assistants to print a variety of creative and everyday items from

your Epson product. Simply add your product to an Epson Connect account, then

link the account to a voice-activated assistant. See www.epson.com/voice (U.S.) or

www.epson.ca/voice (Canada) for more information.

* May require the Epson Print Enabler or Mopria Print Service app from Google Play™.

Charging the Battery

Note: An optional external battery (part number C12C934941) is also available for extended

printing time.

Plug in the printer to charge the battery, as described on page 3.

■The battery light is orange when the battery is charging and turns off when the

battery is fully charged. The light flashes if a battery problem occurs.

■The power light is blue when the printer is turned on and flashes when the printer is

operating. To save power when it is running on the battery, the printer turns off after

several minutes of inactivity. Press the button to turn it back on. To adjust the

power off timer, select Menu > Printer Setup > Power Off Timer.

Battery

light

Power

light

10 Replacing Ink Cartridges and the Maintenance Box

■You can also charge the battery using the micro USB cable.

Connect the printer to your computer using the micro USB cable, as shown on

page 6. Wake the computer if it is in sleep or hibernate mode. Charging starts when

the printer is turned off or goes into sleep mode. You can use any USB power source,

including some automobiles. If battery charging does not start, select Menu >

Battery > Battery Settings on the printer’s control panel, enable USB Power

Supply via PC, then try again.

■A fully charged battery can print approximately 50 color or 100 black and white

pages. Printing is slower when running on the battery.

■When you finish using the printer, make sure you press the button to turn it off.

Replacing Ink Cartridges and the

Maintenance Box

Ensure brilliant results with Epson specialty papers, engineered specifically for Epson

printers. Find specialty Epson papers and Epson Genuine Ink at www.epson.com (U.S.

sales) or www.epson.ca (Canadian sales) and at Epson authorized resellers. Call

800-GO-EPSON (800-463-7766).

Use these part numbers when you order or purchase new ink cartridges or maintenance

boxes:

■Black ink cartridge: 215

■Tri-Color ink cartridge: 215

■Maintenance box: T2950

Note: If you remove a low or expended ink cartridge, you cannot re-install and use the

cartridge.

Travel and Handling Tips

■When you travel by plane, Epson recommends handling the printer as a carry-on.

■Make sure you take extra ink cartridges and a spare maintenance box.

■Avoid strong impacts, which may damage the printer.

■Leave the ink cartridges and maintenance box installed.

■Do not leave the printer in direct sunlight, near heat sources, or inside cars or other

hot locations.

■If print quality declines, you may need to clean or align the print head. For

instructions, see your online User’s Guide.

Altri manuali per WF-110

Indice

Lingue:

Altri manuali Epson Stampante

Epson

Epson Stylus C62 Manuale di istruzioni

Epson

Epson R260 - Stylus Photo Color Inkjet Printer Manuale utente

Epson

Epson EPL-N2750 Manuale utente

Epson

Epson PM-520 series Manuale di istruzioni

Epson

Epson Stylus Photo T50 Manuale di istruzioni

Epson

Epson LQ-1070+ Manuale utente

Epson

Epson Stylus SX130 series Manuale utente

Epson

Epson Stylus Office SX620FW Istruzioni per il montaggio

Epson

Epson Stylus Pro 4800 Portrait Edition Manuale utente

Epson

Epson R260 - Stylus Photo Color Inkjet Printer Manuale utente

Epson

Epson TM-T70 Manuale utente

Epson

Epson FX-2170 - Impact Printer Manuale utente

Epson

Epson Stylus Photo 890 Manuale utente

Epson

Epson Stylus Color 740 Manuale utente

Epson

Epson PX650 Series Manuale di istruzioni

Epson

Epson EcoTank L396 Manuale di istruzioni

Epson

Epson ET-3843 Manuale utente

Epson

Epson WF-2860 Series Manuale utente

Epson

Epson Stylus 400 - Ink Jet Printer Manuale di installazione e funzionamento

Epson

Epson PictureMate Show - PM 300 - PictureMate Show Digital... Manuale di istruzioni

Epson

Epson TM-T88V Manuale utente

Epson

Epson C11C417001 - Stylus Photo 820 Color Inkjet... Dimensioni

Epson

Epson L1300 Manuale di istruzioni

Epson

Epson SC-S60600 Series Manuale utente

Manuali Stampante popolari di altre marche

Lexmark

Lexmark 1400 Series Manuale

Canon

Canon i70 Series Manuale utente

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Canon

Canon LASER SHOT LBP-1210 Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Canon

Canon PIXMA PRO-1 Series Manuale utente

Canon

Canon PIXMA G3560 Guida all'installazione

Dell

Dell Color Laser Printer 2130cn Manuale utente

Tektronix

Tektronix Phaser 840 Manuale utente

Canon

Canon CLBR 460ps Manuale utente

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Canon

Canon imagePASS-A2 Manuale utente

Canon

Canon S820D Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente

Ricoh

Ricoh Aficio AP400 Manuale utente

BIXOLON

BIXOLON SRP-352plusV Manuale utente
