ESAB Origo Tig 3000i Manuale utente

Origo™

Instruction manual

0459 942 201 GB 20170502 Valid for: 039-xxx-xxxx

Tig 3000i AC/DC

TABLE OF CONTENTS

0459 942 201 © ESAB AB 2017

1SAFETY ......................................................................................................... 4

1.1 Meaning of symbols ................................................................................. 4

1.2 Safety precautions ................................................................................... 4

2INTRODUCTION............................................................................................ 7

2.1 Equipment ................................................................................................. 7

2.2 Control panel ............................................................................................ 7

3TECHNICAL DATA ........................................................................................ 8

4INSTALLATION.............................................................................................. 10

4.1 Lifting instruction ..................................................................................... 10

4.2 Location..................................................................................................... 10

4.3 Mains power supply ................................................................................. 10

5OPERATION .................................................................................................. 12

5.1 Connections and control devices ........................................................... 13

5.2 Key to symbols......................................................................................... 13

5.3 Fan control ................................................................................................ 13

5.4 Overheating protection ............................................................................ 13

6MAINTENANCE............................................................................................. 14

6.1 Inspection and cleaning........................................................................... 14

7FAULT-TRACING........................................................................................... 15

8ORDERING SPARE PARTS .......................................................................... 16

DIAGRAM ............................................................................................................. 17

ORDERING NUMBERS........................................................................................ 19

ACCESSORIES .................................................................................................... 20

Rights reserved to alter specifications without notice.

1 SAFETY

0459 942 201 -4- © ESAB AB 2017

1 SAFETY

1.1 Meaning of symbols

As used throughout this manual: Means Attention! Be Alert!

DANGER!

Means immediate hazards which, if not avoided, will result in immediate,

serious personal injury or loss of life.

WARNING!

Means potential hazards which could result in personal injury or loss of

life.

CAUTION!

Means hazards which could result in minor personal injury.

WARNING!

Before use, read and understand the instruction manual

and follow all labels, employer´s safety practices and Safety

Data Sheets (SDSs).

1.2 Safety precautions

Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who

works on or near the equipment observes all the relevant safety precautions. Safety

precautions must meet the requirements that apply to this type of equipment. The following

recommendations should be observed in addition to the standard regulations that apply to

the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the

equipment. Incorrect operation of the equipment may lead to hazardous situations which can

result in injury to the operator and damage to the equipment.

1. Anyone who uses the equipment must be familiar with:

○ its operation

○ location of emergency stops

○ its function

○ relevant safety precautions

○ welding and cutting or other applicable operation of the equipment

2. The operator must ensure that:

○ no unauthorised person is stationed within the working area of the equipment

when it is started up

○ no-one is unprotected when the arc is struck or work is started with the

equipment

3. The workplace must:

○ be suitable for the purpose

○ be free from drafts

1 SAFETY

0459 942 201 -5- © ESAB AB 2017

4. Personal safety equipment:

○ Always wear recommended personal safety equipment, such as safety glasses,

flame-proof clothing, safety gloves

○ Do not wear loose-fitting items, such as scarves, bracelets, rings, etc., which

could become trapped or cause burns

5. General precautions:

○ Make sure the return cable is connected securely

○ Work on high voltage equipment may only be carried out by a qualified

electrician

○ Appropriate fire extinguishing equipment must be clearly marked and close at

hand

○ Lubrication and maintenance must not be carried out on the equipment during

operation

WARNING!

Arc welding and cutting can be injurious to yourself and others. Take precautions

when welding and cutting.

ELECTRIC SHOCK - Can kill

• Install and ground the unit in accordance with instruction manual.

• Do not touch live electrical parts or electrodes with bare skin, wet gloves or

wet clothing.

• Insulate yourself from work and ground.

• Ensure your working position is safe

ELECTRIC AND MAGNETIC FIELDS - Can be dangerous to health

• Welders having pacemakers should consult their physician before welding.

EMF may interfere with some pacemakers.

• Exposure to EMF may have other health effects which are unknown.

• Welders should use the following procedures to minimize exposure to

EMF:

○ Route the electrode and work cables together on the same side of

your body. Secure them with tape when possible. Do not place your

body between the torch and work cables. Never coil the torch or

work cable around your body. Keep welding power source and

cables as far away from your body as possible.

○ Connect the work cable to the workpiece as close as possible to the

area being welded.

FUMES AND GASES - Can be dangerous to health

• Keep your head out of the fumes.

• Use ventilation, extraction at the arc, or both, to take fumes and gases

away from your breathing zone and the general area.

ARC RAYS - Can injure eyes and burn skin

• Protect your eyes and body. Use the correct welding screen and filter lens

and wear protective clothing.

• Protect bystanders with suitable screens or curtains.

NOISE - Excessive noise can damage hearing

Protect your ears. Use earmuffs or other hearing protection.

1 SAFETY

0459 942 201 -6- © ESAB AB 2017

MOVING PARTS - Can cause injuries

• Keep all doors, panels and covers closed and securely in place. Have only

qualified people remove covers for maintenance and troubleshooting as

necessary. Reinstall panels or covers and close doors when service is

finished and before starting engine.

• Stop engine before installing or connecting unit.

• Keep hands, hair, loose clothing and tools away from moving parts.

FIRE HAZARD

• Sparks (spatter) can cause fire. Make sure that there are no inflammable

materials nearby.

• Do not use on closed containers.

MALFUNCTION - Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

CAUTION!

This product is solely intended for arc welding.

WARNING!

Do not use the power source for thawing frozen pipes.

CAUTION!

Class A equipment is not intended for use in residential

locations where the electrical power is provided by the

public low-voltage supply system. There may be potential

difficulties in ensuring electromagnetic compatibility of class

A equipment in those locations, due to conducted as well

as radiated disturbances.

NOTE!

Dispose of electronic equipment at the recycling

facility!

In observance of European Directive 2012/19/EC on Waste

Electrical and Electronic Equipment and its implementation

in accordance with national law, electrical and/or electronic

equipment that has reached the end of its life must be

disposed of at a recycling facility.

As the person responsible for the equipment, it is your

responsibility to obtain information on approved collection

stations.

For further information contact the nearest ESAB dealer.

ESAB has an assortment of welding accessories and personal protection equipment

for purchase. For ordering information contact your local ESAB dealer or visit us on

our website.

2 INTRODUCTION

0459 942 201 -7- © ESAB AB 2017

2 INTRODUCTION

The Tig 3000i AC/DC is a TIG welding power source for alternating current (AC) or direct

current (DC). It can also be used for MMA welding.

ESAB accessories for the product can be found in the "ACCESSORIES" chapter of

this manual.

2.1 Equipment

The power source is supplied with:

Instruction manual for the welding power source, instruction manual for the control panel and

5 m return cable.

Instruction manuals in other languages can be downloaded from the Internet: www.esab.com

2.2 Control panel

TA24 AC/DC

See the separate instruction manual for a detailed description of the control panel.

3 TECHNICAL DATA

0459 942 201 -8- © ESAB AB 2017

3 TECHNICAL DATA

Tig 3000i AC/DC

Mains voltage 400 V, ±10%, 3~ 50/60 Hz

Mains supply Ssc min 5.3 MVA

Primary current

ImaxTIG 18 A

ImaxMMA 22 A

No-load power demand when in the

energy-saving mode,

6.5 min. after welding

26 W

Setting range

TIG, AC* / DC 4-300 A

MMA 16-300 A

Permissible load at TIG, AC/DC

35% duty cycle 300 A / 22 V

60% duty cycle 240 A / 19.6 V

100% duty cycle 200 A / 18 V

Permissible load at MMA

30% duty cycle 300 A / 32 V

60% duty cycle 230 A / 29.2 V

100% duty cycle 190 A / 27.6 V

Power factor at maximum current

TIG AC 0.85

TIG DC 0.90

MMA 0.91

Efficiency at maximum current

TIG AC 71 %

TIG DC 71 %

MMA 76 %

Open-circuit voltage

MMA



58 V

Operating temperature -10 to + 40° C

Transportation temperature -20 to + 55° C

Constant A-weighted sound pressure < 70 dB

Dimensions l x w x h 652 x 249 x 423 mm

Weight 48.5 kg

Insulation class transformer H

Enclosure class IP 23

Application class

3 TECHNICAL DATA

0459 942 201 -9- © ESAB AB 2017

*) The minimum current during AC welding depends on the alloy used for the aluminium

plates and their surface cleanliness.

Duty cycle

The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or

cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.

Enclosure class

The IP code indicates the enclosure class, i.e. the degree of protection against penetration

by solid objects or water.

Equipment marked IP23 is intended for indoor and outdoor use.

Application class

The symbol indicates that the power source is designed for use in areas with increased

electrical hazard.

Mains supply, Ssc min

Minimum short circuit power on the network in accordance with IEC 61000-3-12.

4 INSTALLATION

0459 942 201 - 10 - © ESAB AB 2017

4 INSTALLATION

The installation must be carried out by a professional.

NOTE!

Mains supply requirements

This equipment complies with IEC 61000-3-12 provided that the short-circuit

power is greater than or equal to Sscmin at the interface point between the user's

supply and the public system. It is the responsibility of the installer or user of the

equipment to ensure, by consultation with the distribution network operator if

necessary, that the equipment is connected only to a supply with a short-circuit

power greater than or equal to Sscmin. Refer to the technical data in the

TECHNICAL DATA chapter.

4.1 Lifting instruction

4.2 Location

Position the welding power source such that its cooling air inlets and outlets are not

obstructed.

4.3 Mains power supply

Check that the welding power source is connected to the correct

mains power supply voltage, and that it is protected by the correct

fuse size. A protective earth connection must be made in

accordance with regulations.

Rating plate with supply connection data

Recommended fuse sizes and minimum cable area

Tig 3000i AC/DC TIG MMA

Mains voltage 400 V 1-3~ 50/60 Hz 400 V 1-3~ 50/60 Hz

Mains cable area mm24 mm / phase 4 mm / phase

Altri manuali per Origo Tig 3000i

Indice

Altri manuali ESAB Sistema di saldatura

ESAB

ESAB Precision Plasmarc IEFC-S PT-24 Istruzioni generali

ESAB

ESAB CaddyTig HF Manuale utente

ESAB

ESAB Origo Arc 4001i Manuale utente

ESAB

ESAB Aristotig255 AC/DC DTE 255 Manuale utente

ESAB

ESAB ORIGO Mig C280 PRO Manuale utente

ESAB

ESAB Fabricator 181i Manuale utente

ESAB

ESAB PKB 250 Manuale utente

ESAB

ESAB Caddy Tig 1500i Manuale utente

ESAB

ESAB EMP 205ic AC/DC Manuale utente

ESAB

ESAB SDE-100 Manuale utente

ESAB

ESAB ESP-200 Manuale utente

ESAB

ESAB A6 Mastertrac Tandem Manuale utente

ESAB

ESAB A2SF J1 Manuale utente

ESAB

ESAB Aristo Mig 5000i Manuale utente

ESAB

ESAB A6TF F1 Manuale utente

ESAB

ESAB Thermal Dynamics CUTMASTER 40 Manuale utente

ESAB

ESAB Aristo Tig 4000iw Manuale utente

ESAB

ESAB Aristotig 405 AC/DC Manuale utente

ESAB

ESAB LAF 1001 Manuale utente

ESAB

ESAB 0700300989 Manuale utente

ESAB

ESAB MobileFeed 201 AVS Manuale utente

ESAB

ESAB Origo Mig 4002c Manuale utente

ESAB

ESAB Origo Mig C151 Manuale utente

ESAB

ESAB fabricator 141i Manuale utente

Manuali Sistema di saldatura popolari di altre marche

Berner

Berner PLASMACUT 54 Manuale utente

Pro Spot

Pro Spot PR-155 Manuale utente

Forney

Forney 210 Manuale utente

Thermal Arc

Thermal Arc 400S Manuale utente

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manuale utente

GYS

GYS PROTIG 201 AC/DC Manuale utente

TAFA

TAFA 30*8B35 Manuale utente

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manuale utente

CIGWELD

CIGWELD 636804 Guida rapida

Red-D-Arc

Red-D-Arc DC-400 Manuale utente

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manuale utente

Elettro

Elettro HI-MIG 3000 SYNERGIC Manuale utente

WIA

WIA Weldmatic 270 CP132-2 Manuale utente

Sonics

Sonics H520T Manuale utente

Miller

Miller Big Blue 400D Manuale utente

NewArc

NewArc RT2000 Guida rapida

Hypertherm

Hypertherm powermax1000 Manuale utente

Lincoln Electric

Lincoln Electric POWER WAVE I400 Manuale utente
